1
3 D H O B B Y S H O P . C O M
Assembly Manual
For the following aircraft -
Velox VR-1 48" and Edge 540 47"
Thank you for purchasing this 3DHobbyShop ARF RC aircraft. If you have any issues, questions,
concerns or problems during assembly, please contact our tech department at:
Info@3DHobbyShop.com
or 1-830-990-6978 10am-5pm Central M-F
We highly recommend
www.RCGroups.com
as a good source for RC tips, tricks, and information.
SAFETY in Assembly
During assembly of this aircraft, you will be asked to use sharp knives and hobby adhesives. Please
follow all safety procedures recommended by the manufacturers of the products you use, and always
follow these important guidelines:
ALWAYS protect your eyes when working with adhesives, knives, or tools, especially power tools. Safety
glasses are the best way to protect your eyes.
ALWAYS protect your body, especially your hands and fingers when using adhesives, knives, or tools,
especially power tools. Do not cut toward exposed skin with hobby knives. Do not place hobby knives on
tables or benches where they can roll off or be knocked off.
ALWAYS have a first-aid kit handy when working with adhesives, knives, or tools, especially power tools.
ALWAYS keep hobby equipment and supplies out of the reach of children.
IMPORTANT NOTE – We strive to provide the absolute best-quality ARF aircraft on the planet. However,
the ultimate success or failure of this aircraft is dependent upon proper assembly by you. If you have
questions about an assembly step, please contact us, or read the assembly thread for your airplane on
RCGroups.com before proceeding. It is always better to slow down and be sure of your assembly than to
rush through it and make a mistake which can cause a crash.
SAFETY in Flying
SAFETY NOTICE: This is NOT a toy! It is a very high-performance RC airplane capable of high speeds
and extreme maneuvers. It should only be operated by a competent pilot in a safe area with proper
supervision.
ONLY fly your aircraft in a safe, open area, away from spectators and vehicles–and where it is legal to fly.
NEVER fly over an unsafe area, such as a road or street.
NEVER fly near overhead power or utility lines. If your airplane ever becomes stuck in a line or a tree DO
NOT attempt to retrieve it yourself. Contact the authorities for assistance in retrieving your aircraft.
Power lines are DANGEROUS and falls from ladders and trees CAN KILL!
Never fly too close to yourself or spectators. Spinning propellers are DANGEROUS!
Never run your motor inside a house or building with the propeller attached – Remove the prop for safety.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Velox VR-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3D Hobby Shop Velox VR-1

Summary of Contents for 3D Hobby Shop Velox VR-1

  • Page 1 Assembly Manual For the following aircraft - Velox VR-1 48” and Edge 540 47” Thank you for purchasing this 3DHobbyShop ARF RC aircraft. If you have any issues, questions, concerns or problems during assembly, please contact our tech department at: Info@3DHobbyShop.com...

