Page 1: Table Of Contents
Table of Contents Introduction Congratulations Safety and environment protection Symbol glossary Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo AM/FM stereo cassette AM/FM stereo with CD CD changer Climate Controls Manual heating and air conditioning Electronic automatic temperature control Lights Headlamps Bulb replacement...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Traction control/AdvanceTrac Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies Hazard flasher switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance The dispute settlement board Utilizing the mediation/arbitration...
Page 4: Introduction
The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: In the United States: www.ford.com In Canada: www.ford.ca...
Page 5: Safety And Environment Protection
Introduction This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on the Owner’s Guide when reselling the vehicle.
Page 6 Introduction BREAKING-IN YOUR VEHICLE There are no particular guidelines for breaking-in your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in. SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper...
Page 7 Introduction MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book.
Page 8: Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 9 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES – 0 0 0 0 FUEL DOOR > RPMx1000 0 0 0 0 0 0 km/h BRAKE THEFT CRUISE COOLANT R N D D 1 Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs.
Page 11 Instrument Cluster These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the light should turn off.
Page 12 Instrument Cluster Brake system warning Illuminates if the parking brake is engaged. Also momentarily illuminates at start up to ensure the BRAKE circuit is functional. If the brake warning lamp does not illuminate at these times, or illuminates after releasing the parking brake, seek service immediately.
Page 13 Instrument Cluster Engine oil pressure Illuminates when the oil pressure falls below the normal range. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and specifications chapter. Low coolant (if equipped) Illuminates when the coolant level in the coolant reservoir is low and COOLANT more needs to be added.
Page 14 Instrument Cluster Check transaxle Illuminates when a transaxle problem has been detected and shifting may be restricted. If this lamp remains on, have your vehicle serviced immediately. Turn signals Illuminates when the turn signals or the hazard lights are turned on. If the lights stay on continuously or flash faster, check for a burned-out bulb.
Page 15 Instrument Cluster BeltMinder chime Sounds intermittently to remind you to fasten your safety belts. Supplemental restraint system (SRS) warning chime Sounds when a malfunction in the supplemental restraint system (front or side airbags) has been detected. Have the supplemental restraint system inspected immediately.
Page 16: Gauges
Instrument Cluster GAUGES – 0 0 0 0 FUEL DOOR > RPMx1000 0 0 0 0 0 0 km/h BRAKE THEFT CRUISE CRUISE COOLANT R N D D 1 Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H”...
Page 17 Instrument Cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
Page 18 Instrument Cluster Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. 0 0 0 0 0 0 km/h R N D D 1 Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of RPMx1000 the scale may damage the engine.
Page 19: Entertainment Systems
Entertainment Systems AM/FM STEREO Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume.
Page 20 Entertainment Systems If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. If you wish to maintain your preset volume level, turn the audio system off with the power control before switching off the ignition.
Page 21 Entertainment Systems AM/FM select The AM/FM select control works in radio mode. Press the AM or FM control to enter radio mode. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
Page 22 Entertainment Systems Setting the clock To set the hour, press and hold the hour (H) control. When the desired hour appears, release the control. To set the minute, press and hold the minute (M) control. When the desired minute appears, release the control.
Page 23: Am/Fm Stereo Cassette
Entertainment Systems MACH AUDIO SYSTEM WITH AM/FM STEREO/CASSETTE Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume.
Page 24 Entertainment Systems If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. If you wish to maintain your preset volume level, turn the audio system off with the power control before switching off the ignition.
Page 25 Entertainment Systems Seek function in CD mode • Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 26 Entertainment Systems AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. Pressing the AM or FM controls when the ignition is turned on will also engage the radio.
Page 27 Entertainment Systems Setting the clock To set the hour, press and hold the hour (H) control. When the desired hour appears, release the control. To set the minute, press and hold the minute (M) control. When the desired minute appears, release the control.
Page 28 Entertainment Systems Tape/CD select • Pressing the TAPE or CD control when the ignition is on will engage the system if a tape or CD is present in the audio system. • To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control.
Page 29 Entertainment Systems Tape direction select Press SIDE 1–2 to play the alternate side of a tape. Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction.
Page 30: Am/Fm Stereo With Cd
Entertainment Systems AUDIO SYSTEM WITH AM/FM STEREO/SINGLE CD PLAYER Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume.
Page 31 Entertainment Systems If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. If you wish to maintain your preset volume level, turn the audio system off with the power control before switching off the ignition.
Page 32 Entertainment Systems • Press to seek forward to the next track of the current disc. After the last track has been completed, the first track of the current disc will automatically replay. Scan function The scan function works in radio or CD mode.
Page 33 Entertainment Systems Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 34 Entertainment Systems Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly. • Press to move to the next frequency up the band (whether or not a listenable station is located there).
Page 35: Cd Changer
Entertainment Systems Fast forward The fast forward control works in tape and CD modes. • Pressing the control for less than three seconds results in slow forward action. Pressing the control for more than three seconds results in fast forward action. •...
