Page 1 Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette with CD AM/FM stereo with CD CD changer Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Power windows Mirrors Speed control...
Page 3: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 4 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 5 SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 6 Truck Body Builders Advisory Service 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance...
Page 7 You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer. Ford Ambulance Preparation Package is only available on certain 7.3L Diesel engine equipped vehicles. Notice to owners with vehicles equipped with Power Take Off...
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Child Seat Tether Anchor Anti-Lock Brake System Traction Control Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist...
Page 9 Vehicle Symbol Glossary Power Windows Front/Rear Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Introduction Power Window Lockout Interior Luggage Compartment Release Symbol...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster Brake system warning light: Illuminates if the parking brake is engaged or to indicate low brake fluid level. To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position (alternatively for some vehicles when the ignition is moved from the ON position to the START position, the light will momentarily illuminate prior to reaching the START position).
Page 12 Instrument Cluster Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated. Transmission control indicator light (TCIL): Illuminates when the OVERDRIVE overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily, have the system serviced immediately.
Page 13: Gauges
GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 14 Instrument Cluster Trip odometer: Registers the kilometers (miles) of individual journeys. To reset, depress the P RN control. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Battery voltage gauge (manual transmission only): Indicates the battery voltage when...
Page 15 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). Transmission fluid temperature gauge (automatic transmission only): If the gauge is in the: White area (normal) - the transmission fluid is within the normal operating temperature (between “H”...
Page 16 If the gauge is operating in the Yellow or Red area, stop the vehicle and verify the airflow is not restricted such as snow or debris blocking airflow through the grill. If the gauge continues to show high temperatures, see your Ford or Lincoln Mercury dealer.
Page 17: Entertainment Systems
AM/FM STEREO PUSH TONE 1. Seek: Press to find the next listenable station down/up the frequency band. 2. Tune: Press to manually change radio frequency down/up. 3. AM/FM: Press to choose a frequency band in radio mode. 4. Memory preset buttons: To set a station: Select frequency band AM/FM;...
Page 18 Entertainment Systems 5. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels. 6. Tone: Press TONE until the PUSH desired level — Bass, Treble, Fade, TONE Balance (if equipped) appears on the display. Turn the volume control to raise/lower the levels, or to move the audio sound from the right to left or the front to back (if equipped).
Page 19 AM/FM STEREO CASSETTE 14 15 16 17 VOL - PUSH ON BASS TREB SEEK SCAN TUNE 1. Balance: Press to shift sound to the left/right speakers. 2. Fade: Press to shift sound to the rear/front speakers. 3. CLK: To set the hour, press and hold CLK.
Page 20 Entertainment Systems next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection). The tape MUST have a blank section of at least four seconds duration between programs. 5. Side 1–2: Press to change tape SIDE 1 - 2 direction.
Page 21 Entertainment Systems 13. AM/FM: Press to choose a frequency band in radio mode. 14. Bass: Press decrease/increase the bass output. 15. Treble: Press decrease/increase the treble output. 16. EJ (Eject): Press to eject a tape. 17. Cassette door: Insert a cassette into the cassette door.
Page 22 Entertainment Systems PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD 1. Power/volume: Press to turn ON/OFF; turn clockwise/counterclockwise to increase/decrease volume. 2. Scan: Press SCAN to move up SCAN the radio frequency band. SCAN automatically finds a station, plays it for five seconds, then moves to the next station. Press again to stop. Tape/CD: Press SCAN to sample tape/CD selections for eight seconds.
Page 23 Entertainment Systems 4. Cassette door: Insert the cassette with the opening to the right. 5. Eject: Press to eject the cassette/CD. The radio will resume playing. 6. Tape: Press to start tape play. Press to stop tape during rewind/fast forward. CD: Press to start CD play.
Page 24 Entertainment Systems 10. Balance: Press BAL; then press to shift sound to the left/right speakers. Fade: Press FADE; then press to shift sound to the rear/front speakers. 11. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns.
Page 25 18. Select (SEL): Use with Bass, Treble, Balance and Fade controls. 19. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output. 20. Tune: Works in radio mode only. Press TUNE to change frequency down/up.
Page 26 Entertainment Systems PREMIUM IN-DASH SIX CD SOUND SYSTEM 1. Seek: Press and release SEEK for previous/next strong station, or track of current disc. 2. Rewind: Press for a slow rewind, press and hold for a fast rewind. Fast forward: Press for a slow advance, press and hold for a fast advance.
Page 27 6. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output. 7. Select: Use with Bass, Treble, Balance and Fade controls to adjust levels. Use with MENU to set the clock and engage RDS.
Page 28: Cd Changer
Entertainment Systems are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press again to disengage. 13. Power/volume: Press to turn ON/OFF;...
Page 29 Entertainment Systems 1. Slide the door to access the CD changer magazine. 2. Press to eject the magazine. 3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine. Do not pull too hard on the disc holder as the disc holder may come completely out of the magazine.
Page 30 Entertainment Systems Ensure that the disc holder is evenly inserted and at the same level as the magazine (A). The unit will not operate if the disc holder is not inserted at the same level (B). If your CD changer is located under the rear bench, the following instructions apply to load discs: 1.
Page 31 RADIO RECEPTION FACTORS There are three factors that can effect radio reception: • Distance/strength: The further you travel from an FM station, the weaker the signal and the weaker the reception. • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception.
