Installation & Operation Guide
Introduction
4.500
KMD-1101/1121 NetSensor
This section provides a brief overview of the KMD-1101/1121 NetSensor. Review
this material before you attempt to install the controller.
Illustration 1 shows the major components and their locations.
2.750
ROOMû û F F
ROOM
SETPOINT
SETPOINT
O.A.
O.A.û û F F
OVERRIDE
OVERRIDE
TIME
TIME
1 1
0 0
Illustration 1. NetSensor Component1
LED Display
RJ–12 Connector
Main Control
Buttons
PC Port
Flip Door
0.875
NOTE: Actual label text will depend on
Secondary Button Group
(Under Flip Door)
application and labels used.
3.280 (83.3)
1
893-019-01F
