- Page 1 Compaq NC6770 PCI-X Gigabit Server Adapter User Guide Part Number 252460-00B June 2007 (Second Edition) Product Version: Version 1.0 This user guide provides installation and reference information about the Compaq NC6770 PCI-X Gigabit Server Adapter.
- Page 2 Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.
- Page 3 Regulatory Compliance Notices European Union Notice ..........................A-1 Appendix B Electrostatic Discharge Overview..............................B-1 Grounding Methods ..........................B-1 Appendix C Specifications NC6770 PCI-X Gigabit Server Adapter Specifications................C-1 Fiber Cable Specifications ........................C-2 Compaq NC6770 PCI-X Gigabit Server Adapter User Guide...
- Page 5 About This Guide This user guide can be used for reference when servicing Compaq NC6770 PCI-X Gigabit Server Adapters. WARNING: To reduce the risk of personal injury from electric shock and hazardous energy levels, only authorized service technicians should attempt to repair this equipment.
- Page 6 Integrated Management Log The server includes an integrated, nonvolatile management log that contains fault and management information. The contents of the Integrated Management Log (IML) can be viewed with Compaq Insight Manager. Compaq NC6770 PCI-X Gigabit Server Adapter User Guide...
- Page 7 For Compaq technical support: • In the United States and Canada, call 1-800-OK COMPAQ. • For Compaq technical support phone numbers outside the United States and Canada, visit the Compaq website: www.compaq.com Text Conventions This document uses the following conventions: •...
- Page 8 64-bit/133MHz-network adapter for fiber-optic environments. It is compatible with 64/100, 64/66, 64/33, and 32/33 PCI bus architectures. The NC6770 PCI-X Gigabit Server Adapter has an SC connector and LED indicators for link and activity. The NC6770 PCI-X Gigabit Server Adapter is a supported option for selected Compaq ProLiant™ servers...
- Page 9 Introduction Hardware Overview The NC6770 PCI-X Gigabit Server Adapter has a single, fiber SX port and LED indicators for link and activity. Fiber SX Port LINK Link LED Activity LED Figure 1-1: Fiber SX port and LED locations LED Indicators The NC6770 PCI-X Gigabit Server Adapter has two diagnostic LED indicators for the fiber SX port.
- Page 10 NOTE: Before removing the cover of your server, refer to the Compaq documentation for the proper methods for installing a PCI card and avoiding electric shock hazards.
- Page 11 Installing the Adapter Installing the Adapter in a Server Refer to the Compaq ProLiant server documentation for additional information on how to safely install an I/O card in your server. 1. If the server is not PCI Hot Plug compliant, power down the server and unplug the power cord.
- Page 12 Installing the Adapter Connecting the Network Cable The NC6770 PCI-X Gigabit Server Adapter has one SC fiber port. This port supports 1000Base-SX multimode fiber cable with a maximum cable length dependent on the fiber type, mode, and cable size. See Appendix C for maximum cable lengths.
- Page 13 • EN 55022 (CISPR 22)—Electromagnetic Interference • EN55024 (IEC61000-4-2, 3, 4, 5, 6, 8, 11)—Electromagnetic Immunity • EN61000-3-2 (IEC61000-3-2)—Power Line Harmonics • EN61000-3-3 (IEC61000-3-3)—Power Line Flicker • EN 60950 (IEC 60950)—Product Safety Compaq NC6770 PCI-X Gigabit Server Adapter User Guide...
- Page 14 • Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, have a Compaq authorized reseller install the part. NOTE: For more information on static electricity or assistance with product installation, contact your Compaq authorized reseller.
- Page 15 Specifications NC6770 PCI-X Gigabit Server Adapter Specifications Table C-1: NC6770 PCI-X Gigabit Server Adapter Specifications Specification Description Network Controller Chipset Broadcom 5101 (h) Data Transfer Method 64-bit/133MHZ, compatible with 64/100, 64/66, 64/33, and 32/33 PCI bus architectures Standards Supported IEEE 802.3z, 802.3ad (static configuration mode only), 802.1p...
- Page 16 Specifications Fiber Cable Specifications The NC6770 uses 1000Base-SX fiber cable to connect to the network. Table C-2: Fiber Cable Maximum Distances for 1000Base-SX Mode Size Max Distance 62.5/125 μm Multimode 220 meters 50/125 μm Multimode 550 meters Compaq NC6770 PCI-X Gigabit Server Adapter User Guide...