Page 32 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 33: Climate Controls
HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 34: Manual Heating And Air Conditioning
Climate Controls 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 35 • Do not put objects under the front seats that will interfere with the airflow to the back seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. To aid in side window defogging/demisting in cold weather: 1.
Page 36: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 37 Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on only when the headlamp control is in the position and the high beams are not turned on. Pull headlamp control towards you to turn foglamps on. The foglamp indicator light will illuminate if the ignition is in the RUN position.
Page 38: Turn Signal Control
Lights Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps.
Page 39: Bulb Replacement
COURTESY/READING LAMPS (IF EQUIPPED) The dome lamp lights when the control is in the DOOR (left) position, any door is open, the instrument panel switch is pushed past the detent and when any of the remote entry controls are pressed while the ignition is off.
Page 40 Lights Function Rear fender clearance Interior visor lamp (if equipped) Rear identification All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer Replace entire lamp assembly; bulb is not serviceable. Replacing headlamp bulbs (aerodynamic) 1.
Page 41 Lights 2. Remove the two screws and parking lamp/side marker assembly by pulling gently 3. Disconnect the electrical connectors from the parking lamp/side marker assembly and remove. 4. Remove the four bolts and headlamp bezel. 5. Remove the four screws and the headlamp retaining ring from headlamp.
Page 42 Lights 3. Rotate bulb socket counterclockwise and remove from lamp assembly. 4. Carefully pull bulb straight out of the socket and push in the new bulb. Install the new bulb(s) in reverse order. Replacing tail lamp/turn/backup lamp bulbs — F250/F350 only 1.
Page 43 Lights Replacing brake/tail/backup lamp bulbs — F450/F550 only 1. Make sure the headlamp switch is in the OFF position. 2. Remove the four screws and the lamp lens from lamp assembly. 3. Carefully pull the bulb straight out of the socket and push in the new bulb.
Page 44 Lights Replacing foglamp bulbs (if equipped) 1. Make sure the headlamp switch is in the OFF position. 2. Remove the bulb socket from the foglamp by turning counterclockwise. 3. Disconnect the electrical connector from the foglamp bulb. Install the new bulb(s) in reverse order. Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper.
Page 45: Driver Controls
MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: • briefly: causes a single swipe of the wipers without washer fluid.
Page 46 Driver Controls TILT STEERING WHEEL (IF EQUIPPED) To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control.
Page 47 Driver Controls Install a garage door opener (if equipped) The storage compartment can be used to hold a variety of aftermarket garage door openers. To install your garage door opener: 1. Open the storage compartment door. 2. Remove the storage clip and stow it away.
Page 48: Power Windows
Driver Controls POWER WINDOWS (IF EQUIPPED) Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window. One touch down Allows the driver’s window to open fully without holding the control down.
Page 49: Mirrors
Driver Controls POWER SIDE VIEW MIRRORS (IF EQUIPPED) To adjust your mirrors 1. Select L to adjust the left mirror or R to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror. 3.
Page 50: Speed Control
Driver Controls Never adjust the accelerator and brake pedal with feet on pedals or while the vehicle is moving. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 48 km/h (30 mph) or more without keeping your foot on the pedal. Speed control does not work at speeds below 48 km/h (30 mph).
Page 51 Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 48 km/h (30 mph). Increasing speed while using speed control There are two ways to set a higher speed:...
Page 52 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal or the clutch pedal (if equipped). This will not erase your vehicles previously set speed.
Page 53 CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: • Utility compartment with cassette/CD holder • Coin holder • Pen holder • Writing surface Use only soft cups in the cupholder. Hard objects can injure you in a collision.
Page 54 Driver Controls The trip computer only operates with the ignition in the ON position. Trip computer features are as follows: Selectable features English/metric display Press this control to change the trip computer display between metric and English units. Mode control Each press of the MODE control will display a different feature as follows: Average fuel economy.
Page 55 Driver Controls 2. Press the E/M and MODE controls simultaneously. The display will illuminate the “AVG” indicator. While the indicator is lit, release both controls to reset the average fuel economy. Fuel range. This displays the approximate number of kilometers (miles) left to drive before the fuel tank is empty.
Page 56 Driver Controls Magnetic or metallic objects placed in or on the vehicle may also affect compass accuracy. Adjustments may need to be made to the zone and calibration of the compass. Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map.
Page 57 3. Press and hold both trip computer controls. After approximately eight seconds, the trip computer will enter CAL mode. CAL mode is indicated when the display lights the “CAL” indicator. 4. Release both controls. The display will return to normal, except that the CAL indicator will remain lit until the compass is sucessfully calibrated.
Page 58: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. POWER DOOR LOCKS (IF EQUIPPED) Press control to unlock all doors.
Page 59 Childproof door locks • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 60 Locks and Security Your vehicle is equipped with a remote entry system which allows you to: • unlock the vehicle doors without a key. • lock all the vehicle doors without a key. • activate the personal alarm. If there is any potential remote keyless entry problem with your vehicle, ensure ALL remote entry transmitters are taken to the dealership, to aid in troubleshooting.
Page 61 Locks and Security The UNLOCK feature will work again after: • a door has become ajar, • the ignition is turned to the ON position, or • using the UNLOCK control on your remote entry transmitter. Power door unlock disable feature — activation/deactivation Please see your dealer in order to activate/deactivate this feature.
Page 62 Locks and Security Replacing lost remote entry transmitters If you would like to have your remote entry transmitter reprogrammed because you lost one, or would like to buy additional remote entry transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for reprogramming.
