Morsø 6800
DK
Opstillings- og betjeningsvejledning
UK
Instructions for installation and use
Morsø 6840, 6841, 6843, 6848, 6870, 6890 & 6891
6843
6848
www.morsoe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6840 and is the answer not in the manual?

Questions and answers

Summary of Contents for Morsø 6840

  • Page 1 Morsø 6800 Opstillings- og betjeningsvejledning Instructions for installation and use Morsø 6840, 6841, 6843, 6848, 6870, 6890 & 6891 6843 6848 www.morsoe.com...
  • Page 2: Table Of Contents

    INDhOlD · CONTENTS Opstilling af Deres morsø ovn ......5 Opstillings- og betjeningsvejledning Fyringsteknik/Brugen af Deres ovn ....10 6800-serien Regelmæssig vedligeholdelse af ovnen... . 14 Tekniske data..
  • Page 3: Opstilling Af Deres Morsø Ovn

    Til lykke med Deres nye Morsø ovn! 1.0 Opstilling af Deres Morsø Ovn Morsø, som er den største udbyder på det danske 1.1 Udpakning af ovnen marked, har siden 1853 fremstillet brændeovne af Morsø 6800 ovnene vejer mellem 110 og 125 kg. For at undgå skamferinger i forbindelse med den højeste kvalitet.
  • Page 4: Skorstenen

    Af hensyn til varmecirkulation, rengøring og evt. indvendig rensning af ovn, anbefales afstand 1.6 Rørtilslutning til murværk at være 10-15 cm. Et lag tapet bliver normalt, når det er påsat murværk, betragtet Den øverste støbte topplade løftes af ovnen. som ikke-brændbart materiale. Bemærk den runde støbte dækplade i toppladen skal forblive fastmonteret, hvis ovnen skal monteres med røgrør bagud og skrues af den øverste topplade, hvis røgrøret ønskes monte- På...
  • Page 5: Tilslutning Til Stålskorsten

    1.8 Tilslutning til stålskorsten Er der tale om opstilling, hvor skorstenen føres direkte op gennem loftet, skal man følge de Trækforhold nationale og lokale bestemmelser m.h.t. skorstenens afstand til brandbart loft. Skorstenen Skorstenens træk skabes på grund af forskellen mellem den høje temperatur i skor- tætnes ved røgtuden med vedlagte glassnor.
  • Page 6: Fyringsteknik/Brugen Af Deres Ovn

    2.1 Optænding og fyringsintervaller 2.0 Fyringsteknik/Brugen af Deres ovn Under optænding er der behov for en stor luftmængde. Startes der op med en helt kold ovn, kan man med fordel lade døren stå på klem de første minutter og åbne forbræn- dingslufttilførsel på...
  • Page 7 5. Normal påfyring bør ske, mens der endnu er gløder tilbage. Normalt skal ovndøren altid åbnes roligt de første 2-3 centimeter, og man skal vente til tryk- Gløderne fordeles i bunden, dog flest foran i ovnen. ket er udlignet inden døren åbnes helt. På denne måde undgås eventuelle røggener specielt i forbindelse med dårlige trækforhold.
  • Page 8: Regelmæssig Vedligeholdelse Af Ovnen

    Pakninger 3.0 Regelmæssig vedligeholdelse af ovnen Med tiden vil pakningerne i lågerne blive slidte og bør, for at undgå løbsk forbrænding, udskif- tes efter behov. Brug Morsø pakningssæt 3.1. Udvendig vedligeholdelse Bemærk: Normale sliddele er ikke omfattet af Morsøs udvidede garantiordning. Ovnens støbte overflade er malet med en varmebestandig senotherm maling.
  • Page 9: Tekniske Data

    2. Første sidesten vippes og tages ud. 6. Man skal sikre sig, at røgledeplader og sten igen er korrekt monteret inden optænding efter en rensning. 3. Anden sidesten vippes og tages ud. Vedligeholdelsesdele til 6800-serien Beskrivelse Produktnr. Mellembund 34611000 Røgledeplade øverst 79610600 Røgledeplade nederst 79610500...
  • Page 10 Instructions for installation and use 6800 series 6843 6848 EN 13240 / NS 3058-3059 DEFRA approved for use in United Kingdom smoke control areas MORSØ JERNSTØBERI A/S . DK-7900 NYKØBING MORS E-Mail: stoves@morsoe.com · Website: www.morsoe.com...
  • Page 11: Installing Your Morsø Stove

    Enjoy your new Morsø stove! 1.0 Installing your Morsø stove Morsø, the biggest stove company in the Danish market, has been making wood-burning stoves 1.1 Unpacking the stove of the highest quality since 1853. Just follow the The Morsø 6800 stoves weigh between 110 and 125 kg. In order to avoid damage when unpack- ing and assembling the stove, we recommend that this job be undertaken by 2 people.
  • Page 12 We recommend that the stove be installed at least 10-15 cm from masonry in order to allow 1.6 Connecting the flue pipe heat to circulate and to facilitate the cleaning of the inside and outside of the stove. A layer of lift the upper cast iron top plate off the stove.
  • Page 13 1.8 Connecting to a steel chimney If your installation involves taking the chimney straight up and through the ceiling, you must Draught comply with National, Local Building Regulations or flue manufacturers instructions concern- The draught in the chimney is the result of the difference between the high ing clearances to combustible materials such as walls, floor joists and ceilings.
  • Page 14: Firing/Using The Stove

    2.1 lighting instructions and fuelling intervals 2.0 Firing/using the stove A lot of air is needed when lighting the stove. If you are starting with a cold stove, the door should be left ajar for the first few minutes and the combustion air supply opened to maximum.
  • Page 15 5. Re-stoking should normally be carried out while embers still The stove door should normally be opened gently the first 2-3 cm, then you should wait un- remain. Distribute the embers in the bottom, ensuring that til the pressure has equalised before opening the door all the way. This technique will prevent most of them are at the front of the stove.
  • Page 16: Routine Stove Maintenance

    3.0 Routine stove maintenance Reasons for overly rapid wear of internal parts - Stove fired too vigorously 3.1 External maintenance - Use of very dry wood (wood from old furniture). - Too much soot on top of the baffles (please see the section on Cleaning). The cast surface of the stove is painted with heat-resistant Senotherm paint.
  • Page 17 1. Raise the bottom baffle slightly, and hold it in that positi- 5. Lift the upper baffle out of its holder and tilt it out. on. This loosens the brick panels in the side. 2. Tilt one of the side brick panels and remove it. 6.
  • Page 18: Hetas Amendments

    sary to line the chimney then a flue liner suitable for solid fuel must be used in accordance 4.0 hETAS amendments with Building Regulations Approved Document J. health and safety precautions Any existing chimney must be clear of obstruction and have been swept clean immediately be- Special care must be taken when installing the stove such that the requirements of the Health fore installation of the stove.
  • Page 19 a) Open doors and windows to ventilate room. b) Let the fire out or eject and safely dispose of fuel from the appliance. c) Check for flue or chimney blockage, and clean if required. Do not attempt to relight the fire until the cause of the fume emission has been identified and corrected.