Page 36 Entertainment Systems 2. Press to eject the magazine. 3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine. If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 37 Entertainment Systems 5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press in on the disc holder until it locks securely into the magazine. If the disc holders are not fully locked into the magazine, the unit will not operate.
Page 38 Entertainment Systems If your changer does not work, it may be that: • A disc is already loaded where you want to insert a disc. • The disc is inserted with the label surface downward. • The disc is dusty or defective. •...
Page 39 Entertainment Systems • Do not leave tapes in the cassette player for a long time when not being played. RADIO FREQUENCY INFORMATION The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz...
Page 40: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode Selector Control Controls the direction of the airflow to the inside of the vehicle.
Page 41 Climate Controls The air conditioning compressor can operate in all modes except . However, the air conditioning will only function if the outside temperature is about 6°C (43°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle.
Page 42 Climate Controls • (Defrost) – Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 6°C (43°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging. Operating tips •...
Page 43: Electronic Automatic Temperature Control
Climate Controls To aid in side window defogging/demisting in cold weather conditions: 1. Select the position that distributes air through the Panel and Floor. 2. Set the temperature control to full heat. 3. Set the fan speed to full fan. 4.
Page 44 Climate Controls Turning the EATC on OUTSIDE TEMP AUTO TEMP Press AUTO, any of the override controls or the fan speed control. The EATC will only operate when the vehicle is running. Turning the EATC system off Press OFF. The outside temperature OUTSIDE function will continue to operate TEMP...
Page 45 Climate Controls Temperature selection The display window indicates the AUTO selected temperature, function (AUTO or one of the override controls) and manual control of fan speed ( ) if automatic fan speed is not desired. • • • To control the temperature, select OUTSIDE any temperature between 18°C TEMP...
Page 46 Climate Controls Temperature conversion OUTSIDE TEMP AUTO TEMP Press MAX A/C and F at the same time (until the display changes) to switch between Fahrenheit and Celsius. Fan speed ( When AUTO is pressed, fan speed is adjusted automatically for existing conditions.
Page 47 Climate Controls Manual override controls OUTSIDE TEMP AUTO TEMP The override controls are located at the bottom of the EATC and allow you to determine where airflow is directed. To return to full automatic control, press AUTO. The air conditioning compressor can operate in all modes except .
Page 48 Climate Controls • (Floor)-Distributes outside air through the floor ducts. Heating and air conditioning capabilities are provided in this mode. The air will be heated or cooled based on temperature selection. • (Panel and floor) -Distributes outside air through the instrument panel registers and the floor ducts.
Page 49 Climate Controls Operating tips • In humid weather conditions, place the climate control system in before driving. This will reduce fogging on your windshield. Once the windshield has been cleared, operate the climate control system as desired. • To reduce humidity buildup inside the vehicle in cold weather conditions, don’t drive with the climate control system in the OFF or MAX A/C position.
Page 50 • Protects the climate control components from particle deposits The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, contact your Ford, Lincoln or Mercury Dealer.
Page 51: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to turn on the headlamps. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 52 Lights High beams • Push forward to activate. • Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation.
Page 53 Lights Vertical aim adjustment 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from a vertical wall or screen directly in front of it. • (A) Eight feet • (B) Center height of lamp to ground •...
Page 54 Lights To see a clearer light pattern for adjusting, you may want to block the light from one headlamp while adjusting the other. 5. Locate the vertical adjuster on each headlamp. Using a 4 mm wrench, turn the adjuster either clockwise (to adjust down) or counterclockwise (to adjust up).
Page 55 Lights The dome lamp will stay on if the control is moved to the passenger side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the driver’s side position, the lamp will not come on at all.
Page 56: Bulb Replacement
Lights Rear dome lamp (if equipped) The dome lamp lights when: • any door is opened with the control in the middle position. • the instrument panel dimmer switch is held up until the courtesy lamps come on. • any of the remote entry controls are pressed and the ignition is OFF.
Page 57 Lights Trade n Function Number of bulbs umber 3457 AK Front park/turn lamp (amber) 9007 QL Headlamp (9007 LL optional) Tail lamp/brake/turn lamp 3057K Tail lamp/brake lamp 3057K (wagon) Rear turn lamp (wagon) 3456K Backup lamp Backup lamp (wagon) 3156 License plate lamp High-mount brake lamp (wagon)
Page 58 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Remove the bolt from the headlamp housing. 3. At the back of the headlamp, pry up and remove the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward.
Page 59 Lights 5. Disconnect the electrical connector from the bulb by pulling rearward. 6. Remove the bulb retaining ring by rotating it counterclockwise. 7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly. To install the new bulb: Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 60 Lights 2. Install the bulb retaining ring over the plastic base and lock the ring by rotating clockwise until it snaps into place. 3. Connect the electrical connector to the bulb. 4. Install the protective dust shield and lock the shield by rotating it clockwise until it locks into position.
