Gigaset AL140/AL145
Please note:
New messages in the calls list/
answer machine (network mail-
box) list (page 5) are indicated
by a flashing icon in the display.
1 Charge status of
the battery pack
2 Internal number of
the handset
3 Display keys
4 Message key
5 Directory key
6 Control key
7 Talk key
8 End call and
On/Off key
9 Ringer on/off
(press and hold in
idle status)
10 Keypad lock on/off
(press and hold)
11 Recall key
- Confer (flash)
- Dialling pause
(press and hold)
12 Microphone
13 Alarm clock key

Safety precautions

Read this user guide and the safety precautions
W
carefully before use. Explain their contents and
the potential hazards associated with using the
telephone to your children.
Only use the mains unit supplied.
$
Only use the approved, rechargeable battery
pack, never a conventional (non-rechargeable)
battery pack, as this could result in significant
health risks and personal injury.
Batteries should not be disposed of in general
household waste. Observe the local waste dis-
posal regulations, which you can find out about
by contacting your local authority or the dealer
you purchased the product from.
The operation of medical appliances may be
affected. Be aware of the technical conditions in
your particular environment, e.g. doctor's sur-
gery.
Handset
1
2
2
11.12.
INT
MENU
3
4
5
6
7
8
9
10
11
12
13
1
Base station
V
11:56
Registration/paging key (page 7)
Display keys:
Pressing the keys launches whichever function
that appears above them in the display.
Display
icon
INT
MENU
"
U
T
˜
OK
Do not hold the rear of the handset to your ear
when it is ringing. Otherwise you risk serious
and permanent damage to your hearing.
The handset may cause an unpleasant hum-
ming noise in hearing aids.
A3 1 0 0 8 - M2 0 0 1 - R1 0 1 - 1 - UZ 1 9
Issued by
Siemens Home and Office
Communication Devices GmbH & Co. KG
Schlavenhorst 66
D-46395 Bocholt
© Siemens Home and Office
Communication Devices GmbH & Co. KG 2007
All rights reserved. Subject to availability.
Function when pressed
Call all registered handsets.
Open main/submenu (see Menu
tree, page 11).
Go back one menu level.
Scroll up/down or adjust volume
u
with
.
Move cursor to left/right with
Backspace deletes one character
at a time.
Confirm menu function or save
entry.
u
.

Advertisement

loading

  Also See for Siemens Gigaset AL140

  Summary of Contents for Siemens Gigaset AL140

  • Page 1: Safety Precautions

    D-46395 Bocholt © Siemens Home and Office The operation of medical appliances may be affected. Be aware of the technical conditions in Communication Devices GmbH & Co. KG 2007 your particular environment, e.g.
  • Page 2: Setting Up The Telephone For Use

    Use only the rechargeable battery pack rec- reduced when just one handset is registered to the ommended by Siemens (page 8), i.e. never use a base station and the handset is in the base station. conventional (non-rechargeable) battery pack as...
  • Page 3: Making External Calls And Ending Calls

    ◆ Place the leads in the lead guides. already been registered), handset number four is deregistered and overwritten. Please note: If you have acquired additional handsets in this Gigaset family or other Gigaset handsets, each handset must be registered to your base station in order for them to work properly, see also page 7! Charging the battery pack To charge the battery pack, leave the handset in...
  • Page 4: Calling Line Identification

    Calling Line Identification ◆ to scroll to the entry until the required name is selected. ◆ Enter the first character of the name or scroll to When you get a call, the caller's number will be dis- the entry with , if required.
  • Page 5: Calls List/ Answer Machine (Network Mailbox) List

    Managing entries in the last number redial list If you have requested CNIP, you Show Name can view the name and town that Press the key briefly. are registered for this phone number with your network pro- Select entry. vider. Press the display key.
  • Page 6: Operating The Answer Machine (Al145)

    Operating the answer machine Picking up a call from the answer machine You can still accept a call while the answer (AL145) machine is recording it by pressing Recording stops and you can speak to the caller. The answer machine is operated from the handset (see Menu tree, page 12).
  • Page 7: Using Several Handsets

    For automatic registration of handsets to aware of the "listening in" by a signal tone. Gigaset AL140/AL145, see page 3. Precondition: The Listening in function must be Manual registration of handsets to Gigaset AL140/ activated. AL145 ¢ Activating/deactivating internal listening in 1.
  • Page 8: Setting The Base Station

    Resetting the handset Changing pause after line seizure You can set the length of the pause inserted You can reset any individual settings and changes between pressing the talk key and sending the that you have made. Entries in the directory, the phone number.
  • Page 9: Contact With Liquid

    Questions and answers Base station power consumption AL140 AL145 If you have any questions about using your phone, In standby mode visit us at www.siemens.com/gigasetcustomercare – Handset in charging cradle approx. approx. 1.0 W 1.2 W at any time. The table below contains a list of com- –...
  • Page 10: Service (Customer Care)

    You can get assistance easily when you have technical questions or questions about how to use your device by using our online support service on the Internet at: http://www.siemens.com/gigasetcustomercare This site can be accessed at any time wherever you are. It will give you 24/7 support for all our products. It also provides a list of FAQs and answers plus user guides for you to download.
  • Page 11: Alarm Clock

    Menu tree Your phone has an extensive range of features. To return to idle status: press and hold key These are offered in the form of menus. There are two ways in which you can access a func- tion: With the phone in idle status, press (open MENU ◆...
  • Page 12 Voice Mail Set Key 1 4-1-1 Netw. Mailbx Assign key with answer machine or network mailbox (in idle (all devices) status, press and hold to dial). Netw. Mailbx: your network provider's answer machine; must be requested separately. The network mailbox can be displayed if your network provider supports this function and if key been assigned with the network mailbox.
