Loading Receipt Paper; Transaction Processing Options - First Data XAC Quick Reference Manual

5 Quick reference guide

Loading receipt paper

Transaction processing options

1. Open the printer cover by gently pulling the printer
cover's latch, then lift the cover away from the printer.
2. Load a receipt roll into the printer.
3. Ensure the roll will feed out of the terminal so that the
print side of the paper faces the operator.
4. Close the cover by pressing down evenly on both side
tabs, or by pressing on the centre of the printer cover.
5. Use the serrated bar to tear off any excess paper.
Smart Card Reader
Insert the card into the card reader with the gold chip
facing upward, as shown in the image.
Magnetic Card Reader
Swipe the card with the magnetic stripe facing inwards.
Contactless Card Reader
Place the contactless card near the card reader antenna
during the transaction.