Page 61 Lights 5. Carefully pull bulb straight out of the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly by rotating it clockwise. 7. Carefully position the headlamp assembly onto the vehicle. 8. Hold the headlamp assembly snugly against the vehicle and install the retainer pins straight down to lock the lamp into place.
Page 62 Lights Replacing high-mount brakelamp bulbs — Wagon only 1. Open liftgate. 2. Remove two screw covers, screws and handle from liftgate. 3. Remove two screws and the lower trim panel from the liftgate. 4. Remove the upper trim panel. 5. Remove the rubber plug from the lower access hole in the upper portion of the liftgate.
Page 63 Lights 7. Carefully lift the lamp assembly away from the liftgate. 8. Remove the bulb socket by rotating it counterclockwise and pulling it out from the lamp assembly. 9. Carefully pull the bulb straight out of the socket and push in the new bulb.
Page 64 Lights Sedan 1. Remove two screws, grommets and the license plate lamp assembly from the trunk lid. 2. Carefully pull the bulb from the socket and push in the new bulb. 3. Install the lamp assembly on trunk lid with two grommets, ensuring the grommets are pushed all the way in to the trunk lid and secure with two screws.
Page 65 Lights 4. Remove the bulb socket by rotating it counterclockwise, then pulling it out of the lamp assembly. 5. Pull the bulb from the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly by rotating it clockwise.
Page 66: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 67 Driver Controls Press the washer control to activate the rear washer. The wiper will come on when the washer control is pressed, if it is not already on. Windshield wiper blades Check the wiper blades at least twice a year or when they seem less effective.
Page 68: Steering Wheel Adjustment
Driver Controls Rear window wiper blades Refer to Windshield wiper blades in this section for more information on rear wiper blades. TILT STEERING Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control.
Page 69: Power Windows
Driver Controls AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. The auxiliary power point is located on the instrument panel below the cigarette lighter.
Page 70 Driver Controls One touch down • Press AUTO completely down to the second detent. The driver’s window will open fully. Depress up to stop window operation. AUTO Window lock The window lock feature allows only the driver to operate the power windows.
Page 71: Mirrors
Driver Controls MIRRORS Automatic dimming inside rear view mirror (if equipped) Your vehicle is equipped with an inside rear view mirror which has an auto-dimming function. The electronic day/night mirror will change from the normal state to the AUTO non-glare state when bright lights (glare) reach the mirror.
Page 72 Driver Controls Compass zone adjustment 1. Determine which compass zone you are in by referring to the zone map. 2. With the compass display turned on, press and hold the COMP side of the control for no more than five seconds until the zone selection COMP MIRROR...
Page 73 Driver Controls Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines. 1. Start the vehicle. 2. Press and hold the COMP side of the control for approximately six seconds until “C” appears in the mirror display.
Page 74 Driver Controls Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 75 Driver Controls SPEED CONTROL (IF EQUIPPED) To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever into N (Neutral) with the speed control on.
Page 76 Driver Controls To set a speed • Press SET+. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 77 Driver Controls To set a lower set speed • Press and hold CST −. Release the control when the desired speed is reached or • Press and release CST − to operate the Tap-Down function. Each press will decrease the set speed by 1.6 km/h (1 mph) or •...
Page 78 • Compact disc changer (if equipped) • Tissue holder • Rear A/C vent • Rear ashtray (see your Ford, Lincoln Mercury dealer to obtain rear ashtray Use only soft cups in the cupholder. Hard objects can injure you in a collision.
Page 79 Driver Controls The center console has similar features as the full console. To open the storage compartment, raise the armrest and pull the strap on the seat up and toward the front of the vehicle. The rear seat area is provided with dual cupholders.
Page 80 Driver Controls To avoid potential distraction and increased risk of injury or accident, Ford recommends you do not use the phone while driving. Please pull off the road and park before making or answering a call. To prevent damage to the antenna or your car, remove the cellular phone antenna mast before using an automatic car wash.
Page 81 Driver Controls LIFTGATE (WAGON ONLY) You can open and close the liftgate and the liftgate window from outside the vehicle. It cannot be opened from inside the cargo area. • To open the liftgate window, unlock the liftgate (with the key, the power door locks or the remote entry key fob) and push the key lock cylinder.
Page 82 Driver Controls Cargo net (if equipped) (Wagon) The cargo net secures lightweight objects in the cargo area. Attach the net to the anchors provided. Do not put more than 22 kg (50 lbs.) in the net. This net is not designed to restrain objects during a collision.
Page 83 Driver Controls Rewinding the shade With extended use, the cargo shade may lose its spring tension. If this occurs, the shade must be manually rewound. This is a two-person operation. 1. Remove the shade from the vehicle and extend it with the smooth grain facing you.
Page 84 Driver Controls Cargo utility hooks (Sedan) The utility hooks located in side the trunk can be used to attach a cargo net to secure lightweight objects or hang small items on. Do not hang more than 12 kg (20 lbs) on the hooks. The hooks are not designed to restrain objects during a collision.
