InFocus IN226ST User Manual page 19

SVGA/XGA
Diagonal length
(inch) size of
(m)
4:3 Screen
Width
30.00 0.61
40.00 0.81
60.00 1.22
70.00 1.42
80.00 1.63
90.00 1.83
100.00 2.03
120.00 2.44
150.00 3.05
180.00 3.66
250.00 5.08
300.00 6.10
WXGA
Diagonal length
(inch) size of
(m)
16:10 Screen
Width
30.00 0.65
40.00 0.86
60.00 1.29
70.00 1.51
80.00 1.72
90.00 1.94
100.00 2.15
120.00 2.58
150.00 3.23
180.00 3.88
250.00 5.38
300.00 6.46
This table is for user's reference only.
Screen Size W x H
(inch)
Height Width Height
0.46 24.00 18.00
0.61 32.00 24.00
0.91 48.00 36.00
1.07 56.00 42.00
1.22 64.00 48.00
1.37 72.00 54.00
1.52 80.00 60.00
1.83 96.00 72.00
2.29 120.00 90.00
2.74 160.00 120.00
3.81 200.00 150.00
4.57 240.00 180.00
Screen Size W x H
(inch)
Height Width Height
0.40 25.43 15.90
0.54 33.91 21.19
0.81 50.87 31.79
0.94 59.34 37.09
1.08 67.82 42.39
1.21 76.30 47.69
1.35 84.78 52.99
1.62 101.73 63.58
2.02 127.17 79.48
2.42 152.60 95.38
3.37 211.95 132.47
4.04 254.33 158.96
Installation
Projection Distance (D)
(m) (feet)
wide tele wide
1.19 1.31 3.90
1.58 1.75 5.20
2.38 2.62 7.80
2.77 3.06 9.10
3.17 3.50 10.40
3.57 3.93 11.70
3.96 4.37 13.00
4.75 5.24 15.60
5.94 6.55 19.50
7.92 8.74 25.99
9.91 10.92 32.49
11.89 13.11 38.99
Projection Distance (D)
(m) (feet)
wide tele wide
1.00 1.10 3.26
1.33 1.47 4.35
1.99 2.21 6.53
2.32 2.58 7.62
2.65 2.95 8.70
2.99 3.31 9.79
3.32 3.68 10.88
3.98 4.42 13.06
4.98 5.52 16.32
5.97 6.63 19.58
8.29 9.21 27.20
9.95 11.05 32.64
Offset (Hd)
tele (m) (inch)
4.30 0.07 2.70
5.73 0.09 3.60
8.60 0.14 5.40
10.03 0.16 6.30
11.46 0.18 7.20
12.90 0.21 8.10
14.33 0.23 9.00
17.20 0.27 10.80
21.49 0.34 13.50
28.66 0.46 18.00
35.82 0.57 22.49
42.99 0.69 26.99
Offset (Hd)
tele (m) (inch)
3.62 0.05 1.99
4.83 0.07 2.65
7.25 0.10 3.97
8.46 0.12 4.64
9.66 0.13 5.30
10.87 0.15 5.96
12.08 0.17 6.62
14.50 0.20 7.95
18.12 0.25 9.93
21.75 0.30 11.92
30.20 0.42 16.56
36.24 0.50 19.87
