  • Page 1 SIMPLY CLEVER ŠKODA Fabia Owner's Manual...
  • Page 2 Notes Layout of this Owner's Manual (explanations) WARNING This Owner's Manual has been systematically designed to make it easy for you The most important notes are marked with the heading WARNING. These to search for and obtain the information you require. WARNING notes draw your attention to a serious risk of accident or injury.
  • Page 3 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. You have received a vehicle with the latest technology and range of amenities. Please read this Own- er's Manual carefully, because the operation in accordance with these instructions is a prerequisite for proper use of the vehicle.

  • Page 4: Interior Lighting - Version

    Terms used The on-board literature contains the following terms relating to the service work for your vehicle. › “Specialist garage” - a workshop that carries out specialist service tasks for ŠKODA vehicles A specialist garage can be a ŠKODA partner, a ŠKODA service partner or an independent workshop.

  • Page 5: Table Of Contents

    Electrical power windows Manual gear shifting and pedals Table of Contents Electric sliding/tilting roof Automatic transmission Running in Abbreviations Lights and visibility Economical driving and respect the Lights environment Safety Interior lights Avoiding damage to your vehicle Visibility Passive Safety Driving abroad Windscreen wipers and washers General information...
  • Page 6 Do-it-yourself Emergency equipment, and self-help Emergency equipment Changing a wheel Tyre repair Jump-starting Towing the vehicle Fuses and light bulbs Fuses Bulbs Technical data Technical data Vehicle data Index Table of Contents...
  • Page 7 Abbreviations Abbreviation Definition Engine revolutions per minute Anti-lock brake system Automatic gearbox Traction control discharged quantity of carbon dioxide in grams per driven in g/km kilometer Diesel particle filter Automatic double clutch gearbox Electronic differential lock Economic Commission for Europe Electronic Stability Control Rim depth European Union...

  • Page 8: Safety Passive Safety

    Check the tyre inflation pressure.  Safety Check the engine oil, brake fluid and coolant level.  Secure all items of luggage. Passive Safety  Do not exceed the permissible axle loads and permissible gross weight of  the vehicle – risk of accident. General information Close all doors and the engine compartment and luggage compartment lid.

  • Page 9: Correct And Safe Seated Position

    › Head airbags. Correct seated position of the driver › Anchoring points for child seats using the ISOFIX system. › Anchoring points for child seats using the TOP TETHER system. › Head restraints adjustable for height. › Adjustable steering column. The specified safety equipment works together, in order to optimally protect you and those travelling with you in accident situations.
  • Page 10 WARNING WARNING Always assume the correct seated position before setting off and do not The lever for adjusting the steering wheel must be locked while you are ■ ■ change this position while driving. Also advise your passengers to adopt driving so that the position of the steering wheel cannot accidently change the correct seated position and not to change this position while the car is during the journey –...
  • Page 11 Do not lean out of the window.  Correct seated position of the rear seat passengers Do not put your feet out of the window.   Read and observe on page 7 first. Do not put your feet on the dash panel. ...

  • Page 12: Seat Belts

    WARNING Seat belts Fasten your seat belt before each journey - even when driving in town! ■ This also applies to the people seated at the rear – there is a risk of injury. Wearing seat belts Expectant women must also always wear a seat belt. This is the only way ■...
  • Page 13 WARNING (Continued) The physical principle of a frontal collision The lock tongue should only be inserted into the lock which is the correct ■ one for your seat. Wrong use of the safety belt will reduce its capacity to protect and the risk of injury increases. The slot of the belt tongue must not be blocked otherwise the belt ■...
  • Page 14 › It is also important that rear passengers fasten their seat belts, as they could Insert the lock tongue into the belt buckle belonging to the seat » Fig. 5 –  otherwise be thrown through the vehicle in an uncontrolled manner in the until it you hear it click into place.

  • Page 15: Inertia Reel And Belt Pretensioners

    Belt height adjustment on the front seats Belt tensioners Safety for the driver and front passenger wearing their seat belts is enhanced Fig. 7 by the belt tensioners fitted to the inertia reels of the front three-point seat Front seat: Seat belt height ad- belts.

  • Page 16: Airbag System

    Airbag system System description  Read and observe on page 14 first. Description of the airbag system The functional status of the airbag system is indicated by the indicator light   Introduction in the instrument cluster » page This chapter contains information on the following subjects: When the airbags are deployed they fill with gas and inflate.

  • Page 17: Airbag Overview

    Deployment factors Front airbags It is not possible to generally determine which deployment conditions apply to the airbag system in every situation. An important role is played by factors such as the type of object that the vehicle hits (hard/soft), the impact angle, vehicle speed, etc.
  • Page 18 WARNING Side airbags Information on correct seating position For the driver and front passenger, it is important to maintain a distance ■ of at least 25 cm from the steering wheel or dashboard » Fig. 9. Not keeping to this minimum distance will mean that the airbag system will not be able to properly protect you –...

  • Page 19: Deactivating Airbags

    The airbag covers the windows of the front and rear doors, as well as the door WARNING pillar when it is deployed » Fig. 11 - . Only hang light items of clothing on the hooks fitted in the vehicle. Never ■...
  • Page 20 Deactivating airbags Switching off the front passenger airbag Deactivating an airbag should be considered only in the following cases, for example. › When using a child seat on the front passenger seat, in which the child has its back to the vehicle's direction of travel (in some countries this must be in the direction of travel due to different legal regulations applying) »...

  • Page 21: Transporting Children Safely

    › Check whether the warning light in the      mes-   Transporting children safely sage in the centre of the dash panel does not light up after the ignition is switched on. Child seat WARNING ...
  • Page 22 WARNING (Continued) Pay particular attention to the information provided by the manufacturer ■ of the child safety seat regarding the correct routing of the belt. Seat belts which are not correctly adjusted can themselves cause injuries even in mi- nor accidents. Safety belts must be checked to ensure that they are running properly.
  • Page 23 WARNING WARNING It is essential to switch off the front passenger airbag if you are using a Children must never be seated with their head in the deployment area of ■ ■ child seat on the front passenger seat in which the child is carried with its the side airbag –...

  • Page 24: Fastening Systems

    “Universal” child seat category - a child seat designed for fastening on There are two locking eyes between the rear exterior seats for fixing the the seat with the seat belt. ISOFIX system child seat in place. The places are marked with labels with the ISOFIX logo »...
  • Page 25 Size class Group Front passenger seat Outer rear seats Rear seat middle of the child seat IL-SU 9-18 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with the ISOFIX system attachment points, it is suited for the installation of an ISOFIX child seat with the “Semi-Universal” approval. IL-SU The seat is suited for installation of an ISOFIX child seat with the “Semi- WARNING (Continued)
  • Page 26 Fig. 18 Cockpit Using the system...

  • Page 27: Using The System

    Door opening lever Using the system Switch depending on equipment fitted: › Boot lid remote release Cockpit › Interior monitor Light switch and headlamp beam adjustment 56, 56 Overview Fuse box in the dashboard Door opening lever Bonnet release lever Electrical power windows Lever for adjusting the steering wheel Electric exterior mirror adjustment...