Page 63 Locks and Security Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The illuminated entry system will turn off the interior lights if: • the ignition switch is turned to the ON position, or •...
Page 64 Locks and Security Deactivating/activating the autolock feature Before following the procedure, make sure that the ignition is OFF and all vehicle doors are closed. You must complete steps 1-7 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds.
Page 65: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to avoid injury in a collision or sudden stop.
Page 66 Seating and Safety Restraints 40/20/40 split bench seat (if equipped) • Lift the track release bar to move the seat forward or backward. Ensure the seat is relatched into place. • Pull the handle on the side of the seat up to recline the seat. •...
Page 67 Seating and Safety Restraints To gain access to the storage compartment in your armrest, lift the latch to open the lid. The lid cannot be opened in the upright position. Captain’s chair (if equipped) • Lift the bar to move the seat forward or rearward.
Page 68 Seating and Safety Restraints Adjusting the front power seat (if equipped) The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion.
Page 69 Seating and Safety Restraints Using the manual lumbar support For more lumbar support, turn the lumbar support control toward the front of vehicle. For less lumbar support, turn the lumbar support control toward the rear of vehicle. Heated seats (if equipped) To operate the heated seats: •...
Page 70: Safety Restraints
Seating and Safety Restraints RETURNING THE SEAT TO SEATING POSITION Always be sure that the seat is in a latched position, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. 1.
Page 71 Seating and Safety Restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 72 Seating and Safety Restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 73 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 74 Seating and Safety Restraints Safety belt replacement label The short plastic boot on the front safety belt at the passenger outboard anchor location covers a “Replace Belt” label on the safety belt. In the event of a collision, the colored label (REPLACE BELT) may become visible.
Page 75 Seating and Safety Restraints The Seat Integrated Restraints (SIR) seat (which has shoulder belts attached to the corners of the front seat back) is equipped with a buckle pretensioner. Do NOT place objects between the seats, this could interfere with the functioning of the pretensioner. For the SuperCab and CrewCab base bench seats and all Regular Cab seating positions, the safety belts are equipped with a retractor pretensioner.
Page 76 Seating and Safety Restraints • 4–door Super Cab (if equipped) To adjust the shoulder belt height, push the button and slide the height adjuster up or down. Release the button and pull down on the height adjuster to make sure it is locked in place. Position the safety belt height adjusters so that the belt rests across the middle of your shoulder.
Page 77 Seating and Safety Restraints Shorten and fasten the belt when not in use. Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If...
Page 78 Seating and Safety Restraints If... The driver’s safety belt is not buckled before the vehicle has reached at least 5 km/h (3 mph) and 1-2 minutes have elapsed since the ignition switch has been turned to ON... The driver’s safety belt is buckled while the safety belt indicator light is illuminated and the safety belt warning chime is sounding...
Page 79 Seating and Safety Restraints Reasons given... Consider... “Traffic is light” Nearly 1 of 2 deaths occur in single-vehicle crashes, many when no other vehicles are around. “Belts wrinkle my Possibly, but a serious crash can do much more clothes” than wrinkle your clothes, particularly if you are unbelted.
Page 80 Seating and Safety Restraints • The driver’s safety belt is unbuckled. • The parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure). To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 81 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 82: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DIESEL FUEL ONLY km/h RPM x 1000 ACCEL Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries.
Page 83 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to an occupant in the center front seating position.
Page 84 Seating and Safety Restraints Children must always be properly restrained. Failure to follow these instructions may increase the risk of injury in a collision. An infant in a rear-facing seat faces a high risk of serious or fatal injuries from a deploying passenger air bag. Rear facing infant seats should NEVER be placed in the front seats, unless the passenger air bag is turned off.
Page 85 Seating and Safety Restraints restrained or are otherwise out of position at the time of air bag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the air bag module as possible while maintaining vehicle control. Several air bag system components get hot after inflation.
Page 86 If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. PASSENGER AIR BAG...
Page 87 If the OFF light is illuminated when the passenger air bag switch is in the ON position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. The passenger side air bag should always be ON (the air bag OFF light...
Page 88 Seating and Safety Restraints If your vehicle has rear seats, always transport children who are 12 and younger in the rear seat. Always use safety belts and child restraints properly. If a child in a rear facing infant seat must be transported in front, the passenger air bag must be turned OFF.
Page 89 Seating and Safety Restraints • the child has a medical condition which, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can constantly monitor the child’s condition. 3. Medical condition. A passenger has a medical condition which, according to his or her physician: •...
Page 90: Child Restraints
Seating and Safety Restraints • the child has a medical condition that, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can monitor the child’s condition. 3. Medical condition: A passenger has a medical condition that, according to his or her physician: •...
Page 91 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 92 Seating and Safety Restraints Booster seats should be used until you can answer YES to ALL of these questions: • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? •...
Page 93 Seating and Safety Restraints The shoulder belt should cross the chest, resting snugly on the center of the shoulder. The lap belt should rest low and snug across the hips, never up high across the stomach. If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition.
Page 94 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with a tether anchor.
Page 95 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts 1. Position the child safety seat in a seat with a combination lap and shoulder belt. Air bags can kill or injure a child in a child seat. Never place a rear facing child seat in front of an active bag.