Page 85: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to SecuriLock Passive Anti-Theft System for more...
Page 86 Locks and Security INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.
Page 87: Anti-Theft System
Locks and Security REMOTE ENTRY SYSTEM (IF EQUIPPED) This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 88 Locks and Security Locking the doors/liftgate Press this control to lock all doors and liftgate (wagons). To confirm all doors are closed and locked, press the control a second time within three seconds. The doors will lock again and the horn will chirp.
Page 89 Locks and Security Replacing the battery The remote transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: •...
Page 90 Locks and Security Programming remote transmitters It is necessary to have all (maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure. To program the transmitters yourself: • Place the key in the ignition and turn from 2 (LOCK) to 3 (OFF) and cycle between 3 (OFF) and 4(ON) eight times in rapid...
Page 91 Locks and Security Perimeter lamps illuminated entry The exterior lamps illuminate when the vehicle is unlocked by the remote entry key fob. Vehicles equipped with auto lamps, the puddle, head, park, and tail lamps illuminate. Vehicles not equipped with auto lamp, only the puddle, park and tail lamps illuminate.
Page 92 Locks and Security Your vehicle has a factory-set 5–digit code that operates the keyless entry system. You can also program your own 5–digit personal entry code. The factory-set code is located: • on the owner’s wallet card in the glove compartment •...
Page 93 Locks and Security If you wish to erase your personal code, use the following instructions: Erasing personal code 1. Enter the factory-set code. 2. Press 1/2 within five seconds of step 1 and release. 7 8 9 0 3. Press the 1/2 control and hold for 2 seconds to erase the customer programmed keycode, within five seconds of step 2.
Page 94 This system prevents the engine from being started unless a coded key programmed to your vehicle is used. The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 95 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the 3 THEFT (OFF) position. The light in the instrument cluster will flash every two seconds when the vehicle is armed. Automatic disarming Switching the ignition to the 4 (ON) position with a coded key disarms THEFT the vehicle.
Page 96 Check to make sure the coded key is an approved Ford coded key. If your keys are lost or stolen you will need to do the following: •...
Page 97 Locks and Security Programming spare keys A maximum of eight keys can be coded to your vehicle. Only SecuriLock keys can be used. To program a coded key yourself, you will need two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible for timely implementation of each step in the procedure.
Page 98 Locks and Security PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help prevent your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to the dealership, to aid in troubleshooting.
Page 99 Locks and Security When you press the lock control twice within three seconds on your remote entry transmitter, the horn will chirp once to let you know that all doors/hood and liftgate (wagon) are closed. If the doors/hood or liftgate (wagon) are not closed and you press the remote entry transmitter twice to confirm the doors are locked, the horn will chirp twice to warn you that a door/hood or liftgate (wagon) is still open.
Page 100 Locks and Security • Press the PANIC control on the remote entry transmitter. This will only shut the horn OFF when the alarm is sounding. The alarm system will still be armed. Triggering the anti-theft system The armed system will be triggered if: •...
Page 101: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints Your vehicle’s seats are equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 102 Seating and Safety Restraints Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to reduce the risk of injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 103 Seating and Safety Restraints Adjusting the front power seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 104 Seating and Safety Restraints REAR SEATS 2nd seat/split-folding rear seat (if equipped) One or both rear seatbacks can be folded down to provide additional cargo space. To lower the seatback(s) from inside the vehicle, pull tab to release seat back and then fold seatback down.
Page 105: Safety Restraints
Seating and Safety Restraints 3. Lift the remote latch release on the left side of the compartment and fold the remaining floor panel until it latches. Make sure the seatback is locked in the upright position. To close the seat, make sure the safety belts are properly stowed, then lift the remote latch release and push the seat down until it latches.
Page 106 Seating and Safety Restraints How does the personal safety system work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and occupant conditions. A collection of crash and occupant sensors provides information to the Restraints Control Module (RCM).
Page 107 Seating and Safety Restraints allows your Personal Safety System to tailor the air bag deployment and safety belt pretensioner activation depending upon safety belt usage. Refer to Safety Belt section in this chapter. Front safety belt pretensioners The safety belt pretensioners are designed to tighten the safety belts firmly against the occupant’s body during a collision.
Page 108 Seating and Safety Restraints Safety belt precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 109 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 110 Seating and Safety Restraints Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 8 km/h (5 mph) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
Page 111 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 112 Seating and Safety Restraints Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions. Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front outboard passenger seating positions. The safety belt pretensioners are designed to activate only when the safety belts are fastened during certain frontal or near-frontal collisions with sufficient longitudinal deceleration.
Page 113 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, pull the control down and slide the height adjuster down.
