PTZ Camera

This shortcut opens the PTZ menu. PTZ stands for
Pan, Tilt, Zoom cameras (not included). This menu
option only controls compatible PTZ cameras that
are properly setup in the device management
section of the menu.

The PTZ camera controls

Directional Keys: Moves the camera in the
direction of the arrow.
Zoom: The + zooms in and the – zooms out.
Focus: The + focuses the picture and the - removes
the focus. This is useful if an object is either close
range or long range and is being displayed blurry.
Iris: The + lets in more light and the – removes light
from the image. This is useful for varying lighting
situations as well as correcting
backlight issues.

Start Cruise

This option prompts the PTZ cruise to start (if you have set up the PTZ cruise). Click it again to stop the
PTZ cruise. To Set Cruise follow these steps:
1. Right click the mouse and select
2. Select the channel that the PTZ camera is
connected to. (The PTZ camera must already
be configured).
3. Click on the TIME text field and input the time
(in seconds) for how long you would like the PTZ
camera to stay at that position.
4. Use the directional buttons to adjust the camera
to the areas you would like the PTZ camera to
view in cruise mode.
5. Press the SET button at each desired position.
Speed: Allows you to adjust the speed that the
camera will move.
Cruise Setup: Allows you to set preset positions for
the PTZ to follow. The PTZ camera will cruise through
your set positions and times. Not all PTZ cameras
have this function.
. 6. To review your set points, select the NO. text field
and input the number you would like to view.
7. Click SAVE and then EXIT.
8. To erase preset cruise points select the
CLEAR button.
9. To start the PTZ cruise, open the shortcut menu
and select START CRUISE. To stop the PTZ cruise,
open the shortcut menu and select STOP CRUISE.