Page 96 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 97 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 98 Seating and Safety Restraints The SuperCab rear seat has three straps behind the top of the seat back that function as both routing loops for the tether straps and anchor loops. The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown.
Page 99 Seating and Safety Restraints installing the child seat. Refer to the Folding down the rear seats section in this chapter for information on how to operate the rear seats. 5. Clip the tether strap to the anchor as shown. • Front seat (SuperCab only) •...
Page 100 Seating and Safety Restraints Many tether straps cannot be tightened if the tether strap is hooked to the loop directly behind the child seat. To provide a tight tether strap: 1. Route the tether strap through the loop directly behind the child seat.
Page 101: Driving
STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. For vehicle equipped with a manual transmission, you must depress the ignition release lever to release the key.
Page 102 Driving Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 103 If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: 1. Make sure the parking brake is set.
Page 104 Driving • Turn the key to 4 (ON) without turning the key to 5 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate.
Page 105: Brakes
Using the engine block heater (if equipped) Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23° C (-10° F) or below. For best results, plug the heater in at least three hours before starting the vehicle.
Page 106 Driving emergency stops by keeping the rear brakes from locking. The front wheels, however, may still lock since they are not controlled by the RABS. Noise from the ABS pump motor and brake pedal pulsation may be observed during ABS braking; this is normal. RABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position.
Page 107 Using ABS When hard braking is required, apply continuous force on the brake pedal; do not pump the brake pedal since this will reduce the effectiveness of the ABS and will increase your vehicle’s stopping distance. The ABS will be activated immediately, allowing you to retain full steering control during hard braking and on slippery surfaces.
Page 108 Driving hold the brake pedal down, release the parking brake, then try pushing the parking brake pedal further down. Chock the wheels if required. If the parking brake cannot hold the weight of the vehicle, the parking brake may need to be serviced. STEERING To prevent damage to the power steering system: •...
Page 109: Transmission Operation
Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 110 Driving Do not drive your vehicle until you verify that the brakelamps are working. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 111 N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. by pressing the transmission control switch on the end of the gearshift lever.
Page 112 Driving Forced downshifts • Allowed in (Overdrive) or Drive. • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. Shift strategy (4R100 automatic transmission) To account for customer driving habits and conditions, your 4R100 automatic transmission electronically controls the shift quality by using an adaptive learning strategy.
Page 113 To start the vehicle: 1. Make sure the parking brake is fully set. 2. Press the clutch pedal to the floor, then put the gearshift lever in the neutral position. 3. Start the engine, then press the brake pedal and release the parking brake.
Page 114 Driving Parking your vehicle 1. Apply the brake and shift into the neutral position. 2. Fully apply the parking brake, then shift into 1 (First). 3. Turn the ignition off. Do not park your vehicle in Neutral, it may move unexpectedly and injure someone.
Page 115 Driving The RSS detects obstacles up to 2 meters (6 ft.) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.
Page 116 Driving FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. Four–wheel drive (4WD) supplies power to all four wheels. 4WD should not be operated on dry pavement; driveline damage may occur. If equipped with the Electronic Shift 4WD System, and 4WD Low is selected while the vehicle is moving, the 4WD system will not engage.
Page 117 Engage or disengage the 4WD system by: • rotating the control for both front wheel hub locks from the FREE or LOCK position, then • manually engage or disengage the transfer case with the floor-mounted shifter For increased fuel economy in 2WD, rotate both hub locks to the FREE position.
Page 118 Driving Note: Do not perform this operation if the rear wheels are slipping. Shifting to/from 4L (4WD Low) 1. Bring the vehicle to a complete stop. 2. Depress the brake. 3. On vehicles equipped with an automatic transmission, place the transmission in N (Neutral);...
Page 119 4X4 LOW (4WD Low) - Uses extra gearing to provide maximum power to all four wheels. Intended only for off-road applications such as deep sand, steep grades or pulling heavy objects. 4L (4WD Low) will not engage while the vehicle is moving; this is normal and should be no reason for concern.
Page 120 Driving Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps. You should either know the terrain or examine maps of the area before driving. Map out your route before driving in the area. To maintain steering and braking control of your vehicle, you must have all four wheels on the ground and they must be rolling, not sliding or spinning.
Page 121 If your vehicle gets stuck If your vehicle gets stuck in mud or snow it may be rocked out by shifting between forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 122 Driving Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 123 Driving sounds. This is the front drivetrain coming up to speed and the automatic locking hubs engaging and is not cause for concern. Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain.
Page 124 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 125 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 126 If you nevertheless decide to equip your 4WD for off-road use with tires larger than what Ford Motor Company recommends, you should not use these tires for highway driving. If you use any tire/wheel combination not recommended by Ford Motor Company, it may adversely affect vehicle handling and could cause steering, suspension, axle or transfer case failure.
Page 127 For this reason, Ford Motor Company strongly recommends that you do not make modifications such as adding or removing parts (such as lift kits or stabilizer bars) or by using replacement parts not equivalent to the original factory equipment.
Page 128 Driving The PTO can be used during mobile and stationary continuous/intermittent applications. PTO operation is disabled while the vehicle is in Overdrive (the TCIL will not be illuminated), in N (Neutral), during engine cranking. Transmission upshift and downshift schedules will be reduced by about 15% and will have a firmer shift feel during PTO mobile applications.
Page 129 • GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system. The GAWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. • GCW (Gross Combined Weight): The combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer.
