Page 1: User Manual
4/8/16 CHANNEL DVR SDH-C75080 SDH-C74040 User Manual SDH-B73040 SDH-B73020...
Page 2 Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user's own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
Page 3: Important Safety Instructions
overview IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water.
Page 4 8. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.) 9. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
Page 5: Before Start
• SAMSUNG retains the copyright on this manual. • This manual cannot be copied without SAMSUNG’s prior written approval. • We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of instructions mentioned in this manual.
Page 6: Table Of Contents
overview CONTENTS OVERVIEW Important Safety Instructions Before Start Contents Features Part Names and Functions (Front) Part Names and Functions (Rear) Remote Control CONNECTING WITH OTHER DEVICE installation Checking the Installation Environment Connecting External Devices Connecting the USB Connecting the Camera (SDC-9441BC) Connecting the RS-485 Device Connecting the Network LIVE...
Page 7 SEARCH & PLAY Search Playback WEB VIEWER Introducing Web Viewer Connecting Web Viewer (Windows) Using Live Viewer (Windows) Controlling a Connected PTZ Camera Using Search Viewer Viewer Setup 107 Information 108 Connecting Web Viewer (Mac) 110 Using Live Viewer (Mac) 111 Mobile Viewer BACKUP VIEWER 112 SEC Backup Viewer...
Page 8: Standards Approvals
overview FEATURES The DVR employs H.264 video encoding for 4/8/16 channel inputs and G.711 audio encoding for 4/8/16 channels while simultaneously supports hard disc recording and playback. These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video and audio data.
Page 9: Package Contents
Expansion pipe and Screw Camera Power cable 60FT: 6EA 4 splitter 1EA 24EA/24EA SDH-C75080 90FT: 2EA 8 splitter 1EA 60FT: 4EA 12EA/12EA 9 splitter 1EA SDH-C74040 60FT: 4EA 12EA/12EA 9 splitter 1EA SDH-B73040 60FT: 2EA 6EA/6EA 5 splitter 1 EA SDH-B73020 English _9...
Page 10: Part Names And Functions (Front)
overview PART NAMES AND FUNCTIONS (FRONT) SDR-C75300 SDR-C74300 SDR-B73300 DV25 LAN POWER SRN-475S Part Names Functions USB Port Connects the USB devices. Remote Control Input the remote control signal. Receiver REC : Lights on when recording is in progress. LED Indicator LAN : Displays both network connection and data transfer status.
Page 11: Part Names And Functions (Rear)
PART NAMES AND FUNCTIONS (REAR) SDR- C75300 AUDIO IN POWER CH10 CH11 CH12 CH13 CH14 CH15 CH16 AUDIO OUT CONSOLE HDMI DC 12 V RS485 VIDEO IN SDR- C74300 AUDIO IN POWER AUDIO OUT CONSOLE HDMI DC 12 V RS485 VIDEO IN SDR- B73300 AUDIO IN...
Page 12 overview Part Names Functions VGA OUT Output port for VGA video signal. DC 12V DVR power input port. NETWORK connector port. HDMI HDMI connector port. USB connector port. RS-485 Used to establish RS-485 communications. AUDIO OUT Output port (RCA jack) for the audio signal. [CONSOLE] is designed for the service repair purpose only.
Page 13: Remote Control
REMOTE CONTROL POWER Displays the Shutdown pop up screen. Starts or ends the live recording. NUMBER [0~ + 10] Used as the numeric input keys, or displays a single channel. Sets the ID of the system. Select 2 digits from 0 ~ 9 while pressing the ID Key. Displays or ends PTZ.
Page 14 overview Using the numeric buttons CHANNEL 1–9 Press each button between 1 to 9. (8CH : 8) CHANNEL 10 Press the [0] button or press [+10] button first, then press the [0] button again within 3 seconds. CHANNEL 11–16 Press the [0/+10] button first, then press any number between 1 to 6. Changing the Remote Control ID 1.
Page 15: Connecting With Other Device
[Figure 1] Life (Unit: HOURS) The followings are the recommendations when Samsung DVR is installed on a rack. [Figure 1] 1. Please ensure that the rack inside is not sealed. 2. Please ensure the air is circulated through the inlet/outlet as shown in the picture.
