Onboard LAN The VT6103 is a Physical Layer device for Ethernet 10BASE-T
(optional) and 100BASE-TX using category 5 Unshielded, Type 1
Shielded cables
•
•
•
•
Integrated I/O The mainboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• Two serial port
One parallel port
•
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and line-out
BIOS This mainboard uses Award BIOS that enables users to
Firmware configure many system features including the following:
• Power management
• Wake-up alarms
CPU parameters
•
• CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.

Choosing a Computer Case

Choosing a Computer Case
There are many types of computer cases on the market. The mainboard com-
plies with the specifications for the ATX system case. Some features on the
mainboard are implemented by cabling connectors on the mainboard to indi-
cators and switches on the system case. Ensure that your case supports all
the features required. The mainboard can support one or two floppy diskette
drives and four enhanced IDE drives. Ensure that your case has sufficient
power and space for all the drives that you intend to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that
the I/O template in the case matches the I/O ports installed on the rear edge
of the mainboard.
This mainboard has an ATX form factor of 305 x 244 mm. Choose a case that
accommodates this form factor.
Dual Speed – 100/10 Mbps
Half And Full Duplex
Meet All Applicable IEEE 802.3, 10Base-T and
100Base-Tx Standards
Adaptive Equalizer