Page 130: Trailer Towing
Driving Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in this chapter. Loaded vehicles may handle differently than unloaded vehicles. Extra precautions, such as slower speeds and increased stopping distance, should be taken when driving a heavily loaded vehicle.
Page 131 Note: Do not exceed the GVWR or the GAWR specified on the certification label. Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury.
Page 132 Driving F-250 Regular Cab Pickup Engine Rear axle ratio 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel)
Page 133 F-250 SuperCab Pickup Engine Rear axle ratio 4x2 with manual transmission 6.8L (with 4.30 fifth wheel) 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with manual transmission 5.4L 3.73 5.4L...
Page 134 Driving F-250 Crew Cab Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel)
Page 135 F-250 Crew Cab Pickup Engine Rear axle ratio 4x4 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) F-350 Regular Cab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L 3.73 5.4L...
Page 136 Driving F-350 Regular Cab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L...
Page 137 F-350 Regular Cab Dual Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30...
Page 138 Driving F-350 Regular Cab Dual Rear Wheel Pickup Engine Rear axle ratio 4x4 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) F-350 SuperCab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L...
Page 139 F-350 SuperCab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without...
Page 140 Driving F-350 SuperCab Dual Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30...
Page 141 F-350 SuperCab Dual Rear Wheel Pickup Engine Rear axle ratio 4x4 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) F-350 Crew Cab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 5.4L...
Page 142 Driving F-350 Crew Cab Single Rear Wheel Pickup Engine Rear axle ratio 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L...
Page 143 F-350 Crew Cab Dual Rear Wheel Pickup Engine Rear axle ratio 4x2 with manual transmission 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x2 with automatic transmission 6.8L 3.73 6.8L 4.30 (without fifth wheel) 6.8L (with 4.30 fifth wheel) 4x4 with manual transmission...
Page 144 Driving F-350 Regular Chassis Cab Single Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio 4x2 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 4x4 with manual transmission 5.4L 3.73 5.4L 4.10...
Page 145 F-350 Regular Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle Maximum GCWR - ratio 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 4x4 with automatic transmission 5.4L...
Page 146 Driving F-350 SuperCab Chassis Cab Single Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio 4x4 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 4x4 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 F-350 SuperCab Chassis Cab Dual Rear Wheel (Fifth Wheel Engine Rear axle ratio...
Page 147 F-350 Crew Cab Chassis Cab Single Rear Wheel (Fifth Wheel Towing) Engine Rear axle Maximum GCWR - ratio 4x2 with manual transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 4x2 with automatic transmission 5.4L 3.73 5.4L 4.10 6.8L 3.73 4x4 with manual transmission 5.4L 3.73 5.4L...
Page 148 Driving F-350 Crew Cab Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio 4x4 with manual transmission 6.8L 3.73 6.8L 4.30 4x4 with automatic transmission 6.8L 3.73 6.8L 4.30 F-450 Regular Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio...
Page 149 F-450 SuperCab Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle Maximum GCWR - ratio 4x2 with manual transmission 6.8L 4.88/5.38 4x2 with automatic transmission 6.8L 4.88 6.8L 5.38 4x4 with manual transmission 6.8L 4.88/5.38 4x4 with automatic transmission 6.8L 4.88 6.8L...
Page 150 Driving F-550 Regular Cab Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio 4x2 with automatic transmission 6.8L 4.88 6.8L 5.38 4x4 with automatic transmission 6.8L 4.88 6.8L 5.38 F-550 SuperCab Chassis Cab Dual Rear Wheel (Fifth Wheel Towing) Engine Rear axle ratio...
Page 151 Driving Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. See your dealer or a reliable trailer dealer if you require assistance. Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle.
Page 152 Driving Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 153 • Maximum distance is 80 km (50 miles). If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 154 Note: Ford does not install snowplows. For low speed snow removal, Ford offers a Snowplow Package Option on select 4x4 vehicles. To assist Ford dealers and equipment installers further prepare the vehicle for snowplowing, Ford includes instructions in the Ford Truck Body Builders Layout Book and Ford Truck Source Book.
Page 155 Installing the snowplow Read the following instructions before installing a snowplow: • Front GAWR must not exceed 63% of the GVW. Add ballast weight to the back of the vehicle, if necessary. Refer to the Safety Compliance Certification Label to find your vehicle’s front GAWR. •...
Page 156 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Additional equipment such as snowplow equipment may effect the performance of the air bag sensors increasing the risk of injury.
Page 157 4WD operation while plowing • Shift transfer case to 4x4 LOW (4WD Low) when plowing in small areas at speeds below 8 km/h (5 mph). • Shift transfer case to 4x4 HIGH (4WD High) when plowing larger areas or light snow at higher speeds. Do not exceed 24 km/h (15 mph).
Page 158: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 159 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673;...
Page 160: Fuses And Relays
Roadside Emergencies This switch is located in the passenger’s footwell, by the kick panel. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
Page 161 Standard fuse amperage rating and color Fuse Mini Standard rating fuses fuses Grey Grey Violet Violet Pink Pink 7.5A Brown Brown Blue Blue Yellow Yellow Natural Natural Green Green — — — — — — — — — — Passenger compartment fuse panel / power distribution box The fuse panel is located below and to the left of the steering wheel by the brake pedal.
Page 162 Roadside Emergencies To remove a fuse use the fuse puller tool provided on the fuse panel cover. The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating 15A* Adjustable pedals — Not used — Not used 20A* Power point - instrument panel —...