  • Page 2: Required Items

    Always fly within your control. Always follow manufacturer’s instructions for your radio system. Always obtain proper insurance before flying – contact the AMA at www.modelaircraft.org REQUIRED ITEMS CA Glue – Thin and Thick Hobby Knife Small Phillips Screwdriver Set Metric Allen Wrenches Scissors Needle-nose Pliers Regular Pliers or a small adjustable wrench...
  • Page 3 Covering Material – Your airplane is covered in genuine Oracover covering material. If you ever need to purchase additional covering, Ultracote brand covering is an exact match. Removing covering – Use a new sharp blade in your hobby knife when removing covering over the access holes in the airplane.
  • Page 4 Remove covering on the bottom of the fuselage as shown for motor/battery cool air exit: Assemble the wheel onto the aluminum wheel axles, fix with wheel collar, and slide axle assembly into wheel pant as shown. Assemble axle, wheel and pant onto landing gear leg as shown. Note that the carbon gear has a “front” and “back”...
  • Page 5 When both wheel/axle/pant assemblies are fixed onto the gear legs, assemble the gear onto the fuselage as shown. The screws used are 2 of the shorter black allen-head 3MM screws. Use loctite on these screws. Locate the rudder, the double-sided rudder control horn, and the tail-wheel wire as shown. Open the slots in the covering on the rudder for the horn and wire as shown.
  • Page 6 Your model uses pull-pull cables to actuate the rudder. Please examine the pull-pull system assembly diagram closely: Start the pull-pull installation by screwing the ball links onto the pull wire ends 5 to 6 threads. The cables are already run through the fuselage for you. After you crimp the crimp sleeves onto the wire, place a small drop of thin CA glue on the crimped joint.
  • Page 7 Using a 2mm Phillips screw, washer, and nut, attach the ball joint to the rudder horn. Do this on both sides of the rudder. Use a drop of thick CA glue, as shown in the pull-pull diagram, to lock the 2mm nut on the bottom of the rudder control horns after tightening.
  • Page 8 Use a piece of tape to immobilize the rudder, and make sure the rudder servo is centered. Assemble the cables onto the pull wire ends, crimp, and add a drop of thin CA to the crimp joints. The cables cross once inside the fuselage to form an X shape. It is perfectly fine for the cables to lightly rub against each other.
  • Page 9 Install the tailwheel support bracket onto the fuselage with 2 small wood screws and install the tail wheel and collar as shown. Be careful to make sure that the bracket does not cause drag on the rudder and rudder servo. If necessary, you can open the hole in the bracket larger. Locate the carbon wing spar tube and the horizontal stabilizer.
  • Page 10 Measure the position of the horizontal stabilizer, front-to-back relative to the wing spar tube and also side- to-side. The horizontal stabilizer should also be pushed forward tightly into its slot in the fuselage. When you are satisfied that the stabilizer is straight, use thin CA glue as shown to attach it. NOTE: We do not remove any covering on the stabilizer.
  • Page 11 Without using glue, slide the other elevator onto the joiner rod and into the stabilizer. Check the alignment of the elevators. If there is a misalignment of the elevator tips, you can sand the joiner slot as necessary to correct, but if you have access to a heat gun, a quicker way is to complete the installation of the elevators, then twist the elevators to correct any misalignment, and shrink out any resulting wrinkles in the covering –...
  • Page 12 Attach a 12” inch / 300mm servo extension to the elevator servo. Use heat-shrink tubing or a servo-plug lock on this connection. Install the elevator servo into the fuselage as shown. Install the pushrod adjustor onto the servo arm. As before, do not fully tighten this nut, the adjustor must be able to rotate. Use thick CA glue to lock this nut.
  • Page 13 Mount your brushless motor to the firewall using the 4 long black allen head 3mm screws. 6mm long spacers are included in the kit, use if necessary for proper cowl fit. Loctite these screws. Install your ESC, attach it to the side of the motor box. Install the self-adhesive velcro and velcro strap into the fuselage as shown.
  • Page 14 The cowl is installed with 4 small wood screws which screw into 4 small square plywood pads at the extreme front of the fuselage. Use small pieces of tape or paper as indicators to show the position of these plywood pads after the cowl is on. Install the canopy hatch (if the canopy hatch is not installed when you fit the cowl, it may be impossible to fit the canopy hatch after the cowl is installed!).
  • Page 15 Hinge the ailerons onto the wings using 2 large drops of thin CA on each hinge. Remove the covering over the aileron servo locations and the aileron control horn slots as shown. Install aileron horns into the ailerons using a generous amount of thick CA glue. Assemble the aileron pushrods as you did the elevator pushrod.
  • Page 16 VELOX VR-1 ONLY - Install the SFGs onto the wing tips as shown using 2 large wood screws each. Place the SFG spacers in between the SFGs and the wingtips to space the SFG away from the aileron to avoid interference.

  • Page 17: Setup Information

    SETUP INFORMATION Center of Gravity - Velox VR-1 98 mm from leading edge of wing at wing root (at fuselage) Edge 540 93 mm from leading edge of wing at wing root (at fuselage) These are starting, aerobatic center-of-gravity locations. After several flights, you can and should adjust in small increments to find your perfect, personal CG location.
