5.1 Part Identification
The key number in diagram 5.1 and the first column of the list
will help identify the spare part.
5.2 Ordering
When ordering any spare part, please quote the part number
and the description from the list together with the model name
and serial number information from the data label.
The data label is positioned on the inner case cover, see
diagram 6.1 Installation Instructions.
Key No. Part No
1 452316
2 205733
3 202631
4 202632
5 800745
6 432868
7 800134
8 202253
9 202250
10 202251
11A 800504
11 800504
12 800136
13 202240
14 202226
15 800345
16 800744
17 204536
18 800153
19 800149
20 208214
21 800322
22 202252
221422A
Supplied By www.heating spares.co Tel. 0161 620 6677

5 Spare Parts

Description
Fan assembly
Main injector assembly (75e)
Spark electrode
Sensing electrode
Boiler over heat cut off assy
DHW high limit control assy
Pressure gauge assembly
Control board
Central heating selector switch
Control reset switch
Thermistor assembly-Domestic
Thermistor assembly-Heating
DHW switch assembly
Fuse 2 T(630 mA) - not illustrated
Fuse 1 (2AT) - not illustrated
Water pressure switch assembly
Gas valve
Air pressure switch assy
Automatic air vent assembly
Safety valve assembly
Water inlet filter
Transformer
C.V.I. Ignition module