Page 163 Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating 20A* Cigar lighter / OBD II Power mirrors/switches 15A* Daytime running lamps (DRL) — Not used — Not used 15A* Exterior lamps 20A* Turn lamps/Brake on-off switch (high) 10A* Body security module/4x4 module —...
Page 164 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — Not used 20A* Fuel pump 10A* Instrument cluster 15A* Delayed accessory 10A* Fog lamps — Not used 10A* Ignition switch Run/Start feed 10A* Left-hand lowbeam 10A* Right-hand lowbeam — Not used 30A** Trailer tow electric brake 30A** Door locks/Body security module...
Page 165 Fuse/Relay Fuse Amp Location Rating — Not used — Front blower motor relay — Powertrain (EEC) relay — Injector driver module relay (Diesel engine only) — Not used — Trailer tow battery charge relay — Delayed accessory relay — Starter relay * Mini Fuses ** Maxi Fuses ***Circuit Breaker CHANGING A FLAT TIRE If you get a flat tire while driving:...
Page 166 Roadside Emergencies If your vehicle is equipped with a tire pressure monitoring system, refer to Tire Pressure Monitoring System (if equipped) in the Maintenance and specifications section for important information before changing your tires. If the tire pressure monitoring system becomes damaged, it will no longer function.
Page 167 2. Attach the spare tire lock key (A) to the jack handle (B). 3. Fully insert the jack handle through the bumper hole and into the guide tube. The key and lock will engage with a slight push and counterclockwise turn. Some resistance will be felt when turning the jack handle assembly.
Page 168 Roadside Emergencies To prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 169 Roadside Emergencies The following steps apply to F250/F350 only: 6. Insert the hooked end of the jack handle into the jack and use the handle to slide the jack under the vehicle. 7. Position the jack according to the following guides: •...
Page 170 Roadside Emergencies • Rear Never use the front or rear differential as a jacking point. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
Page 171 Roadside Emergencies The following steps apply to F350 Chassis Cab F450/F550 only: 12. Slide the notched end of the jack handle over the release valve and use the handle to slide the jack under the vehicle. Make sure the valve is closed by turning it clockwise.
Page 172 Roadside Emergencies • Front passenger side (4x4) • Rear 14. Insert the jack handle into the pump linkage. 15. Use an up-and-down motion with the jack handle to raise the wheel completely off the ground. Hydraulic jacks are equipped with a pressure release valve that prevents lifting loads which exceed the jack’s rated capacity.
Page 173 M14 x 1.5 200-225 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On all two-piece flat wheel nuts, apply one drop of motor oil between the flat washer and the nut. Do not apply motor oil to the wheel nut threads or the wheel stud threads.
Page 174: Jump Starting
Roadside Emergencies Stowing the flat/spare tire 1. Lay the tire on the ground with the valve stem facing in the direction specified on the Tire Changing Instructions located with the jack hardware. 2. Slide the wheel partially under the vehicle and install the retainer through the wheel center.
Page 175 Roadside Emergencies 1. Use only a 12–volt supply to start your vehicle. 2. Do not disconnect the battery of the disabled vehicle as this could damage the vehicle’s electrical system. 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch.
Page 176 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 177 Roadside Emergencies 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected.
Page 178 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 179: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. On 4x2 vehicles, it is acceptable to tow the vehicle with the front wheels on the ground and the rear wheels off the ground using a wheel lift or a slingbelt with T-hooks.
Page 180 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 181: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 182 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business) •...
Page 183 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 184 Customer Assistance • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
Page 185 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 186 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 187 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 188 Customer Assistance If you are in another foreign country, contact the nearest Ford dealership. If the dealership employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 189: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (or 366–0123 in the Washington D.C.
Page 190: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 191 • Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. • To remove tar and grease, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA), available from your dealer. ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal.
Page 192 Use only approved products to clean plastic parts. These products are available from your dealer. • For routine cleaning, use Detail Wash (ZC-3–A). • If tar or grease spots are present, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA). WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly.
Page 193 For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 194 FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 195 Cleaning Motorcraft Carlite Glass Cleaner (Canada only) (CXC-100) Motorcraft Spot and Stain Remover (ZC-14) Motorcraft Tire Detailer (ZC-28) Motorcraft Triple Clean (ZC-13) Motorcraft Ultra-Clear Spray Glass Cleaner (not available in Canada) (ZC-23) Motorcraft Engine Shampoo and Degreaser (ZC-20) * May be sold with the Motorcraft name...
Page 196: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 197 Maintenance and Specifications Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral).
Page 198: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 5.4L V8/6.8L V10 gasoline engines Refer to the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for diesel engine component locations. 1. Engine oil dipstick 2. Clutch fluid reservoir (manual transmission) 3.
Page 199: Engine Oil
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 200 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 201 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 202: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 203 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 204 Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.
Page 205 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 206 • Do not add extra inhibitors or additives to the coolant. These can be harmful and compromise the corrosion protection of the engine coolant. • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled engine coolant section).
Page 207 Maintenance and Specifications For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool. Add the proper mixture of coolant and water to the “cold full” level. For all other vehicles, which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant.
Page 208 Maintenance and Specifications Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 209 Maintenance and Specifications • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage. • Decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage.
Page 210 Maintenance and Specifications Once the engine temperature cools, the engine can be re-started. Take your vehicle to a service facility as soon as possible to minimize engine damage. When fail-safe mode is activated You have limited engine power when in the fail-safe mode, so drive the vehicle with caution.