Page 114 Seating and Safety Restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 115 Seating and Safety Restraints grasp the tongue so that it is parallel to the webbing and slide the tongue upward. Provide enough length so that the tongue can reach the buckle. To fasten the belt, pull the combination lap and shoulder belt from the retractor so that the shoulder belt portion of the safety belt crosses your shoulder and chest.
Page 116 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 117 Seating and Safety Restraints If... Then... The driver’s safety belt is The BeltMinder feature will not buckled before the ignition activate. switch is turned to the ON position... The purpose of the BeltMinder is to remind occasional wearers to wear safety belts all of the time.
Page 118 Seating and Safety Restraints Reasons given... Consider... “Belts wrinkle my clothes” Possibly, but a serious crash can do much more than wrinkle your clothes, particularly if you are unbelted. “The people I’m with don’t Set the example, teen deaths occur 4 wear belts”...
Page 119 Seating and Safety Restraints • the ignition switch is in the OFF position • all vehicle doors are closed • the driver’s safety belt is unbuckled • the parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure.) To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 120 (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 121: Air Bags
This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
Page 122 Seating and Safety Restraints The air bag supplemental restraints are an intergral part of the Personal Safety System. They are designed to be deployed in cases where the Personal Safety System has determined the occupant conditions and crash severity are appropriate to activate these devices. Refer to the Personal Safety System section in this chapter.
Page 123 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to occupants in the center front seating position.
Page 124 Seating and Safety Restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 125 Seating and Safety Restraints How do the air bag supplemental restraints work? The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking...
Page 126 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 127 Seating and Safety Restraints How does the side air bag system work? The side air bag system consists of the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 128: Child Restraints
Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with...
Page 129 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 130 Seating and Safety Restraints SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 131 • Put the safety belt in the automatic locking mode. Refer to Automatic locking mode. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
Page 132 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 133 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 134 Seating and Safety Restraints Installing child safety seats in the lap belt seating positions 1. Lengthen the lap belt. To lengthen the belt, hold the tongue so that its bottom is perpendicular to the direction of webbing while sliding the tongue up the webbing.
Page 135 Seating and Safety Restraints 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seatback.
Page 136 Seating and Safety Restraints Attaching safety seats with LATCH (Lower Anchors and Tethers for CHildren) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use seat belts to attach the child seat.
Page 137 Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 138: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine without locking the steering wheel.
Page 139 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 140 Driving 5. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: •...
Page 141 Cold starting performance can also be improved with the use of an engine block heater. The engine block heater is available as a Ford option and can also be obtained from your Ford dealer. Consult the engine block heater section for proper use of the engine block heater.
Page 142 Driving 3. When the engine starts, release the key, then release the accelerator pedal gradually as the engine speeds up. 4. If the engine still fails to start, repeat steps one through three. 5. After the engine starts, hold your foot on the brake pedal, put the gearshift lever in gear and release the parking brake.
Page 143: Brakes
Driving WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 144 Driving heard during this test. This is normal. If a malfunction is found, the ABS warning light will come on. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician. The ABS operates by detecting the onset of wheel lockup during brake applications and compensates for this...
Page 145 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released.
Page 146: Traction Control/Advancetrac
Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. Park brake warning chime Sounds when the parking brake is set, the engine is running and the transaxle is not in P (Park) or N (Neutral).
Page 147 Driving During Traction Control operation, the traction control active light will illuminate, you may hear an electric motor type of sound coming from the engine compartment and the engine will not “rev-up” when you push further on the accelerator. This is normal system behavior.
Page 148: Transmission Operation
Driving • high crown in center of road • high crosswinds • wheels out of alignment • loose or worn suspension components AUTOMATIC TRANSAXLE OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.
Page 149 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician.
Page 150 Driving Hold the brake pedal down while you move the gearshift lever from P (Park) to another position. If you do not hold the brake pedal down, your vehicle may move unexpectedly and injure someone. Understanding gearshift positions P (Park) Always come to a complete stop P R N before shifting into P (Park).
Page 151 Driving N (Neutral) With the gearshift lever in the N P R N (Neutral) position, the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. (Overdrive) (Overdrive) position is the P R N normal driving position for an automatic overdrive transaxle.
Page 152 Driving When to use D (Drive) The D (Drive) position eliminates P R N the needless shifting back and forth between third and fourth gears that your vehicle may do when driving on hilly terrain. It also gives more engine braking than overdrive to slow your vehicle on downgrades.
Page 153: Vehicle Loading
Driving When parking, do not use the gearshift in place of the parking brake. Always set the parking brake fully and make sure that the gearshift is securely latched in Park (P). Turn off the ignition whenever you leave your vehicle. Never leave your vehicle unattended while it is running.
Page 154 Driving • GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system. The GAWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. • GCW (Gross Combined Weight): The combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer.
Page 155: Trailer Towing
Your vehicle does not come from the factory fully equipped to tow. No towing packages are available through Ford or Mercury/Lincoln dealers. Do not tow a trailer until your vehicle has been driven at least 800 km (500 miles).