Page 16: Connecting External Devices
connecting with other device CONNECTING EXTERNAL DEVICES The following figures are based on Model SDR-C75300. A U D IO V ID E O IN V G A A U D IO O U T R S 4 8 P O W U S B C O N S O L E...
Page 17: Connecting The Camera (Sdc-9441Bc)
CONNECTING THE CAMERA (SDC-9441BC) Equipped with the IR LED and the illumination sensor, enables you to monitor at night as well as in daytime. The camera is suitable for both internal and external use. Please make sure not to fully expose the camera to rain. The camera must be installed under a shelter to avoid exposure to excessive rain or moisture.
Page 18 connecting with other device Connecting with DVR The following figures are based on Model SDR-C75300. A U D IO V ID EO V G A A U D IO O U T RS 48 PO W U SB CO N SO H D M LA N D C 1...
Page 19: Connecting The Rs-485 Device
CONNECTING THE RS-485 DEVICE Connect the rear [RS-485 +, –] port to the PTZ camera. You can connect and control the PTZ camera which supports the RS-485 communication. Check if the RS-485 device is compatible with the product first. RS485 Pay attention not to change the polarity (+/-) of the RS-485 device when connecting it.
Page 20 connecting with other device Connecting to the Network using the router A U D IO V ID E O IN V G A A U D IO O U T R S 4 8 P O W U S B C O N S O L E H D M...
Page 21: Live
live GETTING STARTED Starting the system 1. Connect the power cable of the DVR to the wall outlet. It takes about 10 seconds to display the start screen after booting. 2. You will see the initialization screen. The initialization process will last about 1 minute. If a new HDD is installed, the initialization process may take longer.
Page 22: Login/Locking All Buttons
live Login To access a DVR or restricted menu, you should have logged in to the DVR. 1. In live mode, right-click any area of the screen. You will see the context sensitive menu as in the right 2015-01-01 01:10:25 Scene Mode figure.
Page 23: Live Screen Configuration
LIVE SCREEN CONFIGURATION Icons on the Live Screen You can check the status or operation of the DVR with the icons on the live screen. 2015-01-01 00:00:01 CAM 01 Name Description Current Date, Time Displays the current time and date. Login Information When you are logged in, the “LOG ON”...
Page 24 live Name Description Camera Name/ Channel Displays the camera name and the changed channel, if any. Displayed in PTZ setting, and highlighted yellow if PTZ is in operation. Displays AUDIO ON/MUTE. Not displayed in video mode if deactivated. Displayed if a motion detected in the condition that the motion detection is set to Camera Operation <ON>.
Page 25 Split Mode Menu The context sensitive menu in split mode differs, depending on the login/logout status. 2015-01-01 01:10:25 Scene Mode Audio Off Freeze Stop Alarm Record Play Search Backup Main Menu Shutdown Hide Launcher Logout Menu Description Scene Mode Refer to “Live Mode”. (Page28) Audio On/Off Refer to “Audio On/Off”.
Page 26 live Single Mode Menu The single mode menu is available only in Single Mode. The context sensitive menu for the One Channel mode, in Split mode is different from that of the Single mode. 2015-01-01 01:10:25 Full Screen PTZ Control Zoom In Audio On Freeze...
Page 27: View The Launcher Menu
View the Launcher Menu The Launcher menu appears on the bottom of the live screen. 1. In Live mode, right-click to display the context menu and select <Show Launcher>. 2015-01-01 01:10:25 2. Move the cursor to the bottom and click a desired item in the Launcher menu.
Page 28: Live Mode
live LIVE MODE SDR-C75300 display Live images from 16 channels in a total of 8 layout of split screens. Switching the screen mode CH10 CH11 CH12 CH13 CH14 CH15 CH16 To switch the split mode, select a screen mode in the launcher menu, or right-click to select a screen mode in the context menu.
Page 29 CH19 In Single mode, If you have set <SEQ-Dwell Time> in “Device > Camera”, Auto Sequence will be conducted at the set CH10 CH11 CH12 CH13 interval. (Page 45) In a split mode, If you have set <Multi CH SEQ Time> in “Device > Monitor”, Auto Sequence will be conducted at the set interval.
