Syntax SV266A User Manual page 59

Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART Mode Select
UR2 Duplex Mode
Onboard Parallel Port
Parallel Port Mode
ECP Mode Use DMA
Game Port Address
Midi Port Address
Midi Port IRQ
↑ ↑ ↑ ↑ ↓ ↓ ↓ ↓ → → → → ← ← ← ← : Move
Exit F1:General Help
F7:Optimized Defaults
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port 1 (3F8/IRQ4)
This option is used to assign the I/O address and interrupt request (IRQ) for
the onboard serial port 1 (COM1).
Onboard Serial Port 2 (2F8/IRQ3)
This option is used to assign the I/O address and interrupt request (IRQ) for
the onboard serial port 2 (COM2).
UART Mode Select (Normal)
This field is available if the Onboard Serial Port 2 field is set to any option but
Disabled. UART Mode Select enables you to select the infrared communica-
tion protocol: Normal (default), IrDA, or ASKIR. IrDA is an infrared communi-
cation protocol with a maximum baud rate up to 115.2K bps. ASKIR is Sharp's
infrared communication protocol with a maximum baud rate up to 57.6K bps.
UR2 Duplex Mode (Half)
This field is available when UART 2 Mode is set to either ASKIR or IrDA. This
item enables you to determine the infrared function of the onboard infrared
chip. The options are Full and Half (default).
Full-duplex means that you can transmit and send information simultaneously.
Half-duplex is the transmission of data in both directions, but only one direc-
tion at a time.
Onboard Parallel Port (378/IRQ7)
This option is used to assign the I/O address and interrupt request (IRQ) for
the onboard parallel port.
Parallel Port Mode (ECP)
Enables you to set the data transfer protocol for your parallel port. There are
four options: SPP (Standard Parallel Port), EPP (Enhanced Parallel Port),
ECP (Extended Capabilities Port) and ECP+EPP.
SPP allows data output only. Extended Capabilities Port (ECP) and Enhanced
Parallel Port (EPP) are bi-directional modes, allowing both data input and output.
ECP and EPP modes are only supported with EPP- and ECP-aware peripherals.
[Enabled]
[3F8/IRQ4]
Menu Level
[2F8/IRQ3]
[Normal]
[Half]
[378/IRQ7]
[ECP]
[3]
[201]
[330]
[10]
Enter : Select +/-/PU/PD:Value:
F5:Previous Values F6:Fail-Safe Defaults
39
Item Help
F10: Save ESC:
