K R A ME R E LE CT R O N IC S L T D .

USER MANUAL

:
MODEL
VS-41HDCP
4x1DVI Switcher
P/N: 2900-000522 Rev 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS-41HDCP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kramer VS-41HDCP

  • Page 1: User Manual

    K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL VS-41HDCP 4x1DVI Switcher P/N: 2900-000522 Rev 1...
  • Page 2 1 power adapter (5V DC) 4 rubber feet RC-IR3 IR remote control transmitter with batteries and user manual Save he original box and packaging materials in case your Kramer product needs to be returned to the factory for service. Step 2: Install the VS-41HDCP Mount the machine in a rack (using the RK-1 rack adapter) or place on a table.
  • Page 3: Table Of Contents

    10.3 Kramer Protocol 2000 Figures F igure 1: VS-41HDCP 4x1 DVI Switcher Front Panel F igure 2: VS-41HDCP 4x1 DVI Switcher Rear Panel F igure 3: Connecting a VS-41HDCP 4x1 DVI Switcher F igure 4: Connecting the Contact Closure Remote Control PINs...
  • Page 4: Introduction

    GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products. Congratulations on purchasing your Kramer VS-41HDCP 4x1 DVI Switcher. The VS-41HDCP is ideal for conference room presentations and advertising applications, as well as for rental and staging.
  • Page 5: Getting Started

    • Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer VS-41HDCP away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Warning: Use only the Kramer Electronics input power wall...
  • Page 6: Overview

    Overview The VS-41HDCP is a high quality 4x1 switcher for DVI signals that supports up to 2.25Gbps bandwidth per graphic channel (suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions). It equalizes the signal and switches one of the four inputs to a single DVI output.
  • Page 7: Defining Edid

    The Extended Display Identification Data (EDID) is a data-structure provided by a display, to describe its capabilities to a graphics card (that is connected to the display’s source). The EDID enables the VS-41HDCP to “know” what kind of monitor is connected to the output. The EDID includes the manufacturer’s name, the product type, the timing data supported by the display, the display size, luminance data and (for digital displays only) the pixel mapping data.
  • Page 8: Defining The Vs-41Hdcp 4X1 Dvi Switcher

    Connects to the PC or the RS-232 Remote Controller SETUP/PROG USB Connector Connect to a computer for firmware upgrade PROG. Button Push in for “Program” to upgrade to the latest Kramer firmware (see Section 7 ), or release for Normal ( he...
  • Page 9: Connecting A Vs-41Hdcp 4X1 Dvi Switcher

    Always switch off the power to each device before connecting it to your VS-41HDCP. After connecting your VS-41HDCP, connect its power and then switch on the power to each device. To connect the VS-41HDCP 4x1 DVI Switcher (as illustrated in Figure 3), do the following: Connect up to four computer graphics sources to the inputs (1 to 4).
  • Page 10: Connecting To The Vs-41Hdcp Via Rs-232

    Figure 3: Connecting a VS-41HDCP 4x1 DVI Switcher Connecting to the VS-41HDCP via RS-232 You can connect to the VS-41HDCP via an RS-232 connection using, for example, a PC. Note that a null-modem adapter/connection is not required. To connect to the VS-41HDCP via RS-232: •...
  • Page 11: Operating The Vs-41Hdcp

    Press the EDID button. The INPUT buttons blink in sequence until the EDID is acquired. 6.1.2 Resetting the Default EDID To reset the default EDID, disconnect the output and repeat the steps in Section 6.1.1 VS-41HDCP - Operating the VS-41HDCP...
  • Page 12: Controlling Via The Remote Terminal Block Connector

    Connecting the ETHERNET Port directly to a PC (Crossover Cable) You can connect the Ethernet port of the VS-41HDCP to the Ethernet port on your PC, via a crossover cable with RJ-45 connectors. This type of connection is recommended for identification of the factory default IP address of the VS-41HDCP during the initial configuration.
  • Page 13: F Igure 5: Local Area Connection Properties Window

    Select the Internet Protocol (TCP/IP) and click the Properties Button (see Figure Figure 5: Local Area Connection Properties Window Select Use the following IP Address, and fill in the details as shown in Figure Click OK. VS-41HDCP - Operating the VS-41HDCP...
  • Page 14: F Igure 6: Internet Protocol (Tcp/Ip) Properties Window

    6.3.2 Connecting the ETHERNET Port via a Network Hub (Straight- Through Cable) You can connect the Ethernet port of the VS-41HDCP to the Ethernet port on a network hub or network router, via a straight-through cable with RJ-45 connectors. 6.3.3...
  • Page 15: F Igure 7: Connect Screen