Page 30 CH10 CH11 CH12 CH10 CH10 CH11 CH11 CH12 CH12 CH13 CH14 CH15 CH13 CH14 CH15 CH16 CH13 CH14 CH15 CH16 CH16 live CH10 CH11 CH12 Channel Setting CH10 CH13 CH14 CH13 CH14 CH15 You can display the channel in a desired area of a split screen. CH19 CH11 CH12...
Page 31: Zoom
ZOOM This is available only in Single Live mode. In Single mode, select a desired area and use the Zoom function to enlarge it twice. 1. Select <Zoom In> in the right-click menu. Press the [ZOOM] button on the remote control, or simply click < >...
Page 32: Event Monitoring
live EVENT MONITORING This will display the channel in sync with a specific event (Motion/Tampering/Video Loss) if it occurs. In “Monitor > Event Display”, set the event monitoring to ON/OFF and specify the event display time. (Page 52) • If multiple events occur simultaneously, the screen will switch to a split mode. - 2~4 events : 4-split mode - 5~9 events : 9-split mode - 10~16 events : 16-split mode...
Page 33: Main Menu
main menu You can setup the system properties, devices, and options for recording, event, backup and network. SYSTEM SETUP You can setup Date/Time/Language, Permission, System Properties and Log. Date/Time/Language You can check and setup the current Date/Time and time related properties, as well as the language used for the interface on the screen.
Page 34 main menu • Date : Sets the date that will appear on the screen. Date/Time/Language You can select the date format. Date/Time/Language Holiday • Time : Sets the time and its format that will appear on the screen. Date 2015-01-01 YYYY-MM-DD Select either one from <24 Hours, 12 Hours (AM/PM)>.
Page 35: Using The Calendar
Setting Holiday You can set specific dates to Holidays according to your preferences. Holidays are applied to <Recording Schedule> and <Alarm Schedule> too. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Date/Time/Language> window to select <Date/Time/Language>, and press the Date/Time/Language Holiday [ENTER] button.
Page 36 main menu Permission Management You can set permissions of each user over the DVR's specific function and settings. Setting the Administrator You can set and change Administrator’s ID and password. The administrator can use and set all menu items and functions. Using the mouse may help make setup easier.
Page 37: Setting The Group
Setting the Group You can create user groups and setup permissions for those user groups. You can register a user for each group in <User>. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to move to <Permission Management>, and press Permission Management Group...
Page 38 main menu To restrict the user permissions If the admin restricts all permissions of an added group, the users belonging to that group can access only the default minimum menus and can change the user’s own password only. 1. Start the DVR. If all permissions are restricted, only the Login dialog should appear.
Page 39 Setting the User Users can be added only if a group was created in <Group> menu. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to move to <Permission Management>, and press Permission Management User [ENTER] button.
Page 40 main menu Setting Permissions You can set restricted access for all general users. Items with restrictions will require logging in for use. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to move to <Permission Management>, and press Permission Management Setup...
Page 41: System Management
System Management You can check the system version, update to a newer version, as well as data backup and initialization. Checking the System Information You can check the current system version, broadcasting system, MAC address. You can update the system. Using the mouse may help make setup easier.
Page 42 main menu 6. When the updating is done, it automatically restarts. Do not turn the power off until it finishes restarting. If “Upgrade Failed” appears, retry from the step 4. When you experience continued failure, consult the service center for assistance. When you perform S/W update remotely using Smart Viewer, it may take a max of 3 minutes to complete the update since Smart Viewer popped up a confirmation message.
Page 43: Log Information
Settings You can copy and import the DVR settings by using a storage media. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to move to <System Management>, and press [ENTER] System Management button.
Page 44: Event Log
main menu Event Log Event log shows recorded events on alarms, motion detections and video loss. It also shows the log and its timestamp. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <System> window to move to <Log Information>, and press [ENTER] button.
Page 45: Setting The Device
SETTING THE DEVICE You can configure the settings of: Camera, Storage Device, Remote Device and Monitor. Camera Setting the Camera You can set Video, Audio, Channel Name and Dwell Time of a Camera. Using the mouse may help make setup easier. 1.
Page 46 main menu • Screen Setup : The video appeared on the screen may vary depending on the channel’s camera, configure the DVR display to your preferences. (Brightness)>, Select a channel and adjust the < (Contrast)>, and < (Color)> of the selected channel. <...
