Canon imagePROGRAFi PF830 series Setup Manual page 5

Attach the Media Take-up Unit
Attach the media take-up unit (optional) which automatically takes up printed roll paper.
-> Refer to the Media Take-up Unit Setup Guide included with the media take-up unit
Set Up the Output Stacker
Attach the wheeled output stacker or stationary output stacker to collect ejected paper.
-> Refer to "Attach the Output Stacker" in the Printer Stand Setup Guide
Prepare to Turn the Power On
Remove the protective packaging material from the printer.
1
Remove the tape and other packaging material used to secure the
printer.
3
Use the Allen Wrench to loosen the screw of the Belt Stopper (a).
Rotate the Belt Stopper to the left and remove the stopper.
(when using the stationary output stacker or the stacker)
4
Lift the Ejection Guide.
(Option)
2
a
5
5
Open the Top Cover.
• Keep the Belt Stopper you removed
and the Allen Wrench for future use.
MEMO
You will need them in case you move
the printer to another location.
• When you open the top cover, a
cleaning brush is stored on the right
side. Take it out and use it when
cleaning inside the top cover.
Attach the four Ejection Supports (a) on the back of the Ejection
Guide.
a