  • Page 28: Instruments And Indicator Lights

    Instruments and Indicator Lights Overview Instrument cluster  Introduction This chapter contains information on the following subjects: Overview Engine revolutions counter Speedometer Coolant temperature gauge display Fuel gauge Counter for distance driven Digital clock Display of the second speed Fig. 19 Instrument cluster Recommended gear ...
  • Page 29 Button for: Coolant temperature gauge display › Reset trip meter » page 28 ›  Set hours/minutes Read and observe on page 26 first. › Enable/disable the mode selected by means of button The coolant temperature gauge » Fig. 19 on page 26 operates only when Fuel gauge »...
  • Page 30 CAUTION Display of the second speed Never drive until the fuel tank is completely empty! The irregular supply of fuel  Read and observe on page 26 first. can cause misfiring. This can result in considerable damage to parts of the en- gine and the exhaust system.

  • Page 31: Multifunction Display (Mfd)

    If the control unit recognises that it is beneficial to change gear, an arrow Memory shown in the display. The arrow points up or down, depending on whether you should shift into a higher or lower gear. Fig. 21 At the same time, the recommended gear is shown at instead of the gear Multifunction display selected on vehicles with a manual gearbox.
  • Page 32 Operation Multifunction display details  Read and observe on page 29 first. Fig. 22 Multifunction display: Control el- Outside temperature ements The current outside temperature is displayed The temperature is shown with the snowflake symbol  if the outdoor tem- perature is below +4 °C.
  • Page 33 The display is updated regularly while you are driving. Warning against speeding The warning that the speed limit is being exceeded can be enabled/disabled in Range the display » page The estimated range is displayed in kilometres. It indicates the distance you can still drive with your vehicle based on the level of fuel in the tank and the Warning against speeding same style of driving.

  • Page 34: Service Interval Display

    The speed limit set mode is stored even after the ignition is switched off and Prompt in the segment display Fig. 23 Service Interval Display Example of a message  Introduction This chapter contains information on the following subjects: Prompt in the segment display Display in the MAXI DOT display A message concerning the kilometres and days remaining until the next service is due is shown for about 10 seconds after the ignition is switched on...

  • Page 35: Maxi Dot Display

    Note WARNING The kilometres remaining until the next service are displayed instead of the Concentrate fully on your driving at all times. As the driver you are fully re- odometer. sponsible for the operation of your vehicle. Display in the MAXI DOT display Main menu Oil change service If an oil change service is due, the message Oil change in ...
  • Page 36 Settings Door, boot lid and bonnet warning   Read and observe on page 33 first. Read and observe on page 33 first. You can change certain settings yourself through the MAXI DOT display. The If at least one door is open, or the boot or bonnet is open, the MAXI DOT dis- current menu item is shown in the top of the display under a line.

  • Page 37: Warning Lights

    The following message is shown in the MAXI DOT display. EPC fault light (petrol engine)  Diesel particulate filter (diesel engine)  Gearbox overheated. Stop. Log book!  Fuel reserve  Stop the vehicle, switch off the engine, and wait until the icon goes out – Airbag system ...

  • Page 38: Brake System

    Further information » page Brake system   Read and observe on page 35 first. Generator   indicator light comes on if the brake fluid level in the braking system is Read and observe on page 35 first.  too low or there is a fault in the ABS.

  • Page 39: The Following Message Is Shown In The Maxi Dot Display

    The warning light comes on for a few seconds when the ignition is switch-  Coolant   ed on  Read and observe on page 35 first. Stop the vehicle, switch off the engine, and check the engine oil lev- »...

  • Page 40: Power Steering

    As the ESC operates in conjunction with the ABS, the ESP indicator light will Power steering  also come on if the ABS system fails.  Read and observe on page 35 first. Further information » page 114, Stabilisation control (ESC). The warning light comes on for a few seconds when the ignition is switched ...

  • Page 41: The Rear Fog Light

    The following message is shown in the MAXI DOT display. Exhaust inspection system  Error: ABS   Read and observe on page 35 first. The vehicle will only be braked by the normal brake system without the ABS. If the warning light lights up, there is a fault in the exhaust inspection sys- ...

  • Page 42: Fuel Reserve

    In order to clean the filter, and where traffic conditions permit » , the vehicle Fuel reserve  should be driven at an even speed of at least 60 km/h at engine speeds of 1  800 - 2 500 rpm for at least 15 minutes or until the warning light goes out with Read and observe on page 35 first.

  • Page 43: Tyre Pressure

    WARNING Traction control (TCS) switched off  When a fault of the airbag system occurs, there is a risk of the system not  Read and observe on page 35 first. being triggered in the event of an accident. Therefore, this is to be checked immediately by a specialized company.

  • Page 44: Unlocking And Locking

    Selector lever lock Unlocking and locking   Read and observe on page 35 first. Unlocking and locking If the warning light lights up, operate the brake pedal. This is necessary to   Introduction be able to move the selector lever from position P or N »...

  • Page 45: Replacing The Battery In The Remote Control Key

    WARNING Replacing the battery in the remote control key Never leave the key in the vehicle when you exit the vehicle. Unauthor- ■ ized persons, such as children, for example, could lock the car, turn on the ignition or start the engine - there is the danger of injury and accidents oc- curring! When leaving the vehicle, never leave people who are not completely in- ■...

  • Page 46: Child Safety Lock

    Note Opening/closing the door The system has to be synchronised, if the vehicle cannot be unlocked or ■ locked with the remote control key after replacing the battery » page Replacing the battery in the key a glued decorative cover requires the cover ■...

  • Page 47: Central Locking System

    Locking/unlocking the vehicle without central locking Emergency locking of the doors Fig. 30 Rear door: Emergency locking of the door An emergency locking mechanism is located on the end face of the doors Fig. 29 Securing knob in the front door/rear door which have no locking cylinder, it is only visible after the door is opened.

  • Page 48: Individual Settings

    Warning light in the driver's door If the ignition key is withdrawn, the car is then automatically unlocked again. After locking the vehicle, the warning light flashes for around 2 seconds in In addition, it is possible for the driver or front passenger to unlock the car by quick succession, afterwards it begins to flash evenly at longer intervals.

  • Page 49: Unlocking The Vehicle Using The Key

    › All the doors and the boot lid are locked. WARNING › The switched on interior lights will switch off over the door contact. If the car is locked from the outside and the safelock system is switched on, › The windows and the electric sliding/tilting roof close while the key is held in no-one must be in the car, as it is then not possible to open either a door or the lock position.

  • Page 50: Remote Control

    › If at least one door has been opened, the vehicle cannot be locked. The battery must be replaced if the central locking or anti-theft alarm system ■ › In the event of an accident in which the airbags are deployed, the locked does react to the remote control at less than 3 metres away »...

  • Page 51: Anti-Theft Alarm System

    In addition, when the car is unlocked, the electrically adjustable seats and ex- Note terior mirrors move into the position assigned to this key. The stored setting of The working life of the alarm siren is 5 years. ■ driver seat and exterior mirrors is retrieved. Before leaving the car, it must be checked that all of the windows, doors and ■...

  • Page 52: Tailgate

    WARNING Interior monitor and towing protection Ensure that the lock is properly engaged after closing the boot lid. Other- ■ wise, the lid might open suddenly while the vehicle is moving, even if the Fig. 34 lid was locked – risk of accident! Button for interior monitor and Never drive with the tailgate fully opened or slightly ajar otherwise ex- ■...

