AquaCraft Cajun Commander Instruction Manual page 3

Weight: 107 G ± 10 G
Plugs: 4 mm
50 amp Brushless air cooled, water proof, motor controller
w/ Star connector
Details
Amps: 50 amp continuous
Max Amps: 65 A 10 sec
Voltage range: 9V -12.6 V
BEC: 5V 2 A
Motor Connectors: 4 mm bullet (3)
Battery Connector: Star Connector
Stutter Voltage: 9.7 volts
LVC: 9 volts
Wire Gauge: #14
Max Output Power: 500 watts
On-Resistance: 0.0015 ohms
Operating Freq: 8 kHz PWM, 16 MHz MCU
Timing Angle: Auto
STARTUP AND OPERATION
Charge your battery using the recommended charge method
that came with the charger and battery you purchased to
operate the model.
Install four AA batteries into the bottom of the transmitter.
(Page 2 of your transmitter manual)
Turn the transmitter on,
confi rmation chime, BEEP BEEP BEEP. Your boat is ready
making sure the power
to go.
light is glowing.
Let's review the arming procedure:
Rotate the lock and lift
the front edge of the
NOTE: You need to repeat this simple arming procedure each
seat compartment.
time you unplug the power battery and operate the boat.
Slip the radio box
cover forward and up.
Then, place it to the
side.
Install two AA batteries
into the battery holder
for the LED lights.
the twin rudders correspond in the proper direction. Carefully
squeeze the throttle trigger making sure your hands and
fi ngers are a safe distance from the propeller to check motor
operation.
● Plug a charged battery into the boat, bee da beep--
-BEEP!
● Fully squeeze the trigger and hold, BEEP, BEEP!
● Relax the trigger back to neutral, BEEP, BEEP, BEEP!
● The boat is now armed and ready to run.
To turn the lights on
and off, use the switch
located on the side of
the radio box.
Remove and place
the hook and loop
to the bottom of the
battery pack. Place the
charged battery into
the open compartment
and plug the battery
into the boat.
You will hear a jingle;
bee da beep- - -BEEP!
The boat is now ready
to arm. To arm the
boat, fully squeeze
the throttle trigger and
hold until you hear a
chime – BEEP BEEP!
Relax the throttle
trigger back to neutral
and you will hear a
Re-install the radio
box cover by aligning
the wires and sliding
the attachment pegs
into the holes. Turn the
lock to secure the lid.
Check the steering
direction to make
sure when the wheel
is turned right or left
3
