Summary of Contents for Jazz HDV149
-
Page 2: Table Of Contents
Contents Contents………………………………………………………………………………………………………...1 FCC statement Function Description…………………………………………………………………...2 Notice for use………………………………………………………………………………………....3 System requirements………………………………………………………………………………………...4 Start to use………………………………………………………………………………………....5 1. Appearance and Buttons………………………………………………………………………5 2. Basic operation…………………………………………………………………………………7 Install battery ………………………………………………………………………… 7 Use SD/MMC/SDHC card …………………………………………………………… 7 Change mode………………………………………………………………………… 8 Video recording…………………………………………………………………… 8 Still photo taking……………………………………………………………………… 9 Playback videos or photos…………………………………………………………10 TV output …………………………………..……………………………………..…10 Delete files ………………………………………………………………………..…11... -
Page 3: Fcc Statement Function Description
FCC statement FCC STATEMENT ’ ’... -
Page 4: Notice For Use
Notice for use General: 1. Never open or disassemble the housing of recorder to avoid damage and failure to operate. 2. Humidity, excessive heat and dropping may also damage the recorder. This device is precision instrument and must be treated with utmost care as with all electronic devices. Memory and storage: 1. -
Page 5: System Requirements
5. Remove the battery and store recorder in dry place if you plan not using it for extended time. 6. Product is designed to operate in normal environment with temperatures between 32F – 104F (0 to 40C) Avoid leaving the recorder exposed to extreme temperatures, such as in the car parked under strong sunshine or outside during sub-zero weather. -
Page 6: Start To Use
Start to use 1. Appearance and Buttons... - Page 7 Cover SD Card Slot...
-
Page 8: Basic Operation
2. Basic operation 2.1 Installing the battery Press / slide down the Battery Cover and insert supplied Li-On battery. Note battery contacts and correct polarity of terminals. Close the Battery Cover. Charging the Battery 1. Power off the recorder. 2. Connect the recorder to the computer USB port with USB cable to charge the battery. 3. -
Page 9: Change Mode
you may remove the card from the camera. Note that the SD Card has a tiny LOCK switch on the side. Set the switch to un-LOCK position in order to save recorded videos & still pictures on inserted SD Card. 2.3. -
Page 10: Still Photo Taking
Video Resolution from available options: QVGA (320x240); D1(720x480); HD(1280X720). Note that D1 resolution (720x480)) is the default mode setting. - Press the MODE Key and select Video Recording mode. - Press the Shutter key to START recording a video clip; press the Shutter key again to STOP recording. -
Page 11: Playback Videos Or Photos
Note: l If the memory is full or the SD card is LOCK-ed, the recorder will not take any further recording. Turn the camera OFF and un-LOCK or replace the card to continue recording. 2.6 Playback - Press the Playback Key to enter playback mode and LCD display will show last recorded image or file. -
Page 12: Delete Files
- Use supplied AV cable and connect device to TV set. (make sure recorder is turned OFF) - Insert the yellow jack into the VIDEO IN of your TV and insert red or white jack into the AUDIO IN port of your TV. - Insert the single jack (of the AV cable) into the video recorder TV OUT port and then activate the recorder. -
Page 13: Connect To Pc
2.9 Connecting camera with PC and t Slide the USB Switch DOWN to extend the USB connector urn the recorder ON. Use a fingernail if necessary to release and move the adjacent USB protective cover. Insert the recorder USB connector into computer USB port or use supplied USB extension cable and to connect to computer USB port. -
Page 14: Download Files From Camera To Pc
2.10 Downloading files to PC When recorder is connected to the computer, select "My Computer” and open the "Removable Disk." Select and open the Removable Disc; The video and images are stored inside the \DCIM\ 100MEDIA folder. Open this folder. Choose the desired video or photo file and copy (or drag) file into selected location / target folder in your computer. -
Page 15: Introduction Interface For Software Installation
If the CD driver does not start automatically (depends on your computer configuration) go to My Computer, then select the CD Drive and click / open autorun.exe program. Instalingl MediaImpression: Click “Install MediaImpression” button and complete the installation as per indicated steps... -
Page 17: Mediaimpression Installation And Use
Restart the computer when prompted. Run and using the MediaImpression : icon on the desktop or follow “Start → Programs” to open: Double click the MediaImpression... - Page 18 After starting MediaImpression, click the “Import” to import the media. Choose the video camera storage and choose the output location.
- Page 19 Choose require file and click the import, selected file will be stored in the output location. Click “Go to start page” to return the main screen, click the “Video” or “All media” to use the “YouTube” function.
- Page 20 Choose file and click the “upload to YouTube. Enter your username and password to login the YouTube and execute upload.
-
Page 21: Product Specifications
Product specifications: Video Resolution QVGA(320x240), D1(720x480),HD(1280X720) 1.3 Mega Pixels (1280x1024); 3.1 Mega Pixels (2048x1536); Still Photo Resolution 5 Mega Pixels (2592x1944) Lens F3.0, f=5.7mm Focus Range 4ft (1.2M) ~ infinity Digital Zoom 4× Shutter Electronic LCD Display 1.8 inch Display Function Mode Record video, Record still photo, Playback White Balance &...