  • Page 53: Electrical Power Windows

     Opening the boot lid for vehicles with central locking Read and observe on page 50 first. › Press the handle and open the tailgate in the direction of the arrow » Fig. 35 The boot lid can be unlocked manually if there is a fault in the central locking - .
  • Page 54  Read and observe on page 51 first. CAUTION Keep the windows clean to ensure the correct functionality of the electric ■ Power window buttons » Fig. windows. Button for electrical power window of the driver's door Should the windows freeze, first remove the ice »...

  • Page 55: Electric Sliding/Tilting Roof

    Power window force limiter Operational faults   Read and observe on page 51 first. Read and observe on page 51 first. The electrical power windows are fitted with a force limiter. It reduces the risk Electrical power windows do not operate of bruises or injuries when closing the windows.
  • Page 56 Force limiter CAUTION The sliding/tilting roof is fitted with a force limiter. If an obstacle (e.g. ice) pre- During the winter it may be necessary to remove any ice and snow in the vicin- vents closing, the sliding/tilting roof stops and opens completely. The sliding/ ity of the sliding/tilting roof before opening it to prevent any damage to the tilting roof can be closed completely without the force limiter by pushing the opening mechanism and seal.

  • Page 57: Lights And Visibility

    Emergency operation Lights and visibility Lights  Introduction This chapter contains information on the following subjects: Parking and low beam lights Headlight beam adjustment Daylight running lights (DAY LIGHT) Turn signal and main beam lights Halogen projector headlights with cornering light function Fig.

  • Page 58: Read And Observe And On Page 53 First

     Read and observe on page 55 first. Parking and low beam lights Turning the rotary switch » Fig. 41 from position  to  gradually adjusts the Fig. 40 headlight beam thereby shortening the beam of light. Dash panel: Light switch The positions of the rotary switch correspond approximately to the following car load.

  • Page 59: Turn Signal And Main Beam Lights

    Activating on vehicles with the START-STOP system When the left or right turn signal is on, the warning light flashes in the   › Switch off the ignition. instrument cluster. › At the same time, pull the turn signal light stalk »...

  • Page 60: Fog Lights

    Fog lights Rear fog light  Read and observe on page 55 first. Fig. 43 Dash panel: Light switch Switching on/off › First turn the light switch » Fig. 43 on page 58 to position  or . › Pull the light switch to position The rear fog light is switched off in the reverse sequence.

  • Page 61: Interior Lights

    › Engage reverse gear (manual gearbox) or move the selector lever to the R All the turn signal lights on the vehicle flash at the same time when the hazard position (automatic gearbox), warning light system is switched on. The warning light for the turn signals and ›...

  • Page 62: Rear Interior Light

    Interior lighting - version 1 Interior lighting - version 2 Fig. 45 Fig. 46 Interior lighting – version 1 Interior lighting – version 2 Positions of sliding switch » Fig. Slide switch positions » Fig. Switch on Switch on  ...

  • Page 63: Visibility

    Note Luggage compartment light If the on-board voltage drops, the rear window heater switches off automati- The light comes on automatically when the boot lid is opened. If the tailgate cally, in order to provide sufficient electrical energy for the engine con- remains open for more than 10 minutes, the luggage compartment light trol »...
  • Page 64 The windscreen wipers and the windscreen washer system only operate when Windscreen wiper and washer the ignition is switched on. The rear window is wiped once automatically if the windscreen wipers are on Fig. 50 when reverse gear is selected. Operating stalk: Windscreen wipers and washer settings Top up with windscreen wiper fluid...

  • Page 65: Rear Window

    Windshield wiper blades in proper condition are essential to obtain good visi- Headlight cleaning system bility. Wiper blades should not be allowed to become dirtied by dust, insect re-  Read and observe on page 62 first. mains and preserving wax. Juddering or smearing of the wiper blades could then be due to wax residues The headlights are sprayed briefly if the low beam or main beam are switched left on the windshield by vehicle washing in automatic vehicle wash systems.
  • Page 66 The movement of the mirror surface follows the movement of the rotary knob. WARNING Make sure that the mirror is not covered by ice, snow, condensation or ■ Folding in the exterior mirrors other objects. The whole exterior mirror can be manually folded towards the side windows. Convex (curved outward) or aspheric exterior mirrors increase the field of ■...

  • Page 67: Seats And Storage

    Seats and storage Adjusting the front seats - Version 1 Front seats Fig. 54 Control elements on the seat  Introduction This chapter contains information on the following subjects: Adjusting the front seats - Version 1 Adjusting the front seats - Variant 2 Front seat heating The driver's seat should be adjusted in such a way that the pedals can be fully ...

  • Page 68: Rear Seats

    › Release the lever and push the seat until the lock clicks into place. CAUTION Do not kneel on the seats or otherwise apply pressure at specific points to ■ Adjusting height of seat › avoid damaging the heating elements for the seat heaters. To lift the seat, pull or pump lever »...

  • Page 69: Head Restraints

    The luggage compartment can be increased in size by folding the seat backr- Folding the seat cushions forwards, removing ests forward. The seat backrests can be folded forward individually on vehicles with divided rear seats. Folding forward › Before folding the rear seats forwards, adapt the position of the front seats in such a way that they are not damaged by the folded rear seats.

  • Page 70: Boot

    Adjusting the head restraints Storing the head restraints in the seat squabs Fig. 60 Rear seats: Inserting head re- straints in the seat cushions The rear head restraints can be inserted into the corresponding holes in the Fig. 59 Head restraint: adjusting/removing folded seat squabs »...

  • Page 71: Fastening Elements

    Example: In the event of a frontal collision at a speed of 50 km/h, an object Note weighing 4.5 kg produces energy corresponding to 20 times its own weight. Tyre pressure must be adjusted to the load » page 151, Tyre service life. This means that it results in a weight of approx.

  • Page 72: Folding Hooks

    WARNING Folding hooks Do not exceed the maximum permissible load of the fixing nets. Heavy ob- jects are not secured adequately – there is a risk of injury. Fig. 62 Boot: folding hooks CAUTION The maximum permissible load of the fixing nets is 1.5 kg. ■...

  • Page 73: Further Positions Of The Luggage Compartment Cover

    WARNING CAUTION No objects should be placed on the boot cover, the vehicle occupants could In this position » Fig. 65 -  the luggage compartment cover is designed for be endangered if there is sudden braking or the vehicle collides with some- small objects up to a weight of 2.5 kg.

  • Page 74: Variable Loading Floor In The Luggage Compartment (Fabia Estate)

    Variable loading floor in the luggage compartment (Fabia Estate) Removing and refitting the variable loading floor  Introduction This chapter contains information on the following subjects: Dividing up the luggage compartment with variable loading floor Removing and refitting the variable loading floor Removing and installing carrier rails The variable loading floor makes handling of bulky items of luggage easier.

  • Page 75: Net Partition (Fabia Estate)

    Removing and installing carrier rails Net partition (Fabia Estate)  Introduction This chapter contains information on the following subjects: Using the net partition behind the rear seats Using the net partition behind the front seats Removing and refitting the net partition housing WARNING The belt locks and the belts must be in their original position after folding ■...
  • Page 76 › Pull the net partition by tab » Fig. 70 out of the housing in the direc- Retracting › tion of mounts Pull the transverse rod back slightly first on one side and then on the other › Insert the transverse rod into one of the mounts and push forwards.