Page 47 Setting the PTZ To use Camera’s PTZ functions, ID and protocols of each camera and DVR should be matched. For other settings, refer to the <Remote Device> settings. (Page 51) Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Camera>, and press [ENTER] button.
Page 48: Storage Device
main menu Storage Device You can check information on storage devices. Confirming Devices You can check storage devices and their free space, usage as well as status. Devices available are HDD, and USB devices (Memory, HDD). Using the mouse may help make setup easier. 1.
Page 49 Formatting You can format a storage device. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Storage Device>, and press [ENTER] button. Storage Device Format Device HDD Alarm 2. Select <Format>. Device Select Used/Total...
Page 50 main menu HDD Alarm You can set alarm settings for HDD defects such as Check Alarm Output Port, Replace Alarm Output Port, and its duration. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Storage Device>, and press [ENTER] button.
Page 51 Remote Devices You can set the RS-485 communication for use of PTZ Camera with the DVR. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Remote Device>, and press [ENTER] button. Remote Device 2.
Page 52: Screen Setup
main menu Monitor You can configure information to be displayed and its format for Spot Out monitor. Setting the Monitor Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Monitor>, and press [ENTER] button. Monitor Monitor Mode...
Page 53 Setting the Screen Mode You can configure the Live screen and Split Screens. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Device> window to move to <Monitor>, and press [ENTER] button. Monitor Mode Monitor 2.
Page 54: Setting The Recording
main menu SETTING THE RECORDING You can setup scheduled recording, event recording and other recording related settings. Recording Schedule Make your reservation on a date and time to schedule the recording on specified time. Using the mouse may help make setup easier. 1.
Page 55: Event Record Duration
Recording Color Tags Color Part Names Functions White No Recording No schedule / event recording Orange Continuous Scheduled recording only Blue Event Event recording only Green Both(Cont&Evnt) Both scheduled / event recordings Each press of a selected cell will cycle through <No Recording>-<Continuous>-<Event>- <Both(Cont&Evnt)>.
Page 56: Record Option
main menu Setting Event Recording Properties You can set each channel’s resolution, quality and FPS for event recordings. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Record> window to move to <REC Quality & Resolution>, and press REC Quality &...
Page 57: Setting The Event
SETTING THE EVENT You can set recording options when motion, image loss detection or tampering event occurs. Motion Detection You can set target detection region and motion, as well as the alarm signal output. When the motion detection region is set, it detects motion within the area. Using the mouse may help make setup easier.
Page 58: Video Loss Detection
main menu Video Loss Detection You can set the alarm to be generated on a camera disconnection, which causes a video loss. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Event> window to move to <Video Loss Detection>, and press [ENTER] Video Loss Detection button.
Page 59: Backup
Alarm Schedule You can set the conditions and operating hours for scheduled alarms. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Event> window to move to <Alarm Schedule>, and press [ENTER] button. Alarm Schedule 2.
Page 60 Player are recommended as the media player compatible with this format In case of Windows Media Player, download the latest codec from www.windows7codecs.com and install it prior to use. - SEC : Saves data in the Samsung’s proprietary format with built-in viewer, which supports immediate playback on a PC.
Page 61: Network Configuration
It provides networked monitoring of Live screen from a remote place, and supports mail forwarding function with events. You can configure the network environment which enables such functions. Please refer to the Quick Guide enclosed when connecting a network with the wireless USB adaptor used only for Samsung DVR. Connection Mode You can set the network connection route and protocol.
Page 62 main menu Setting the Port 1. Use the up/down buttons () in <Network> window to move to <Connection Mode>, and press [ENTER] Connection Mode Port button. Interface 2. Select <Port>. Protocol Type Device Port 4520 4524 UDP Port 8000 ~ 8160 3.
Page 63 Notification In a multi-browser environment, the <HTTP Port> should be set to 80 (private port). Select one between 4505 and 4530 for RTSP • Network Overview Cable/ADSL Router (External IP: 109.112.92.133, Modem Local IP: 192.168.1.1 Internet DDNS Server (www.samsungipolis.com) DV25 DV25 LAN POWER LAN POWER...