Page 211 Maintenance and Specifications Automotive fuels can cause serious injury or death if misused or mishandled. Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle.
Page 212 Maintenance and Specifications When refueling always shut the engine off and never allow sparks or open flames near the filler neck. Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container.
Page 213 Maintenance and Specifications be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 214 World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 215 Maintenance and Specifications Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
Page 216 Maintenance and Specifications • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in kilometers or miles).
Page 217 Maintenance and Specifications • Revving the engine before turning it off may reduce fuel economy. • Using the air conditioner or defroster may reduce fuel economy. • You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs.
Page 218 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 219 Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 220 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. Check the fluid level when it is at ambient temperature, 20° – 80° F (-7°...
Page 221 CLUTCH FLUID (IF EQUIPPED) Check the clutch fluid level. Refer to the scheduled maintenance guide for the service interval schedules. Use only a DOT 3 brake fluid designed to meet Ford specification ESA-M6C25–A. Refer to Lubricant Specifications in this chapter.
Page 222 Maintenance and Specifications Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes. Seek medical if irritation persists. If taken internally, drink water and induce vomiting. Seek medical attention immediately. During normal operation, the fluid level in the clutch reservoir should remain constant or rise slightly.
Page 223 Maintenance and Specifications operated for an extended period at high speeds, in city traffic during hot weather or pulling a trailer, the vehicle should be turned off for about 30 minutes to allow fluid to cool before checking. 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature.
Page 224 Maintenance and Specifications The transmission fluid should be in this range if at normal operating temperature (66°C-77°C [150°F-170°F]). The transmission fluid should be in this range if at ambient temperature (10°C-35°C [50°F-95°F]). High fluid level Fluid levels above the safe range may result in transmission failure.
Page 225 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter.
Page 226 Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 227: Air Filter(S)
Maintenance and Specifications Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running. Changing the air filter element (gasoline engines only) 1. Loosen the clamp that secures the air filter element in place. 2.
Page 228 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 229 Maintenance and Specifications which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
Page 230 Maintenance and Specifications Tire inflation information The F450 and F550 vehicles are equipped with a tire that is an all-steel radial. All-steel radial tires utilize steel cords in the sidewalls, and also require increased inflation pressures of up to 95 psi. As such, they cannot be treated like normal light truck tires.
Page 231 Maintenance and Specifications • Four tire rotation • Five tire rotation...
Page 232 Maintenance and Specifications • DRW – Six tire rotation If you vehicle is equipped with dual rear wheels it is recommended that front and rear tires (in pairs) be rotated only side to side, with the rear tires maintaining original vehicle position.
Page 233 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, “Touring”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires.
Page 234: Part Numbers
*Refer to the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for Motorcraft diesel engine service part numbers. **Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Ford Part Fluid Name Front axle Hypoid Gear Oil SAE 90...
Page 235 Maintenance and Specifications Ford Part Fluid Name Brake fluid (and Motorcraft High clutch fluid-if Performance equipped) DOT 3 Motor Vehicle Brake Fluid Engine coolant Motorcraft Premium Engine Coolant (green-colored) or Motorcraft Premium Gold Engine Coolant (yellow-colored) Engine oil Motorcraft SAE...
Page 236 The axle lubricant should be changed any time the rear axle has been submerged in water. Add 236 ml (8 oz.) of Additive Friction Modifier XL-3or equivalent meeting Ford Specification EST-M2C118-A for complete refill of Traction-Lok axles. Application...
Page 237: Lubricant Specifications
The amount of transmission fluid and fluid level should be set by the indication on the dipstick’s normal operating range. LUBRICANT SPECIFICATIONS Ford part Item name or equivalent High...
Page 238 Maintenance and Specifications Ford part Item name or equivalent Motorcraft SAE 75W-140 High Performance Synthetic Rear Axle Lube Motorcraft SAE 75W-90 Rear axle Synthetic Rear Axle Lubricant Motorcraft SAE 80W-90 Premium Rear Axle Lubricant (Dana 135 axles) Motorcraft High Brake fluid and...
Page 239 Motorcraft Premium Windshield Windshield washer fluid Washer Concentrate Add 236 ml (8 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118-A for complete refill of Ford part Ford number specification XG—4 or XL-5 ESR-M1C159-A ESB-M1C93–B XL-1...
Page 240 Maintenance and Specifications Traction-Lok axles. Ford design rear axles contain a synthetic lubricant that does not require changing unless the axle has been submerged in water. Dana rear axles also contain a synthetic lubricant but do require a change. Refer to your “Service Guide” for change intervals on Dana rear axles.
Page 241 Maintenance and Specifications VEHICLE DIMENSIONS F250–Regular and Super Cab Dimension Regular Cab 4x2 (1) Overall 1935 mm 2 005 mm height (76.2 in) (78.9 in) (2) Track 1 736 mm 1 736 mm (Front / (68.3 in) / (68.3 in) / Rear) 1 729 mm 1 729.3 mm...
