A
Hub Specifications
S
PECIFICATIONS
This appendix lists the specifications for the LinkBuilder FMS 100-TX Hub.
Physical Dimensions
Length:
Width:
Height:
Weight:
Environmental Operating Ranges
Operating temperature:
Storage temperature:
Humidity:
Altitude:
Power Requirements
AC input voltage:
Inrush current:
AC input isolation:
Power consumption:
Heat output:
User-replaceable fuse:
Repeater Classification
30.48 cm (12 in.)
43.94 cm (17.3 in.)
4.37 cm (1.72 in.)
5.5 kg (12 lb)
0˚ to 40˚ C (34˚ to 104˚ F)
–30˚ to 60˚ C (–22˚ to 140˚ F)
10% to 90% relative humidity, noncondensing
3,050 m (10,000 ft) operating
100–240 VAC, 47–63 Hz
20 A peak for 1/2 cycle @ 250 VAC
2000 VAC
40 W maximum
136.5 BTU/hr
Fast-blow 2 A, 250 V
Class I