Page 156 Driving 3.0L 4-Valve Duratec Engine Model Passenger Luggage Load - Max Trailer Load - #/kg kg (lbs.) Wt.- kg (lbs.) (lbs.) Sedan 5/340 (750) 590 (1 300) 2/135 (300) 70 (150) 725 (1 600) 2/135 (300) 795 (1 750) Wagon 5/340 (750) 70 (150) 455 (1 000)
Page 157 Driving If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 158: Recreational Towing
Driving Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 159: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist if you should have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 160: Hazard Flasher Switch
ROADSIDE COVERAGE BEYOND BASIC WARRANTY In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, for uninterrupted Roadside Assistance coverage, you may purchase extended coverage prior to your Basic Warranty’s Roadside...
Page 161 Roadside Emergencies If your vehicle is a sedan, the fuel pump shut-off switch is located on the right side of the trunk behind the trunk liner. If your vehicle is a wagon, the fuel pump shut-off switch is located behind the service panel on the right side of the cargo area.
Page 162: Fuses And Relays
Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 163 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 164 Roadside Emergencies Fuse/relay Fuse amp Passenger compartment fuse location rating panel description Integrated control panel (ICP), Rear washer wiper control, Front washer, Cell phone, Passenger switch illumination, GEM, Rear wiper motor Heated mirrors, Rear defrost switch Power point — Not used Front wiper motor Flasher and GEM power, Integrated control panel (ICP)
Page 165 Roadside Emergencies Fuse/relay Fuse amp Passenger compartment fuse location rating panel description Autolamps, Park lamps, PWM, Headlamp switch Horns and horn switch, OBD II connector — Not used ABS, DRL relay coil, Speed control actuator, Traction control switch, AC heater selector switch, Blend door actuator, Brake shift interlock, Rear defroster relay coil —...
Page 166 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 167 Roadside Emergencies Fuse/relay Fuse amp Power distribution box location rating description 60A** Fuse junction panel 30A** PCM relay 60A** Fuse junction panel — Not used — Not used — Not used 40A** Starter relay, Ignition switch 20A** Transit relay (export only) 40A** Cooling fan relays —...
Page 168: Changing Tires
Roadside Emergencies Fuse/relay Fuse amp Power distribution box location rating description 15A* HEGO sensor transmission shift solenoid, Canister vent, A/C clutch relay — Wiper park relay — Fuel pump relay — PCM power relay — Fan relay — A/C clutch relay * Mini Fuses ** Maxi Fuses Relays Relays are located in the power distribution box and should be replaced...
Page 169 Roadside Emergencies • drive through an automatic car wash, because of the vehicle’s reduced ground clearance • try to repair the temporary spare tire or remove it from its wheel • use the wheel for any other type of vehicle Tire change procedure 1.
Page 170 Roadside Emergencies • In the wagon, they are stored in the left side rear trim panel for the temporary spare and in the floor cargo area storage compartment for the full size spare. 3. If equipped with a wheel cover that’s bolted on, loosen the five plastic nuts with the lug nut wrench.
Page 171 Roadside Emergencies 6. Put the jack in the jack notch next to the door of the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground. 7. Remove the lug nuts with the lug nut wrench.
Page 172: Jump Starting
Roadside Emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted.
Page 173 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 174 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable. Make the connection to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 175 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 176 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 177: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 178 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company provides a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 179: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 180 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business).
Page 181 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 182: The Dispute Settlement Board
THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes • available free to owners and lessees of qualifying Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford...
Page 183 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 184 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 185: Utilizing The Mediation/Arbitration
UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 186: Ordering Additional Owner's Literature
If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 187 Customer Assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 188: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 189: Cleaning
Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your authorized Ford, Lincoln or Mercury dealer. Always use a clean sponge or carwash mitt with plenty of water for best results. Dry the vehicle with a chamois or soft terry cloth towel in order to eliminate water spotting.
Page 190 Minor scratches or paint damage from road debris may be repaired using the Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), which is available at your authorized Ford, Lincoln or Mercury dealer. This kit contains: • Lacquer Touch-Up Paint (ALBZ-19500–XXXXA) •...
Page 191 Cleaning CLEANING THE ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • The engine must be cool to the touch before spraying with water. • Never spray a hot engine with cold water, as damage to the engine block or engine components may occur.
Page 192 Road Oil Removal (B7A-19520–AA). Use only approved products to clean plastic parts. These products are available from your authorized Ford, Lincoln or Mercury dealer. WASHING THE EXTERIOR LAMPS In order to avoid scratching the plastic lamps, do not use dry paper towels, non-approved chemical solvents or abrasive cleaners.
Page 193 Clean the outside of the windshield or rear window with a non-abrasive cleaner such as Ultra Clear Spray Glass Cleaner (E4AZ-19C507–AA), available from your authorized Ford, Lincoln or Mercury dealer. If after cleaning the glass surface, the water sheets from the glass (e.g., does not bead), then the window is clean.
