Summary of Contents for Monte Carlo Fan Company 5WF52XXD Series
- Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions Total fan weight with light kit For 5WF52XXD Series Fans READ AND SAVE THESE INSTRUCTIONS UALITY EILING FANS...
-
Page 2: Tools Required
Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower, it must be marked as appropriate for the application. - Page 3 Hang assembled fan from the mounting bracket installed to ceiling in previous steps. Make sure the fan is hanging straight. Rotate fan until the tab on the Mounting bracket engages the slot on the Downrod Ball. This must be done to prevent the fan body from rotating when the blades are in motion.
- Page 4 Locate blue and white wire from the fan marked “For light kit”. Connect blue from fan to black from light and white from fan to white from light by pushing connectors together. Attach switch cap to fan by lining up 3 screw holes and twisting cap clock- wise.
- Page 5 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
