- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weigh with light For 5WCR56XXD Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
- Page 2 WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced.
- Page 3 Tighten 2 downrod set screws and lock nuts. Install top decorative cover over downrod onto fan body. Then install yoke cover. Loosen set screw that holds ball. Remove keeper from cross pin and then cross pin from yoke. Replace keeper on cross pin and save.
- Page 4 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Install remote receiver by sliding into opening in the Mounting bracket.
- Page 5 To control fan speed select from High, Medium or low speed buttons. To turn the fan off press the Fan on / off button. To dim upper lights press and hold U/L botton. To dim Lower lights press and hold D/L button. To turn off either up or down light press and quickly release either U/L or D/L button.
- Page 6 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
- Page 7 6/21/06 REV.0 New made from 5GMR manual...
