Dacor ERD36 Planning Manual

ERD36, ERDE36, ERD48, & ERDE48
081705
Dedicated Circuit
Model No. Required
240VAC, 4-wire,
ERD36 60Hz, 30A
(Breaker)
240VAC, 4-wire,
ERDE36 60Hz, 40A
(Breaker)
ERD48
240VAC, 4-wire,
60Hz, 50A
(Breaker)
ERDE48
Web: http://www.dacor.com
Corporate Phone: 800-793-0093
36", 48" Wide,
Epicure™ Ranges
30 3/8" (772mm)
29 1/8" (740mm)
28 1/8" (714mm)
26 1/2" (673mm)
(483mm)
1 9/16"
(40mm)
Finished Side
sIDE vIEW
Total Approximate
Connected Shipping
Load Weight
5.0kW (24A)
471 lbs.
7.7kW (34A)
10.0kW (46A)
613 lbs.
10.8kW (48A)
Handle
Front Edge of Bullnose
Face of Control Panel/Oven Door
Rear of Control Panel/Oven Door
9"
(229mm)
3"
(79mm)
19"
15 1/4"
(387mm)
9" (229mm)
Backguard
3" (76mm)
Backguard
35 1/2" - 38 5/8"
(902mm - 981mm)
Panel
NOTES:
1. Utilities may be located in the lower left corner of
the adjacent right cabinet. (Recommended)
2. Contact your local building department to verify
compliance with local code interpretation.
3. Backguards are ordered separately in heights of
3", 9" or 24".
4. 3/4" Regulator provided. 1/2" House Pipe okay.
5. Toe skirt sold separately (part# AETS36 or
AETS48).
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/2
24"(610mm)
Backguard
5.5
L65336 rev D
