"NO CD": The compact disc player is
empty. Insert a disc.
If the disc is not playing correctly, for any
other reason, try a known good disc.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
H/M (Hours/minutes adjustment)
These buttons are used to adjust the
clock time. For details, see "Clock" on
page 154 in Section 1−10.
INFO (Information)
When an RDS radio station transmits a
text message, "INFO" will be displayed. At
this time, push the "INFO" button to view
the text message. If the whole message
does not appear on the display, part of
the message will appear every three sec-
onds until the message is completed. To
scroll through the message at your own
speed, push the "INFO" button consecu-
tively. When the whole message has been
displayed,
The message display will be canceled if
any button that affects the display is
pushed. To view the message again, push
the "INFO" button again.
The RDS audio system saves a message
until a new message is received.
If the text message is not available when
you push "INFO" button, "NO INFO" will
appear on the display.
LOAD
This button is used to load the compact
discs in the compact disc player which is
integrated with the radio. This compact
disc player can store up to 6 discs.
The key must be in the "ACC" or "ON"
position for the load function.
Loading one compact disc only—
To load one compact disc only, quickly
push and release the button. If you hold
the button too long, the mechanism will
change to the mode for loading multiple
compact discs. After pushing the button,
wait for the load/eject status light to turn
green then, insert a compact disc. After
the disc is loaded, the shutter of the slot
will close.
If no compact disc is inserted, the shutter
the message will disappear. will close after 8 seconds.
If you push this button when the player is
full, three beeps will sound.
'04 MATRIX_U (L/O 0307)
Loading multiple compact discs—
To load multiple compact discs, push and
hold the button until you hear two beeps.
When the load/eject status
green, insert a disc. Wait for the load/
eject status light to turn green before in-
serting the next disc.
If no compact disc is inserted, the shutter
will close after 8 seconds.
If you push this button when the player is
full, three beeps will sound.
PWR/VOL (Power/Volume)
Push "PWR/VOL" to turn the audio system
on and off. Turn "PWR/VOL" to adjust the
volume.
P·TYPE (Program Types)
To turn on the PTY mode, push the
"P·TYPE" button while receiving an RDS
station. The current program type will ap-
pear on the display.
You can select one of the following pro-
grams by turning the tune (P·TYPE) knob
while the PTY mode is on.
D
Any Type
D
News
D
Inform (Information)
D
Sports
2004 MATRIX from Oct. '03 Prod. (OM12861U)
light turns
133
