Sharp R-9570 Service Manual page 36

R-9570
REF. NO.
PART NO.
DESCRIPTION
Q'TY ' CODE
4-28B
L A N G T 0 4 1 7 W R W 0 Lower sash mounting plate
1 AG
4-28C
P S L D M 0 3 6 4 W R E 0
Ferrite (same as 4-27C)
1 AH
4-29
H D E C Q A 0 3 4 W R F 0 Left sash
1 AG
4-30
L A N G Q 0 4 3 4 W R W 0 AH sensor mounting plate
1 AD
4-31
P C 0 V P 0 3 5 3 W R W 0 AH sensor cover
1 AD
DOOR PARTS
5
C D 0 R F A 0 8 1 W R K 0 Complete door assembly
1 BN
MISCELLANEOUS
6- 1 QW-QZO 164WREO
HighvoltagewireA
1 AE
6- 2
QW-Q Z 0 1 3 2WR E 0
High voltage wire B
1
AE
6- 3 Q W- V Z A 0 0 9 W R E 0
Earth wire '(for AH sensor)
1 AB
6- 4
F W- V Z A 1 6 2 W R E 0 Main wire harness
1
AU
6- 5 L B N D K 0 0 1 2 Y B E 0
Wire holder (WH-1, 'IL")
1
AA
6- 6 TCAUHO 11 4WRR0
Cautionlabel
1 AC
6- 7 TCADC0220WRRO
Cookbook
1
AY
6- 8 T i N S E A 1 5 3 W R R 0 Operation manual 1 AK
6- 9 TSPCNA279WRRO
Nameplate 1 AC
SCREWS, NUTS AND WASHERS
7- 1 L X - B Z 0 1 4 1 W R E 0
Screw; monitor switch lever mtg. 1 AA
7- 2
L X - B Z 0 1 8 6 W R E 0 Screw; Capacitor holder, rectifier,
turntable
motor cover mtg. 5
AA
7- 3 X 0 T S C 4 0 P 1 2 0 0 0 Screw; outer case cabinet
mtg.
7
AA
7- 4 L X - E Z 0 0 4 6 W R E 0 Screw; outer case cabinet
mtg.
2 AA
7- 5 L X -C Z 0 0 4 7 W R E 0 Screw; cabinet base (A) and lower sash assembly
4 AA
7- 6 L X-C Z 0 0 5 2 W R E 0 Screw; latch
upper hook and lower latch hook mtg.
2 AA
7- 7 X B B U W 3 0 P 0 8 0 ,O 0 Screw;
lamp socket mounting plate mtg.
2 AA
7- 8 X F P S D 3 0 P 1 0 0 0 0 Screw; fuse holder mtg.
1 AA
7- 9 X B P S D 4 0 P 2 5 0 0 0
Screw;
fan motor mtg.
2 AA
7-l 0 X B P S D 4 0 P 2 0 b 0 0 Screw;
cord anchorage mtg.
1 AA
7-1 1 X B P S D 5 0 P 1 0 K 0 0 Screw;
magnetron mtg.
4 AA
7-l 2 X B P S D 6 0 P 1 4 K S 0 Screw; transformer mtg.
power
2 AA
7-l 3 X B T U
W
4 0 P 0 8 0 0 0 Screw; turntable motor assembly
mtg.
3 AA
7-l 4 X F P S D 4 0 P 0 8 0 0 0 Screw; turntable motor mtg.
2 AA
7-15 X C P S D 3 0 P 0 8 0 0 0
Screw; oven lamp socket, left sash assembly
mtg.
4 AA
7-16 L X -C Z 0 0 7 4 W R E 0 Screw; oven hinge and lower
upper oven hinge mtg.
5 AA
7-l 7 X C T D S 4 0 P 1 2 0 0 0 Screw; cabinet base (B), upper sash assembly
and lower
11
AA
sash assembly, rear cabinet mtg.
7-18 X WV S D 3 5 - 0 4 0 0 0 Washer; control unit mtg.
2 AA
7-l 9 L X-N Z 0 0 7 0 W R E
0
Nut; earthing (mains supply cord) mtg.
1 AA
&I-I- -Fl I.
. . .
Iuole: I ne voltage supplred to the parts marked " %" is greater
than 250V.
