  • Page 1 Read Me Before Usage! Manual of 1502 Manual of 1502 Manual of 1502 Manual of 1502...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Content Description —1 Section 1 On-Lap Monitor and Accessories —1 Section 2 Notices of Touch Screen Monitor —2 Section 3 Safety Precautions —3 Section 4 Safety Instructions —3 Section 5 Product Maintenance —3 Section 6 LCD Pixel Statement —3 Section 7 Disposal of Electronic Equipment —4...

  • Page 3: Chapter 1 Content Description -1

    Chapter 1 Content Description Section 1 On-Lap Monitor and Accessories Parts Description Magnetic Holder Mount Fig.: 1502 parts, buttons and LED light Description Fig.: On-Lap 1502 input/ output ports...
  • Page 4 Fig.: Part description of Stand 4 Package & Accessories Accessories 1502 T 1502 I Micro HDMI Video Cable x1 No (Optional) No (Optional) VGA Video Cable x1 Micro USB to USB Touch Power Cable Yes x 1 Yes x 2 Charger (5V,Max.2A) x1...

  • Page 5: Section 3 Safety Precautions -3

    Avoid LCD monitor become exposed to direct sunlight for a long period of time, which may result in damage. When monitor displays different images, image brightness may become slightly uneven. Monitor may be broken when heavy pressure or sharp object is applied to it.

  • Page 6: Chapter 2 Installation Instructions -4

    X plate is properly inserted onto slot. Step2: Place On-Lap 1502 onto Stand 4 Place On-Lap 1502 onto Stand 4. Stand 4 is positioned at the bottom center of monitor. Section 2 Connect the Video Cable and USB Touch Output and...
  • Page 7 1 1 1 1 Connect USB Touch Output and Power Cable’s Micro USB (B type) connector to On-Lap 1502’s Micro USB port. Connect the other end, USB connector to USB port of laptop. With this connection, laptop will provide power and touch signal to On-Lap 1502.

  • Page 8: Cable

    Place On-Lap 1502 onto VESA 100 mount, secure with four screws. * If need to adjust monitor position, please use two hands to hold VESA 100 mount to adjust, do not apply force onto On-Lap 1502 body. Excessive force onto On-Lap 1502 body may result in monitor glass become broken.

  • Page 9: Power On And Off The On-Lap Monitor

    Chapter 3 Power On and Off the On-Lap Monitor Section 1 Power On and Off the On-Lap From Off state to On state: Press Power Button to activate On/Off. First time use: When Micro USB to USB touch signal and power connect to USB port on computer or 5V DC Charger, On-Lap will automatically start and detect video signal to automatically display video.

  • Page 10: Section 3 Windows 8 Touch Gesture Description -8

    Section 3 Windows 8 Touch Gesture Description Common Touch Gesture Introduction: Use finger to swipe in from edge: Swipe in from the right edge of the screen (Arrow 1) : Open the five charms – Search, Share, Start, Devices, and Settings Swipe in from the left edge of the screen (Arrow 2) : Switch between apps Swipe in from the left edge of the screen then out toward the left...

  • Page 11: Section 2 Osd Description -9

    Hot Keys Description Power: Touch the Power Button can power on/off the Monitor. Exit/Auto Adjustment: In the OSD panel, touch the Exit Button to exit and back to the previous page. When there is no OSD menu, touch this Button will activate automatic adjustment func- tion (only pertains to analog VGA signal) Increase Volume/UP: Touch this Button to in- crease the volume of speakers.
  • Page 12 Color Setting – Color Temperature adjustment Press to launch the OSD panel. Press to select , press to enter. Press to select Color temperature adjust- ment sub-menu and press to enter; press to adjust color saturation for R/G/B. → increase / decrease the red saturation of the image.

  • Page 13: Section 3 Low Power Protection Warning -11

    Menu Adjustment Press to launch the OSD panel. Press to select , press to enter. Press to select sub-menu, press to enter, press to adjust. OST Timer → adjust OSD time Language → select language Reset → restore to factory settings Version →...

  • Page 14: Section 3 Specification -12

    VGA port) USB Connector Pinout Pin No. Name Vcc(+5V) Fig .: USB Connector Ground Section 3 Specification 1502 I 1502 T 15.6” TFT IPS (LED Back- 15.6” TFT TN (LED Back- Panel type light) light) Resolution / Color 1920 x 1080 /262K colors...

  • Page 15: Section 4 Troubleshooting -13

    Check if Micro USB Touch Output and Power Cable is properly connected between the computer and On-Lap No response when finger 1502’s USB port. touches on monitor Check if Micro USB Touch Output and Power Cable is mistakenly connected to DC IN port. If so, it only power is transmitted and no touch is available.
  • Page 16 GeChic Corporation 5F-3, No. 138, Zhongming S. Rd., West Dist., Taichung, Taiwan (R.O.C.) Customer Service: service@gechic.com www.gechic.com...