Page 64 main menu • 1st Set Port Forwarding Setting Port Forwarding is 4520~4524 (4520, 4521, 4522, 4523, 4524) Port Forwarding is 80 SDR-C75300 SDR-C75300 192. 168. 1. 192. 168. 1. • 2nd Set Port Forwarding Setting Port Forwarding is 4525~4529 (4525, 4526, 4527, 4528, 4529) Port Forwarding is 81 SDR-C75300 SDR-C75300...
Page 65: Connecting And Setting Network
Connecting and Setting the Network Networking may differ from the connection method, check your environment before setting the connection mode. When no router is used • Static mode - Internet connection : Static PPPoE, leased line, and LAN environments allows connection between the DVR and remote user.
Page 66 main menu When a router is used To avoid IP address conflict with the DVR's static IP, check followings : • Setting the DVR with a static IP - Internet connection : You can connect the DVR to a router which is connected to an PPPoE/Cable modem or a router in a Local Area Network (LAN) environment.
Page 67: Ddns
• Setting Router’s Port Forwarding 1. Set the protocol to <TCP>. Connection Mode 2. External Port Range : Enter the TCP Port set in the Port Interface <Device Port> in <Port> menu of the connected DVR. Protocol Type If more than one DVRs are connected to the router, the Device Port 4520 4524...
Page 68: Ddns Setting
DDNS Site : iPOLiS • DDNS Settings of the Router Select the corresponding menu for the network transfer protocol of the router. • SETTING UP SAMSUNG iPOLiS DDNS Go to Your PC 1. Open your browser and go to http://www.samsungipolis.com and click <LOGIN>.
Page 69 Product ID Quick Connect Not Used DDNS Host Address http://www.samsungipolis.com/ Cancel 3. Under Product ID, enter the product ID you created on the Samsung iPOLiS website. DDNS Under Quick Connect, select <Use> and click <OK>. DDNS Site iPOLiS Server Name www.samsungipolis.com...
Page 70: Live Transfer
main menu Live Transfer Sets the quality of the image that is transferred from the DVR to the network. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Network> window to move to <Live Transfer>, and press [ENTER] button. Live Transfer The Live Transfer window appears.
Page 71: Mailing Service
Mailing Service You can send an e-mail to a DVR-registered user at a specific time interval, or if an event occurs. If an event occurs with a channel where the camera’s video is set to <OFF> or the remaining recording count is set to <OFF>, only the text notification will be sent to the applicable email address.
Page 72: Event Setting
main menu Event Setting You can set the interval and type of the event that will be sent to the user. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Network> window to move to <Mailing Service>, and press [ENTER] button. Mailing Service Event SMTP...
Page 73 Recipient Setting You can add/remove a recipient(s) to/from the specified group and edit the group if necessary. Using the mouse may help make setup easier. 1. Use the up/down buttons () in <Network> window to move to <Mailing Service>, and press [ENTER] button. Mailing Service Recipient SMTP...
Page 74: Controlling A Ptz Device
main menu CONTROLLING A PTZ DEVICE The DVR enables you to adjust the settings of a PTZ camera as well as an ordinary one to your preference. PTZ Device The PTZ device can be activated only if a channel in connection with the PTZ camera is selected. Getting started with PTZ The PTZ camera is available, only if a channel is selected, in the following way : Using the remote control buttons...
Page 75 Using the PTZ camera You can use one camera to perform all functions of PAN, TILT and ZOOM for monitoring multiple places and set the preset to your preference in a desired mode. 1. Launch the <PTZ Control> menu. 2015-01-01 01:10:25 As the <...
Page 76: Camera Setting
The camera-specific menu appears. You can configure the settings of only those cameras that support the protocols of Samsung T/E, Pelco D/P, AD and Panasonic. If you are setting Auto Pan or Pattern in the camera menu, press Camera Setup and hold the appropriate button for a certain time so that the button operation can be different from that in normal PTZ setting.
Page 77: Search & Play
search & play SEARCH You can perform the search for recorded data by the time or by the search criteria such as an event. You can access the <Search> menu directly in Live mode. 1. In Live mode, right-click any area of the screen. The Live menu appears.