  • Page 77: Bicycle Carrier In The Luggage Compartment

    › Check how well the cross member is fastened by pulling on it. Bicycle carrier in the luggage compartment  Install bicycle carrier Introduction This chapter contains information on the following subjects: Fig. 74 Install cross member Install bicycle carrier Install bicycle carrier Put bicycle into the bicycle carrier Secure the stability of the bicycles with a belt...

  • Page 78: Roof Rack System

    Put bicycle into the bicycle carrier Secure the stability of the bicycles with a belt Fig. 75 Put in the bicycle/example fastening the front wheel Fig. 76 Securing bicycles   Read and observe on page 75 first. Read and observe on page 75 first.

  • Page 79: Useful Equipment

    WARNING Attachment points The items being transported on the roof rack must be reliably attached – ■ there is the risk of an accident. Fig. 77 Always secure the load with appropriate and undamaged lashing straps ■ Attachment points for roof bars or tensioning straps.
  • Page 80 WARNING CAUTION Do not place anything on the dash panel. These objects might slide or fall Do not leave open beverage containers in the cup holder during the journey. ■ down while you are driving (under acceleration or when cornering) and There is a risk of spilling e.g.
  • Page 81 Cigarette lighter 12-volt power outlet Fig. 80 Fig. 81 Centre console: Cigarette lighter Boot: 12-Volt power socket   Read and observe on page 78 first. Read and observe on page 78 first. Operation The 12-volt electrical outlet (hereinafter referred to only as a socket) is located ›...

  • Page 82: Storage Compartments

     Connecting electrical components when the engine is not running will drain Read and observe on page 78 first. ■ the battery of the vehicle – there is a risk of the battery discharging. The note holder is designed e.g. for attaching car park tickets. Only use matching plugs to avoid damaging the power socket.

  • Page 83: Storage Compartments On The Front Passenger Side

    Opening the air supply when the air conditioning system is switched on allows Storage compartments on the front passenger side cooled air to flow into the storage compartment. Opening the air inlet when the air conditioning system is on causes fresh or in- Fig.

  • Page 84: Glasses Storage Box

    WARNING Stowage compartment in centre console Never put heavy items in the map pockets – risk of injury. Fig. 88 CAUTION Centre console: Stowage com- Do not put any large items such as bottles or sharp objects into the map pock- partment ets, as the pockets and the seat covers could be damaged.

  • Page 85: Front Armrest With Storage Compartment

     Read and observe on page 80 first. Front armrest with storage compartment There is a bottle holder at » Fig. 91 of the pocket in the front doors. WARNING Use the section » Fig. 91 of the door pocket only for storing objects which do not project so that the effectiveness of the side airbag is not im- paired.

  • Page 86: Heating And Air Conditioning

    Flexible storage compartment Heating and air conditioning Heating, ventilation, cooling Fig. 93 Flexible storage compartment  Introduction This chapter contains information on the following subjects: Air outlets Using the air conditioning system economically Operational problems The heating effect is dependent upon the coolant temperature, thus full heat ...
  • Page 87 Close air outlet vents 3 and 4 Note › Turn the vertical wheel (air vents 3) » Fig. 94 or the horizontal wheel (air out- The exhaust air streams out through vents at the rear of the luggage com- ■ let nozzles 4) to the 0 position.

  • Page 88: Heating

    If you are not able to resolve the fault yourself, or if the cooling output has re- Functions of the individual controls » Fig. duced, switch off the cooling system and obtain assistance from a specialist Set the temperature (turn to the left: to reduce the temperature, turn to garage.

  • Page 89: Air Conditioning System (Manual Air Conditioning System)

    Setting Recommended basic settings of the heating controls. Control dial settings » Fig. 95 on page 86 Symbol Key  » Fig. 95 Air outlet vents 4 » Fig. 94 Setting on page 86 page 85 Defrosting the windshield and side To the right up to the Open and align with the side ...
  • Page 90 The cooling system operates only if the following conditions are met. Operation The cooling system is switched on » page  The engine is running.  The outside temperature is above approximately +2 °C.  The blower switch is switched on (positions 1-4). ...
  • Page 91 Setting the air conditioning system  Read and observe on page 88 first. Recommended basic settings of the air conditioning controls. Control dial settings » Fig. 96 on page 88 Button » Fig. 96 on page 88 Air outlet vents 4 »...

  • Page 92: Climatronic (Automatic Air Conditioning System)

    Climatronic (automatic air conditioning system) Control elements  Introduction This chapter contains information on the following subjects: Control elements Automatic mode Setting the temperature Recirculated air mode Controlling the blower Defrosting windscreen Climatronic in automatic mode ensures the best-possible setting of the tem- perature of the outflowing air, the blower stage and air distribution.
  • Page 93 Switch recirculation on/off » page 91  CAUTION Switch the cooling system on/off Lengthy and uneven distribution of the air flow out of the vents (especially  around the feet) and large differences in temperature, for example, when get- Note ting out of the vehicle, can cause susceptible individuals to catch a cold.

  • Page 94: Communication And Multimedia

    The blower speed set is indicated by displaying the corresponding number of Communication and multimedia segments in icon » Fig. 97 on page 90 in the display. Universal telephone preinstallation GSM II WARNING “Stale air” may result in fatigue in the driver and occupants, reduce atten- ■...

  • Page 95: Introductory Information

    › Managing telephone calls via the adapter » page WARNING (Continued) › Telephone operation in the MAXI DOT display » page The national regulations for using a mobile phone in a vehicle must be ■ › Voice control of the telephone »...

  • Page 96: Operating The Phone On The Multifunction Steering Wheel

    Operating the phone on the multifunction steering wheel There are buttons in the steering wheel for easy operation of the basic func- Fig. 98 tions of the phone » Fig. 98 so that the driver is distracted from the traffic as Multifunction steering wheel: little as possible when using the phone.

  • Page 97: Managing Telephone Calls With The Help Of The Adapter

    The following steps must be carried out for the connection. CAUTION › Taking the mobile phone out of the adapter during the call can lead to inter- ® Activate Bluetooth and the visibility of your mobile phone on your tele- ruption of the connection.

  • Page 98: Symbols In The Maxi Dot Display

    Creating a connection with an already paired mobile phone Symbol Meaning After switching on the ignition, the connection is automatically established for The hands-free system is visible to other devices.  the already paired mobile phone . Check on your mobile phone if the automat- A multimedia unit is connected to the hands-free system.

  • Page 99: Voice Control

    Bluetooth Optimum understanding of the voice commands depends on several factors. › The following menu items can be selected from the Bluetooth menu item. Speak with a normal tone of voice without intonation and excessive pauses. › User - Overview of the stored users Avoid a bad pronunciation.

  • Page 100: Multimedia

    Store voice recording of a contact Note If automatic name recognition does not work reliably for some contacts, you The dialogue of an incoming call is immediately interrupted. ■ can choose to save your own voice tag for the contact in the Phone book - The voice control is only possible in vehicles fitted with a multifunction ■...
  • Page 101 Operating the radio and navigation system on the multifunction steering wheel The radio and navigation system can of course still be operated on the devices. Fig. 101 A description is included in the relevant operating instructions. Multifunction steering wheel: If the side lights are switched on, the buttons on the multifunction steering Control buttons and wheel wheel are illuminated.
  • Page 102 The AUX- and MDI inputs are used to connect external audio sources (e.g. iPod or MP3 player) and to play back music from these devices via the factory-fitted radio or navigation system. For a description of use, refer to the relevant operating instructions for the ra- dio or navigation system.