Page 242 Maintenance and Specifications F250-Crew Cab Dimension Crew Cab 4x2/ Short (1) Overall 1960 mm 2 027 mm height (77.2 in) (79.8 in) (2) Track 1 736 mm 1 736 mm (Front / (68.3 in) / (68.3 in) / Rear) 1 729 mm 1 729 mm (68.1 in) (68.1 in)
Page 243 Maintenance and Specifications F350–except Crew Cab Dimension Chassis Chassis Cab — Cab — Regular Super Cab (1) Overall 1 924 mm 1 928 mm height (75.7 in) (75.9 in) 1 912 mm 1 931 mm (75.2 in) (76.0 in) 2 028 mm 2 029 mm (79.8 in) (79.9 in)
Page 244 Maintenance and Specifications Dimension Chassis Chassis Cab — Cab — Regular Super Cab 3 576 mm 4 110 mm Wheelbase (140.8 in) (161.8 in) 4 186 mm (164.8 in) (5) Overall 5 733 mm 6 267 mm length (225.7 (246.7 in) a,b,c,d 6 343 (249.7 4x2 Single rear wheel (SRW)
Page 245 Maintenance and Specifications Dimension Crew chassis (2b) Track — 1 729 mm Rear (68.1 in) 1 803 mm (74.0 in) (3) Overall 2 031 mm width (79.9 in) 2 304 mm (90.7 in) 2 329 mm (91.7 in) (4) Wheelbase 4 475 mm (176.2 in ) (5) Overall...
Page 246 Maintenance and Specifications Dimension Regular Regular Chassis 4x2 Chassis 4x4 (2) Track 1 736 mm 1 736 mm (Front / (68.4 in) / (68.4 in) / Rear) 1 880 mm 1880 mm (74.0 in) (74.0 in) (3) Overall 2 377 mm 2 377 mm width (93.6 in)
Page 247 Maintenance and Specifications F550 Dimension Regular Regular Chassis Chassis Cab 4x2 Cab 4x4 (1) Overall 2 076 mm 2 075 mm height (81.7 in) (81.7 in) 2 068 mm 2 063 mm (81.4 in) (81.2 in) 2 059 mm 2 059 mm (81.1 in) (81.1 in) 2 049 mm...
Page 248 Maintenance and Specifications Dimension Regular Regular Chassis Chassis Cab 4x2 Cab 4x4 (5) Overall 5 733 mm length (225.7 in) (225.7 in) 6 343 mm (249.7 in) (249.7 in) 6 952 mm (273.7 in) (273.7 in) 7 257 mm (285.7 in) 3 576 mm (140.8 in) wheel base 4 186 mm (164.8 in) wheel base 4 795 mm (188.8) wheel base...
Page 249 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 250 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 251: Accessories
Accessories FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 252 Accessories Travel equipment Adjustable Towing System Auto headlamp system with Daytime Running Lights (DRL) Bed Tent Box Aluminum Rack cargo storage systems Daytime running lights (DRL) Electrochromic inside mirror with compass Electrochromic inside mirror with compass and temperature display Fog lights Battery Warmer Highway safety and first aid kit Off road lights...
Page 253 Accessories Carpet floor mats Cap (hard, color keyed – Leer supplier branded) Cap (commercial – Leer supplier branded) Cleaners, waxes and polishes Diamond plate bed rail caps Diamond plate front box protection Diamond plate splash guards Diamond plate tool box Door edge guards Fender flares Flat splash guards...
Page 254 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 255: Index
Accessory delay ...48 Air bag supplemental restraint system ...82 and child safety seats ...83 description ...82 disposal ...86 driver air bag ...84 indicator light ...85 operation ...84 passenger air bag ...84 passenger deactivation switch ...86 Air cleaner filter ...226–227, 234 Ambulance packages ...6 Antifreeze (see Engine coolant) ...204...
Page 256 ...68 Coolant checking and adding ...204 refill capacities ...208, 234 specifications ...237, 240 Customer Assistance ...158 Ford accessories for your vehicle ...194 Ford Extended Service Plan ...183 Getting assistance outside the U.S. and Canada ...187 Getting roadside assistance ...158 Getting the service you need ...181...
Page 257 refill capacities ...234 specifications ...237, 240 Exhaust fumes ...105 Fail safe cooling ...209 Fluid capacities ...234 Foglamps ...37 Four-Wheel Drive vehicles ...116 driving off road ...119 electronic shift ...118–119 indicator light ...116 lever operated shift ...117 manual locking hubs ...116 preparing to drive your vehicle ...108 Fuel ...210...
Page 258: Message Center
Index Instrument panel cleaning ...193 cluster ...10 lighting up panel and interior ...38 Jump-starting your vehicle ...174 Keyless entry system autolock ...63 Keys positions of the ignition ...101 Lamps autolamp system ...36 bulb replacement specifications chart ...39 cargo lamps ...38 daytime running light ...37 fog lamps ...37 headlamps ...36...
Page 259 fluid, specifications ...237, 240 Preparing to drive your vehicle ...108 Radio ...17, 19, 22, 26 Relays ...160 Remote entry system ...60 illuminated entry ...63 locking/unlocking doors ...58 Reverse sensing system ...114 Roadside assistance ...158 Safety belts (see Safety restraints) ...70–73, 75 Safety defects, reporting ...189 Safety restraints ...70–75 belt minder ...77...
Page 260 Index fluid, checking and adding (manual) ...225 fluid, refill capacities ...234 lubricant specifications ..237, 240 manual operation ...112 Turn signal ...38 Vehicle dimensions ...241 Vehicle Identification Number (VIN) ...250 Vehicle loading ...128 Ventilating your vehicle ...105 Warning lights (see Lights) ...10 Washer fluid ...199 Water, Driving through ...128 Windows...