Page 194 Extra Strength Upholstery Cleaner (E8AZ-19523–AA). CLEANING LEATHER SEATS (IF EQUIPPED) All Ford, Lincoln and Mercury vehicles with leather seating surfaces have a clear, protective coating over the leather. To clean the leather seats, simply use a soft cloth with Deluxe Leather and Vinyl Cleaner (F2AZ-19521–WA).
Page 195: Underbody Preservation
(E4AZ-19C507–AA). Dry the area by wiping with a dry, soft, clean cloth. FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 196 Motorcraft Vinyl Conditioner (Canada only) Ford Deluxe Leather and Vinyl Cleaner (not available in Canada) Motorcraft Vinyl Cleaner (Canada only) Ford Extra Strength Tar and Road Oil Remover* (not available in Canada) Ford Extra Strength Upholstery Cleaner (not available in Canada)
Page 197: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 198: Hood
Maintenance and Specifications Working with the engine on 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Block the wheels to prevent the vehicle from moving unexpectedly. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 199: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.0L V6 Vulcan engine 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Air filter assembly 4. Battery 5. Engine oil filler cap 6. Engine oil dipstick 7. Engine coolant reservoir 8.
Page 200 Maintenance and Specifications 3.0L DOHC V6 Duratec engine 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Air filter assembly 4. Battery 5. Engine oil dipstick 6. Engine oil filler cap 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.
Page 201 In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Ford specification ESR-M17P5–A. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 202: Engine Oil
Maintenance and Specifications Checking and adding washer fluid for the liftgate (if equipped) The opening for the reservoir is located on the passenger side under the tail lamp. Refill this reservoir with the same fluid you use for your windshield. ENGINE OIL Checking the engine oil Refer to the scheduled maintenance guide for the appropriate intervals...
Page 203 Maintenance and Specifications 5. Locate and carefully remove the engine oil indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the add 1QT and FULL marks or between the MIN and MAX marks (depending on application), the oil level is acceptable.
Page 204 Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 205: Battery
Maintenance and Specifications Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 206 Maintenance and Specifications Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 207 Maintenance and Specifications • The vehicle may need to be driven 16 km (10 miles) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 208 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 209 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. • Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium...
Page 210 Maintenance and Specifications • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 211 Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 212: Fuel Information
Maintenance and Specifications If you drive in extremely hot climates: • It is still necessary to maintain the coolant concentration above 40%. • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage.
Page 213 Maintenance and Specifications Fuel ethanol and gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling.
Page 214 Maintenance and Specifications • FFV fuel tanks may contain zero to 85 percent ethanol. Any fuel blends containing gasoline and ethanol should be treated the same as “Fuel Ethanol ”. To identify if your vehicle is an FFV, check your VIN or the label on the inside of your fuel filler door.
Page 215 Maintenance and Specifications When refueling always shut the engine off and never allow sparks or open flames near the filler neck. Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container.
Page 216 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 217 Maintenance and Specifications Unleaded Gasoline engines Your vehicle is designed to use “Regular” unleaded gasoline with an (R+M)/2 octane rating of 87. We do not recommend the use of gasolines labeled as “Regular” that are sold with octane ratings of 86 or lower in high altitude areas.
Page 218 “Ethanol Fuel Compatible” dispensing station equipment. These standards and guidelines can be obtained from Ford Motor Company. Fuel stations may apply to be certified as meeting these standards. However, not all stations meet these standards at this time. To ensure proper operation of your FFV on fuel ethanol, refuel at certified stations.
Page 219 Maintenance and Specifications Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
Page 220 Maintenance and Specifications • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1.
Page 221 Maintenance and Specifications • Slow down gradually. • Driving at reasonable speeds (traveling at 88 km/h [55 mph] uses 15% less fuel than traveling at 105 km/h [65 mph]). • Revving the engine before turning it off may reduce fuel economy. •...
Page 222 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine...
Page 223 Maintenance and Specifications Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly.
Page 224 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 225 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 226 Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid Refer to your scheduled maintenance guide for scheduled intervals for fluid checks and changes. Your transaxle does not consume fluid. However, the fluid level should be checked if the transaxle is not working properly, i.e., if the transaxle slips or shifts slowly or if you notice some sign of fluid leakage.
Page 227 Maintenance and Specifications Correct fluid level The transmission fluid should be checked at normal operating temperatures 66°C-77°C (150°F-170°F) on a level surface. The normal operating temperature can be reached after approximately 30 km (20 miles) of driving. The transmission fluid should be in this range if at normal operating DON’T ADD IF IN CROSSHATCH AREA--CHECH WHEN HOT-IDLING temperature (66°C-77°C...
Page 228 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 229 Maintenance and Specifications The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 230 Maintenance and Specifications Tire rotation Because your vehicle’s tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the scheduled maintenance guide. If you notice that the tires wear unevenly, have them checked. •...