  • Page 103: Driving

    CAUTION Driving The starter must only be operated when the engine is not running and the ■ vehicle is at a standstill. The starter or engine can be damaged if the starter is Starting-off and Driving activated when the engine is running »...

  • Page 104: Brakes

    The MAXI DOT display shows the following: Starting the engine Immobilizer active.  Read and observe on page 101 first. Ignition lock Vehicles with a diesel engine are equipped with a glow plug system. The glow plug warning light lights up after the ignition has been switched on. Start ...
  • Page 105 The brake pads wear more quickly if a lot of journeys are completed in towns WARNING and over short distances or if a very sporty style of driving is adopted. Greater physical effort is required for braking when the engine is switch- ■...

  • Page 106: Manual Gear Shifting And Pedals

    Handbrake Manual gear shifting and pedals  Introduction Fig. 103 Handbrake This chapter contains information on the following subjects: Manual gear changing Pedals Manual gear changing Fig. 104  Shift pattern of the 5-speed Read and observe on page 103 first. manual gearbox Apply ›...

  • Page 107: Automatic Transmission

    In the driver's footwell, only a footmat, which is attached to the two corre- CAUTION sponding attachment points, may be used. If the selector lever is shifted to N while the vehicle is being driven you must ■ lift off the accelerator pedal and you will need to wait until the engine has Only use factory-supplied footmats or footmats from the range of ŠKODAOrigi- reached its idling speed before shifting the selector lever to a forward driving nal Accessories, which are fitted to two attachment points.
  • Page 108 - Reverse gear Manual gear shifting (Tiptronic) Reverse gear can only be engaged when the vehicle is stationary and the en- gine is at idling speed. Depress the brake pedal and simultaneously press the shiftlock in the selector lever grip before shifting to R from P or N. - Neutral Power transmission to the drive wheels is interrupted in this mode.
  • Page 109 When accelerating, the gearbox automatically shifts up into the higher gear The gearbox shifts down one or more gears depending on the vehicle speed just before the maximum permissible engine speed is reached. and engine speed, and the vehicle accelerates. If a lower gear is selected, the gearbox does not shift down until there is no The gearbox does not shift up into the highest gear until the engine has risk of the engine overrevving.

  • Page 110: Running In

    Up to 1 000 kilometres Selector lever-emergency unlocking › Do not drive faster than 3/4 of the maximum speed of the gear in use, i.e. 3/4 of the maximum permissible engine speed. Fig. 107 › No full throttle. Selector lever-emergency un- ›...

  • Page 111: Economical Driving And Respect The Environment

    Fuel consumption is also be influenced by external factors which are beyond New tyres the driver's control. Consumption increases during the winter or under difficult New tyres have to be “run in” since they do not offer optimal grip at first. Drive conditions, on poor roads, etc.

  • Page 112: Avoiding Full Throttle

    An effective way of achieving good fuel economy is to shift up early. Observe In vehicles not equipped with the START-STOP system, turn off the engine the recommended gear » page 28, Recommended gear. when in a traffic jam, at a level crossing or traffic lights with longer wait times. A suitably selected gear can have an effect on fuel consumption »...

  • Page 113: Avoiding Unnecessary Ballast

    Always ensure the tyre inflation pressure is correct. If the pressure is too low, For the sake of the environment the tyres will have to overcome a higher rolling resistance. This will not only Additional improvements to the fuel economy can be made by using synthet- ■...

  • Page 114: Avoiding Damage To Your Vehicle

    › No asbestos. General information › Reduction in the “vaporisation” of plastics. Pay attention to low-slung parts of the vehicle, such as the spoiler and ex- Manufacture › haust, particularly in the following situations. Solvent-free cavity protection. › › When driving on poorly maintained roads and tracks. Solvent-free protection of the vehicle for transportation from the production ›...

  • Page 115: Driving Abroad

    WARNING Unleaded petrol Driving through water, mud, sludge etc. can reduce the braking power ■ A vehicle fitted with a petrol engine must always be refuelled with unleaded and extend the braking distance – there is the risk of an accident. petrol »...

  • Page 116: Assist Systems

    Assist systems Stabilisation control (ESC)  Read and observe on page 114 first. Brake assist systems The ESC system helps to maintain control of the vehicle in situations where it  Introduction is being operated at its dynamic limits, such as a sudden change to the direc- tion of travel.
  • Page 117 Hill hold control (HHC) The ASR function is automatically activated each time the ignition is switched HHC allows you to move your foot from the brake pedal to the accelerator ped- al without having to use the handbrake when pulling away on a gradient. During an intervention of the system, the TCS warning light flashes in the ...

  • Page 118: Parking Aid

    Parking aid Function  Introduction Fig. 113 Parking aid: Range of sensors This chapter contains information on the following subjects: Function Activation/deactivation WARNING The parking aid is not a substitute for the driver paying proper attention ■ and it is always the driver's responsibility to take care when reversing the vehicle or carrying out similar manoeuvres.

  • Page 119: Cruise Control System

    It is not possible on vehicles fitted with an automatic gearbox to switch on Note ■ the cruise control system if the selector lever is in the position P, N or R. The system cannot be activated on vehicles with a factory-fitted towing device The cruise control system may automatically switch off when some brake as- ■...

  • Page 120: Start-Stop

    › The speed will increase continuously, if the rocker button is pressed and held System conditioned automatic start-up in the RES position. Release the rocker button once the desired speed is Manually deactivating/activating reached. The set speed is then stored in the memory. Information messages Decreasing the speed The START-STOP system (hereinafter referred to just as the system) reduces...
  • Page 121 If after stopping the car, the message UNABLE TO START STOP appears in the System conditioned automatic start-up segment display or in the MAXI DOT display the check mark » Fig. 115, then  the conditions for automatic engine shutdown are not met. Read and observe on page 118 first.

  • Page 122: Towing A Trailer

    Error: start-stop system  Towing a trailer ERROR START-STOP  Towing device A system error is present. Seek help from a specialist garage.  Introduction This chapter contains information on the following subjects: Description Adjusting the ready position Fitting the ball head Check proper fitting Removing the ball head Use and care...
  • Page 123 Release pin Description Locking ball Note The tool for removing the wheel trim is part of the vehicle tool ■ » page 159 If you lose the key, please get in touch with a specialist garage. ■ Adjusting the ready position Fig.
  • Page 124 WARNING Fitting the ball head Carefully remove the cap for the mounting recess - there is a risk of hand ■ injury. Keep your hands outside the lever's range of motion when attaching the ■ ball head – there is a risk of finger injury. Never attempt to pull the operating lever upwards forcibly to turn the ■...
  • Page 125 › The key is removed. Offer up the cap to the rear bumper » Fig. 117 on page 121 aligning it with  “check mark” in the lower bumper area. The cap is on the lock of the operating lever. ...