    192 . 168. 1 . 39 50000 Figure 7: Connect Screen Select the method to connect to the Ethernet port of the VS-41HDCP. Select:  Ethernet, if you know the IP address number or the machine name. The default name for the machine is KRAMER_XXXX (the four digits are the last four digits of the machine’s serial number)
  • Page 16: Operating The Vs-41Hdcp Using A Web Browser

    If required, make changes and click Set. If not, click Close. Operating the VS-41HDCP using a Web Browser The embedded Web pages can be used to remotely operate the VS-41HDCP using a Web browser and an Ethernet connection. Before attempting to connect: •...
  • Page 17: Log On To The Vs-41Hdcp Web Pages

    Load and enable Java • Enable Javascript in your browser Log On to the VS-41HDCP Web Pages To log on to VS-41HDCP Web pages: Open your Internet browser. Type the unit’s IP number in the Address bar of your browser.
  • Page 18: F Igure 11: First Time Security Warning

    (see Figure 12). The Web pages let you control the VS-41HDCP via the Ethernet. The menu appears on the left side of the screen. There are two remote operation Web pages: • The PANEL main page (see Section 6.5.1...
  • Page 19: Figure 12: Vs-41Hdcp Switching Matrix Page

    6.5.1 The PANEL Main Page The VS-41HDCP main page inputs to the output by clicking the audio and/or video signal indicators (purple and blue, respectively). Figure 12: VS-41HDCP Switching Matrix Page You can perform the following operations via this Web page: •...
  • Page 20: Figure 13: Configurations Page

    A window appears informing you that the configuration has been successfully changed. Click OK. If the IP address has been changed, close your browser and reload the Web page using the new IP address. Figure 13: Configurations Page VS-41HDCP - Operating the VS-41HDCP...
  • Page 21: Firmware Upgrade

    Firmware Upgrade For instructions on upgrading the firmware, see the Updating the Firmware Using the P3K Software document. The latest version of firmware and installation instructions can be downloaded from the Kramer Web site at www.kramerelectronics.com. VS-41HDCP - Firmware Upgrade...
  • Page 22: Technical Specifications

    22cm x 18cm x 4.5cm (8.6” x 7” x 1.8”) W, D, H WEIGHT: 1.3kg (2.9lbs) approx. ACCESSORIES: Power supply OPTIONS: Kramer DVI cables, RK-1 rack adapter Specifica ions are subject to change without notice Go to our Web site at http://www.kramerelectronics.com to access the list of resolu ions Default Communication Parameters...
  • Page 23: Default Edid

    1024 x 768p at 75Hz - VESA 1280 x 1024p at 75Hz - VESA 1280 x 1024p at 60Hz - VESA STD 1600 x 1200p at 60Hz - VESA STD 1152 x 864p at 75Hz - VESA STD VS-41HDCP - Default EDID...
  • Page 24: Kramer Protocol

    Protocol 3000 and Section 10.3 defines Protocol 2000. By default, the VS-41HDCP is set to Kramer’s Protocol 3000, but it is also compat ble with Protocol 2000. 10.1 Switching Protocols You can switch protocols either via the front panel buttons (see Section 10.1.1) or...
  • Page 25: Kramer Protocol 3000

    Address Body Delimiter (optional) Sender_id@ command SP [param1 ,param2 …] result CR LF CR = Carriage return (ASCII 13 = 0x0D) LF = Line feed (ASCII 10 = 0x0A) SP = Space (ASCII 32 = 0x20) VS-41HDCP - Kramer Protocol...
  • Page 26 3000 to Protocol 2000, in Protocol 2000 there is already such a command to switch Protocol to ASCII Protocol (#56 : H38 H80 H83 H81). Instruction Codes for Protocol 3000 Device initiated messages Command Syntax Start message Kramer Electronics LTD. , Device Model Version Software Version Switcher actions Video channel has switched (Breakaway mode) VID IN>OUT VS-41HDCP - Kramer Protocol...
  • Page 27: Kramer Protocol 2000

    This RS-232/RS-485 communication protocol uses four bytes of information as defined below. The default data rate is 9600 baud, with no parity, 8 data bits and 1 stop bit. DESTINATION INSTRUCTION 1st byte INPUT 2nd byte OUTPUT 3rd byte MACHINE NUMBER 4th byte VS-41HDCP - Kramer Protocol...
  • Page 28 NOTE 19 - After this instruction is sent, the unit will respond to the ASCII command set defined by the OUTPUT byte. The ASCII command to operate with the HEX command set must be sent in order to return to working with HEX codes. VS-41HDCP - Kramer Protocol...
  • Page 29 1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site www.kramerelectronics com.
  • Page 30 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
