Canon imagePROGRAFi PF830 series Setup Manual page 13

4
In the Printer Selection window, select
The printer is connected to computers
in a network and click Next.
6 6
When searching the available printer on the network
Available printers are listed in the Search Results window.
Select a printer from the list on either their IPv4 Devices or IPv6 Devices
tabs and click Next.
The following step differs depending on the IP Address Status of the
selected printer.
In the case of Not Set or IP Address Overlap, proceed to step 7.
In the case of Available, the installation begins. Proceed to step 9.
7 7
When searching the available printer on the network
In the Method of Configuring IP Addresses window, select the method of configuring the IP
address as suitable for your system.
• To configure by directly entering the IP address
Select Configure manually in Method of Configuring IP Addresses and enter the IP address.
• To have the IP addresses allocated automatically using the DHCP server function
Select Configure automatically. Note that other settings outside of the procedure are also
required. ("Using DHCP", P.4)
Once you have selected the method for configuring IP addresses, enter your preferred name for
the printer in Device Name and the installation location in Printer Location under Information
About Printer to Configure, and click Install to begin the installation.
Proceed to step 9.
8 8
When entering the printer's IP address manually
In the IP Address Specification window,
select either IPv4 Address or IPv6
Address to enter the printer's IP address
and click Install.
The installation process begins.
10
In the Finish window, select Restart my
computer now and click Restart.
5 5
When searching the available printer on
the network
After reading the precautions in the
Getting Ready window, select Find
available printers in the network and
click Next.
Proceed to step 6.
MEMO
• Ask your network administrator for the
IP address, as needed.
• The IPv6 Devices tab is not displayed
in Windows XP, Windows Server 2003
MEMO
R2, and Windows Server 2003.
11
When you restart the computer, the
software settings are enabled. The
software installation is now completed.
3
When entering the printer's IP address
manually
After reading the precautions in the Getting
Ready window, select Specify the IP
address of available printers in the
network and click Next.
Proceed to step 8.
• The IPv6 Devices tab is not displayed in Windows XP, Windows
Server 2003 R2, and Windows Server 2003.
• If the printer you want to use is not displayed in the list on the IPv6
Devices tab, connect via IPv4 instead.
• If the printer you want to use is not displayed in the list of printers on
the IPv4 Devices tab, refer to "When the printer cannot be found on
the network" on page 4 to setup and configure an IP address for the
printer.
9
After reviewing the installation results in
the Complete Installation window, click
Next.