  • Page 126: Trailer

    The engine output falls as altitude increases, as does the ability to climb. CAUTION Therefore, for every additional 1000 m in height (or part), the maximum per- Apply grease to the upper part of the mounting recess. Make sure you do not missible towed weight must be reduced by 10 %.
  • Page 127 On downhill sections shift down a gear in good time to also use the engine as Always switch off the anti-theft alarm system before a trailer is coupled or un- a brake. coupled » page Conditions for including a trailer in the anti-theft alarm system. Engine overheating The speed must be reduced immediately if the needle for the coolant tempera- The vehicle is factory-fitted with an anti-theft alarm system and towing...

  • Page 128: General Maintenance

    WARNING General Maintenance We advise you only to use ŠKODA Original Accessories and ŠKODA Origi- ■ nal Parts which have been expressly approved for use on your vehicle. Reli- Car care ability, safety and suitability for your vehicle are guaranteed with these. ŠKODA Original Accessories and ŠKODA Original Parts can be purchased ■...
  • Page 129 Before you decide to have damaged body parts replaced, however, you should Spoiler first contact your specialist garage to determine whether or not such parts can  also be repaired. Repairs to body parts are usually cheaper. Read and observe on page 126 first.

  • Page 130: Washing The Car

    It is essential to also thoroughly clean the underside of the vehicle at the end WARNING of the winter. Observe the following instructions for the airbag system. It is prohibited to tamper with individual parts of the airbag system as this ■...

  • Page 131: Vehicle Exterior Care

    The temperature of the water used for cleaning must not exceed 60 °C – ■ Automatic car wash systems there is a risk of damaging the vehicle.  Read and observe on page 128 first. See also Washing a vehicle with decorative film trim using a high-pressure ■...

  • Page 132: Caring For Vehicle Paintwork

    CAUTION CAUTION Do not use any insect sponges, kitchen scrubbers or similar cleaning prod- Never apply wax to the windows. ■ ■ ucts – there is a risk of damaging the paintwork finish. Mat painted or plastic parts must not be treated with polishing products or ■...

  • Page 133: Decorative Films

    CAUTION CAUTION Do not polish the chrome parts in a dusty environment - there is a risk of The ice scraper should not be moved forward and backward but in one direc- ■ scratching the finish. tion to avoid any damage to the surface of the glass. Snow or ice that is contaminated with coarse dirt such as fine gravel, sand, ■...

  • Page 134: Care Of The Interior

    CAUTION Underbody waxing Severe layers of dirt on the wheels can also result in wheel imbalance. This  Read and observe on page 129 first. may show itself in the form of a wheel vibration which is transmitted to the steering wheel which, in certain circumstances, can cause premature wear of All the cavities of your vehicle which are at risk from corrosion are protected the steering.

  • Page 135: Completely Independent, E.g. Children - There Is A Danger Of Poisoning

    The leather should be cleaned on a regular basis depending on the amount of WARNING wear-and-tear. Care products may be harmful to your health if not used according to the ■ instructions. Dust and dirt in pores and creases act as abrasives. This leads to severe abra- Always keep the automobile care products safe from people who are not ■...
  • Page 136 Avoid leaving the vehicle for lengthy periods in bright sunlight to prevent the Note ■ fabrics from bleaching. If the vehicle is parked in the open for lengthy periods, During the life of the vehicle, minor visible changes can occur on the leather protect the fabrics against direct sunlight by covering them.

  • Page 137: Inspecting And Replenishing

    Soiled belts may impair proper operation of the inertia reels. Inspecting and replenishing WARNING Fuel The seat belts must not be removed for cleaning. ■ Never clean the seat belts chemically as chemical cleaning products could ■  Introduction destroy the fabric. The seat belts must not be allowed to come into contact with corrosive ■...
  • Page 138 Refuelling Unleaded petrol  Read and observe on page 135 first. The vehicle can only be operated with unleaded petrol in compliance with the EN 228 standard. All petrol engines can be operated using petrol with a maximum of 10% bioe- thanol (E10).
  • Page 139 CAUTION Diesel fuel Even filling the tank with leaded petrol that does not meet the standard ■  Read and observe on page 135 first. once can lead to serious damage to parts of the exhaust system. Do not start the engine or switch on the engine if you have refuelled in error ■...

  • Page 140: Engine Compartment

    CAUTION WARNING The vehicle cannot be operated with biofuel RME, therefore this fuel must Information for working in the engine room ■ not be filled in the tank and used for driving the vehicle. The use of biofuel Keep all people, especially children, away from the engine compartment. ■...
  • Page 141 WARNING Opening and closing the bonnet Information for working on the fuel system or the electrical system Always disconnect the vehicle battery from the electrical system. ■ Do not smoke. ■ Never work near open flames. ■ Always have a functioning fire extinguisher nearby. ■...
  • Page 142 Closing Note › Lift the bonnet slightly and unhook the bonnet support. Press the bonnet The location of the inspection points in the engine compartment of petrol and prop into the bracket provided. diesel engines is practically identical. › Let the bonnet drop into the lock carrier lock from a height of around 20 cm – do not push it in.

  • Page 143: Engine Oil

    Clear water is not sufficient to intensively clean the windscreen and head- The specifications (VW standards) stated in the following can be indicated sep- lights. We recommend using clean washing water together with the screen arately or together with other specifications on the bottle. cleaner from the range of ŠKODA Original Accessories (in winter additionally The oil capacities include oil filter change.
  • Page 144 Diesel engines Specification Capacity Checking the oil level 1.2 l/55 kW TDI CR DPF VW 507 00 Fig. 128 1.6 l/55 kW TDI CR DPF VW 507 00 Principle sketch: Dipstick 1.6 l/66 kW TDI CR DPF VW 507 00 1.6 l/77 kW TDI CR DPF VW 507 00 Engine oil VW 505 01 can optionally be used in diesel engines without a DPF.

  • Page 145: Coolant

    We recommend maintaining the oil level within the range , but not above, if The coolant consists of water with a concentration of coolant additive. This the engine has been operating at high loads, for example, during a lengthy mixture guarantees antifreeze protection, protects the cooling/heater system motorway trip during the summer months, towing a trailer or negotiating a against corrosion and prevents the formation of scale.
  • Page 146 Explanation of graphic » Fig. 129 Capacity Mark for the maximum coolant level.  Read and observe on page 143 first. Mark for the lowest permissible level of coolant. Coolant capacity (in litres) The coolant level should be kept between the marks Petrol engines Capacity If the coolant level is above the mark...

  • Page 147: Brake Fluid

     Do not use an alternative additive if the specified coolant is not available in an Read and observe on page 145 first. emergency. In this case, use just water and have the correct mixing ratio of The brake fluid reservoir is located in the engine compartment »...
  • Page 148 Disconnecting or reconnecting WARNING (Continued) If any battery electrolyte comes into contact with your eyes, rinse the Automatic load deactivation ■ eyes immediately with clear water for several minutes - consult a doctor Warning symbols on the vehicle battery immediately. Symbol Meaning Splashes of acid on your skin or clothes should be neutralised as soon as...
  • Page 149  Read and observe on page 146 first. CAUTION The vehicle battery must only be disconnected if the ignition is switched off, ■ The battery is located in the engine compartment below a plastic otherwise the vehicle's electrical system (electronic components) can be dam- »...
  • Page 150 We therefore recommend that you have the battery checked and, if necessary, CAUTION recharged by a specialist garage before the start of the winter. On vehicles with the START/STOP system, the pole terminal of the charger must not be connected directly to the negative terminal of the vehicle battery, CAUTION but only to the engine earth »...