Page 231 Follow these guidelines when using snow tires and chains: • Use only cable type chains offered by Ford as an accessory or equivalent. SAE class “S” or other conventional link type chains may cause damage to the vehicle’s wheel house and/or body.
Page 232: Part Numbers
Maintenance and Specifications MOTORCRAFT PART NUMBERS Component 3.0L V6 Vulcan 3.0L FFV V6 3.0L DOHC V6 engine engine Duratec engine Air filter FA-1683 FA-1683 FA-1683 element Fuel filter FG-1006 FG-1006 FG-1006 Battery BXT-36R BXT-36R BXT-36R (standard) Battery BXT-36R (optional) Oil filter FL-400-S FL-400-S FL-820-S...
Page 233: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft Fill to line on High reservoir Performance DOT 3 Motor Vehicle Brake Fluid Engine Motorcraft 3.0L V6 Vulcan 11.0L coolant Premium engine (11.6 quarts) Engine Coolant...
Page 234: Lubricant Specifications
Maintenance and Specifications Fluid Ford Part Application Capacity Name Windshield Ultra-Clear Wagon 1.8L washer fluid - Windshield (60.9 oz.) Rear Washer Concentrate Add the coolant type originally equipped in your vehicle. LUBRICANT SPECIFICATIONS Ford Part Ford Part Ford Items Name or...
Page 235 Maintenance and Specifications Ford Part Ford Part Ford Items Name or Number Specification equivalent Engine coolant Motorcraft VC-4–A (US) or ESE-M97B44-A Premium Engine CXC-10 Coolant (Canada) (green-colored) Motorcraft VC-7–A Premium Gold -M97B51–A1 Engine Coolant (yellow-colored) Power steering Motorcraft XT-2-QDX MERCON...
Page 236: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.0L V6 Vulcan 3.0L FFV V6 3.0L DOHC V6 engine engine Duratec engine Cubic inches Required fuel 87 octane 87 octane or 87 octane Ethanol (E 85) Firing order 1-4-2-5-3-6 1-4-2-5-3-6 1-4-2-5-3-6 Spark plug gap 1.07-1.17 mm 1.07-1.17 mm 1.3-1.4 mm...
Page 237 Maintenance and Specifications...
Page 238 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 239 Maintenance and Specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 240: Accessories
Accessories FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 241 Accessories Travel equipment Electrochromic inside mirror with compass Electrochromic inside mirror with compass and temperature Emergency kit Factory luggage rack adaptors First aid kit Framed luggage carrier Removable luggage rack Removable luggage rack adapters Soft luggage cover Speed control Track rider bars Protection and appearance equipment Air bag anti-theft locks Car covers...
Page 242 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 243: Index
Index Accessory delay ......70 Battery ........205 acid, treating emergencies ..205 Air bag supplemental charging system restraint system ..121–122, 126 warning light ......12 and child safety seats ....124 jumping a disabled battery ..172 description ......122, 126 maintenance-free ....205 disposal ........128 replacement, driver air bag ..121, 125, 127 specifications ......232 indicator light ....12, 125...
Page 244 ....234, 236 jump-starting ......172 Cruise control Emission control system ..222 (see Speed control) ....75 Engine ........236 Customer Assistance ....159 check engine/service Ford accessories for engine soon light ......10 your vehicle ......195 cleaning ........191 Ford Extended coolant ........207 Service Plan ......181...
Page 245 Index idle speed control ....205 safety information relating lubrication to automotive fuels ....212 specifications ....234, 236 Fuses ........162–163 refill capacities ......233 service points ....199–200 starting after a collision ..160 Engine block heater ....142 Gas cap (see Fuel cap) ..11, 215 Engine oil ........202 Gas mileage checking and adding ....202...
Page 246 Index high beam ......14, 52 replacing bulbs ......58 turning on and off ....51 Lamps warning chime ......15 autolamp system .......51 bulb replacement Heating ........43 specifications chart ....56 heating and air conditioning cargo lamps .......52 system ........40 daytime running light ....51 Hood ..........198 headlamps .........51 headlamps, flash to pass ..52...
Page 247 Index Locks fluid, checking and adding ..224 autolock ........94 fluid, refill capacity ....233 childproof ........85 fluid, specifications ..234, 236 doors ..........85 Lubricant specifications .....234, 236 Rear window defroster ....50 Lumbar support, seats .....101 Relays ........162, 168 Remote entry system ...87–88 illuminated entry ....90–91 locking/unlocking doors ..85, Mirrors .........68...
Page 248 Index SecuriLock passive Transmission anti-theft system .....94–95, 97 fluid, checking and adding (automatic) ......226 Servicing your vehicle ....197 lubricant specifications ..234 Spark plugs, Trip odometer ......18 specifications .....232, 236 Trunk ......81, 84, 86, 88 Specification chart, remote release ......80 lubricants ......234, 236 Turn signal ......14, 54 Speed control ......75 Speedometer .......17...