  • Page 151: Wheels

    Automatic load deactivation Wheels  Read and observe on page 146 first. Tyres and rims The vehicle voltage control unit automatically prevents the battery from dis-  Introduction charging when the battery is subjected to heavy loads. This may be noticed from the following.
  • Page 152 WARNING (Continued) WARNING (Continued) Unusual vibrations or pulling of the vehicle to one side could be a sign of If the wheel bolts are tightened to a too low tightening torque, the rim ■ ■ tyre damage. If there is any doubt that a wheel is damaged, immediately re- can come loose when the car is moving –...
  • Page 153 Adjust the tyre pressure accordingly if you are carrying a greater load. Tyre service life Driving style Fast cornering, sharp acceleration and braking increase the wear of your tyres. Balancing wheels The wheels of a new vehicle are balanced. There are a wide range of influen- ces when the car is being driven which may result in an imbalance.
  • Page 154 Tyre age 190 km/h Tyres age losing their original characteristics, even if they are not used. There- 200 km/h fore, we recommend that you do not use summer or winter tyres that are older 210 km/h than 6 years or 4 years respectively. 240 km/h 270 km/h Explanation of the tire labelling...
  • Page 155 Fabia GreenLine - approved tyres / rim combinations Tyre Load Speed Motorisation size index icon Tyre Load Speed Motorisation size index icon 165/70 R14 185/60 R14 1.2 l/55 kW TDI CR 185/60 R15 185/60 R15 Fabia Green tec - approved tyres / rim combinations 1.4 l/63 kW 195/55 R15 Tyre...
  • Page 156 Tyre Load Speed Tyre pressure monitor Motorisation size index icon 205/40 R17 Fig. 135 Button for setting the tyre infla- 1.2 l/63, 77 kW TSI 205/45 R16 tion pressure control value 185/60 R15 205/40 R17 1.4 l/63 kW 205/45 R16 185/60 R15 205/40 R17 1.2 l/55 kW TDI CR...
  • Page 157 Stowing the wheel WARNING › Place the wheel into the spare wheel well with the wheel rim pointing down- When the warning light illuminates, immediately reduce the speed and ■  ward. avoid sudden steering and brake manoeuvres. Stop the vehicle as soon as ›...

  • Page 158: Winter Use

    Fitting Full wheel trim › Push the cap onto the wheel bolt up to the stop.  Read and observe on page 149 first. The wheel bolt caps are housed in a plastic box in the spare wheel or in the storage space for the spare wheel.
  • Page 159 For the sake of the environment Re-fit the summer tyres at an appropriate time as they provide better handling properties, a shorter braking distance, less tyre noise, and reduced tyre wear on roads which are free of snow and ice as well as at temperatures above 7 °C. The fuel consumption is also lower.

  • Page 160: Do-It-Yourself

    Do-it-yourself Fire extinguisher Emergency equipment, and self-help Fig. 139 Fire extinguisher Emergency equipment  Introduction This chapter contains information on the following subjects: First aid kit and warning triangle Fire extinguisher Vehicle tool kit The fire extinguisher is attached by two straps in a bracket under the driver's seat.

  • Page 161: Changing A Wheel

    WARNING Vehicle tool kit The factory-supplied lifting jack is only intended for your model of vehicle. ■ Under no circumstances attempt to lift heavier vehicles or other loads – there is a risk of injury. Ensure that the vehicle tool kit is safely secured in the boot. ■...
  • Page 162 › Switch off the engine. WARNING (Continued) › Move the gearshift lever into Neutral or move the selector lever for the auto- Secure the base plate of the lifting jack with suitable means to prevent ■ matic gearbox into position P. possible moving.
  • Page 163 › Have the tightening torque of the wheel bolts checked with a torque Note wrench as soon as possible. If it proves difficult to undo the bolts, carefully apply pressure to the end of the › Change the damaged wheel or consult a specialist garage about repair possi- wrench with your foodt.

  • Page 164: Tyre Repair

    › Support the base plate of the jack with its full area resting on level ground Note and ensure that the jack is located in a vertical position at the point where Make a note of the code number hammered into the rear side of the adapter ■...
  • Page 165 Repair kit components » Fig. 145 WARNING A tyre filled with sealant has the same driving characteristics as a stand- ■ Valve remover ard tyre. Sticker with “max. 80 km/h”/“max. 50 mph” speed designation Do not travel faster than 80 km/h. ■...

  • Page 166: Jump-Starting

    › Do not remove the foreign body, e.g. screw or nail, from the tyre. Once a tyre pressure of 2.0 – 2.5 bar is reached, the journey may be continued › Unscrew the valve cap. at a maximum speed of 80 km/h (50 mph). ›...
  • Page 167 WARNING Jump-starting using the battery from another vehicle A discharged vehicle battery may already freeze at temperatures just be- ■ low 0 °C. If the battery is frozen, do not jump start with the battery of an- Fig. 146 other vehicle – there is a risk of explosion. Jump-starting: A –...

  • Page 168: Towing The Vehicle

    › Negative cable - colour coding in the majority of cases is black. On vehicles with a manual transmission, only push down on the accelerator pedal once the rope is taught. Jump-starting in vehicles with the START-STOP system The maximum towing speed is 50 km/h. Driver of the towed vehicle Fig.
  • Page 169 Note Rear towing eye We recommend using a tow rope from ŠKODA Original Accessories available ■ from a ŠKODA Partner. Fig. 149 Towing another vehicle requires a certain amount of practice. Both drivers ■ Rear towing eye should be familiar with the particular points about towing a vehicle. Unskilled drivers should not attempt to tow in another vehicle or to be towed in.

  • Page 170: Fuses And Light Bulbs

    Note Fuses and light bulbs We recommend that you always carry replacement fuses in the vehicle. A box ■ of replacement fuses can be purchased from ŠKODA Original Accessories. Fuses One fuse may cover several consumers. ■  A single consumer may use several fuses. Introduction ■...
  • Page 171 Fuse assignment in the dash panel Power consumer Power consumer Telephone preinstallation S-contact Petrol engine: AKF valve, Diesel engine: Control flap START-STOP, air-conditioning system Injection, coolant pump Instrument cluster, headlamp beam adjustment Fuel pump, ignition, Cruise control system, operation of PTC relay Control unit for ABS, button for START STOP Lambda probe Petrol engine: Speed regulating system...

  • Page 172: Bulbs

    Power consumer Fuses in the engine compartment Glow plugs, radiator fan Electro-hydraulic power steering ABS or TCS or ESC Radiator fan Automatic gearbox ABS or TCS or ESC Central control unit Electrical auxiliary heating system Note Fig. 152 Vehicle battery: Distribution board cover. Fuses 1-7 are replaced by a specialist garage.
  • Page 173 WARNING Headlights Always read and observe the warnings before completing any work in the ■ engine compartment » page 138. Accidents can be caused if the road in front of the vehicle is not suffi- ■ ciently illuminated and the vehicle cannot or can only be seen with difficul- ty by other road users.
  • Page 174 ›  Remove the connector from the bulb, unlock the securing clip and remove Read and observe on page 171 first. the bulb » Fig. 155. › › Remove the rubber cover » Fig. 154 on page 171. Insert a new light bulb in such a way that the fixing lugs of the bulb socket fit ›...
  • Page 175 Foglights and daytime running lights Fabia Scout, Fabia RS foglights Fig. 158 Front bumper: Protective grille/removing the fog light Fig. 159 Front bumper: Fabia Scout/Fabia RS  Read and observe on page 171 first. Bulb location » Fig. 158. - Bulb for daylight driving light - Light bulb for fog lights Removing the cap ›...
  • Page 176 › Turn the bulb holder and bulb in the direction of the arrow to the stop and Rear light remove. › Replace the bulb, insert the bulb holder and new bulb and turn in the oppo- site direction to that of the arrow to the stop. ›...
  • Page 177 › To refit the rear light assembly, first insert screw into the opening in the bodywork » Fig. 162. › Carefully press the tail light assembly into the bodywork so that the bolts latch with the mounts in the body. ›...

  • Page 178: Technical Data

    The vehicle data sticker contains the following data. Technical data Vehicle identification number (VIN) Technical data Vehicle type Gearbox code/paint number/interior equipment/engine output/engine Vehicle data code Partial vehicle description  Introduction Type plate This chapter contains information on the following subjects: The type plate »...
  • Page 179 The operating weight also contains the weight of the driver (75 kg), the weight Note of the operating fluids, the tool kit, and a fuel tank filled to 90 % capacity. The fuel consumption and emission levels given on the Škoda websites or in ■...
  • Page 180 Dimensions Vehicle dimensions (mm) FABIA ESTATE FABIA FABIA SCOUT FABIA RS ESTATE ESTATE SCOUT ESTATE RS GreenLine GreenLine Length 4000 4000 4032 4029 4247 4247 4275 4276 Width 1642 1642 1658 1642 1642 1642 1658 1642 Width including exterior 1886 1886 1886 1886...
  • Page 181 Vehicle-specific details according to engine type The values specified have been determined in accordance with rules and under conditions set out by legal or technical requirements for determining operational and technical data for motor vehicles. 1.2 ltr./44 kW engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 44/5200...
  • Page 182 1.2 ltr./63 kW TSI engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 63/4800 160/1500-3500 4/1197 Performance and Weights FABIA ESTATE Top speed (km/h) Acceleration 0-100 km/h (s) 11.7 11.8 Operating weight (in kg) 1116 1136 Permissible trailer load, braked (kg) 1100...
  • Page 183 1.4 ltr./63 kW engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 63/5000 132/3800 4/1390 Performance and Weights FABIA ESTATE Top speed (km/h) Acceleration 0-100 km/h (s) 12.2 12.3 Operating weight (in kg) 1104 1124 Permissible trailer load, braked (kg) 1000 /1200...
  • Page 184 1.4 ltr./132 kW TSI engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 132/6200 250/2000-4500 4/1390 Performance and Weights FABIA RS ESTATE RS Top speed (km/h) Acceleration 0-100 km/h (s) Operating weight (in kg) 1318 1313 1.2 ltr./55 kW TDI CR DPF engine Output (kW at rpm)
  • Page 185 1.6 ltr./55 kW TDI CR engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 55/4000 195/1500-2000 4/1598 Performance and Weights FABIA ESTATE Top speed (km/h) Acceleration 0-100 km/h (s) 14.1 14.2 Operating weight (in kg) 1204 1224 Permissible trailer load, braked (kg)
  • Page 186 1.6 ltr./77 kW TDI CR engine Output (kW at rpm) Maximum torque (Nm at rpm) Number of cylinders/displacement (cm 77/4400 250/1500-2500 4/1598 Performance and Weights FABIA ESTATE Top speed (km/h) Acceleration 0-100 km/h (s) 10.9 11.0 Operating weight (in kg) 1219 1239 Permissible trailer load, braked (kg)

  • Page 187: Index

    Air conditioning system Index Air outlets Back-up wheel Climatronic Ball head Manual air conditioning system Check fitting Abroad Air outlets Fitting Driving abroad Alarm Ready position Unleaded petrol Anti-theft alarm system Removing Operation Belts warning light Trailer Belt tensioners Accessories Antilock Braking System Bicycle carrier Adjusting...
  • Page 188 Bulbs Changing a wheel Climatronic Changing Preparation Automatic mode In the rear light Removing and fitting a wheel Control elements Subsequent steps Controlling the blower Button in the driver's door Defrosting windscreen Electrical power windows Charging a vehicle battery Recirculated air mode Check Setting the temperature Fit ball head properly...
  • Page 189 De-icing rear window Economical driving Starting the engine Anticipation in driving Switching off the engine Deactivating airbags Ballast Engine compartment Decorative films Driving at full throttle Brake fluid Delayed locking of the boot lid Idling Coolant see boot lid Regular maintenance Overview Diesel Saving energy...
  • Page 190 Refuelling Recirculated air mode Hazard warning light system Unleaded petrol Seats Low beam lights Main beam lights fuel consumption Heating and air conditioning Parking lights 56, 59 Fuel consumption Hill hold control Rear fog light Fuses Horn Replacing bulbs Assignment Switching on and off Changing Tourist lights...
  • Page 191 Maximum speed Remote control key Replacing the battery Paintwork Repairs and technical alterations Mirror See Caring for paintwork Exterior mirrors Replacing Parking Manually dimmed rear-view mirror Vehicle battery Parking aid Vanity Windscreen wiper blades Parking lights Mobile phone Replenishing Part replacement Connecting to the hands-free system Coolant Passive safety...
  • Page 192 Seat Sliding/tilting sunroof Taking care of the vehicle Adjusting Closing Natural leather Seat belts Seat belt Snow chains warning light Taking care of your vehicle Spare wheel Automatic car wash system Seat belts Speedometer Chrome parts Belt tensioners Speed symbol Cleaning the wheels Cleaning see Wheels...
  • Page 193 Transport Washing Boot Automatic car wash system Variable loading floor Roof rack system by hand Dividing the luggage compartment Chrome parts Transporting children safely Removing and refitting High-pressure cleaner Turn signals Vehicle battery Water Two-way radio systems Automatic load deactivation Driving through Tyre load-bearing capacity Charging...
  • Page 194 Windscreen washer fluid Checking Replenishing Warning light Winter Windscreen washer system Windscreen wash system Windscreen washer Windscreen wiper Operate Replacing the windscreen wiper blades Windscreen wipers Cleaning the windscreen wiper blades Windscreen washer fluid Winter Deicing windows Winter operation Snow chains Winter tyres See Wheels Winter use...
  • Page 195 ŠKODA AUTO a.s. pursues a policy of constant product and model develop- Reprinting, reproduction, translation, or any other use, either in whole or in ment. We trust that you will understand that changes to models in terms of part, is not permitted without the written consent of ŠKODA AUTO a.s.. shape, equipment and engineering, may be introduced at any time.
  • Page 197 www.skoda-auto.com You also can do something for the environment! The fuel consumption of your ŠKODA and the related pollutant emissions are determined crucially on how you drive. The noise and the wear of the vehicle depend on the way how you deal with your vehicle.

This manual is also suitable for:

Fabia

Table of Contents