Page 78: Event Search
search & play • Zoom Out : The map will switch in the reverse order of the Time Search detailed mode above. Go to First It will switch in the sequence of 4 hours - 8 hours - 16 hours 2015-01-01 Go to Last Overlapped Data List1...
Page 79: Motion Search
Motion Search If a motion is detected in each channel, you can set a desired area to perform the search. You can use the mouse to select the related items. 1. Select <Motion Search> in the <Search> menu. Motion Search 2.
Page 80: Playback
search & play PLAYBACK Play You can play data stored in the HDD and backup a desired portion of the data. Using the mouse may help make setup easier. 1. In Live mode, click <Play> in the right-click menu or <...
Page 81 Using the Playback Button Part Names Functions Play Timeline Indicates the current playback point, and can be used to move. Skip Backward Moves backward by unit time. (Move by 10 minutes) Backward Fast Used for quick backward playback. (2 - 64x speed) Play Backward Slow Used for backward frame-by-frame search while in PAUSE.
Page 82: Web Viewer
web viewer web viewer INTRODUCING WEB VIEWER What is Web Viewer? Web Viewer allows remote access to your DVRs. You have access to li ve video, archived video, PTZ control (if configured), etc. Product Features Network • Remote access from a standard browser • Supports PTZ camera controls • Supports 1, 4, 9, 16 camera viewing formats (maximum of 16 cameras in the list).
Page 83: Connecting Web Viewer (Windows)
CONNECTING WEB VIEWER (Windows) 1. Open your web browser and type the IP address or URL of DVR into the URL address box. “192.168.1.200” is set to IP by default. Set to an available IP address in "Network > Connection Mode”.
Page 84 web viewer 5. When a program installation wizard window appears, press the [Install] button to install the program. 6. When the program installation is complete, the Explorer window closes. Open the web viewer window again to log in. Live Viewer's main screen appears when you log in successfully after installing the program.
Page 85: Using Live Viewer (Windows)
USING LIVE VIEWER (Windows) The Live Viewer screen consists of following : Menu Functions Menu Selection Switches into corresponding menu screen by clicking each menu. Address, Name, Time Displays the IP, model name, time, etc. of connected DVR. Select <DVR Time> or <PC Time> for the OSD time information display setting of the DVR Time, PC Time Live Viewer.
Page 86 web viewer Menu Functions Display Pane Displays the video of camera connected to DVR. User ID, Logout Displays the user's ID. Click Logout icon for logout. OSD Information Display a The channel number of the connected DVR are displayed. b Either the <DVR Time> or the <PC Time> will be displayed as the current date and time, according to your configuration.
Page 87 Split-Screen Click split mode selection button to switch to the corresponding screen mode. SINGLE MODE QUAD MODE NINE MODE SIXTEEN MODE To switch to full screen mode Click < >. Current split screen appears in full screen. Press the [ESC] key to exit the full screen mode. English _87...
Page 88 web viewer Changing the Live Screen Mode 16-split mode does not support “Sequence”, “Previous” and “Next”. : When this button is clicked, the previous screen • appears. - In SINGLE MODE, the channel numbers are switched in reverse order. - In QUAD MODE, the screens are changed like 1st 4 channels (1~4)  2nd 4 channels (13~16)  3rd 4 channels (9~12) ...
Page 89 To print a screen 1. Click < > button. 2. Print current camera’s video image with the printer connected to the PC operating the Web Viewer. To save as AVI 1. Click < > button. When “AVI Setup” window appears, select the record saving path and capacity.
Page 90: Controlling A Connected Ptz Camera
web viewer CONTROLLING A CONNECTED PTZ CAMERA Controlling PTZ If PTZ camera is connected, the < > icon appears on screen. When selecting corresponding camera channel, the PTZ tab is provided to allow you to control the PTZ. Part Names Functions Direction Adjustment Adjusts the direction of a camera.
Page 91 To set a preset 1. Click < > button to display “Preset” window. 2. Click < > to select a desired preset number. 3. Enter the name of preset. 4. Use direction keys to adjust the direction which camera aims at. 5.
Page 92 web viewer Controlling OSD Menu If connected PTZ camera supports the OSD menu, press the < > to enter camera’s menu screen to change its settings. Part Names Functions Direction Adjustment You can go to a desired menu. ENTER Selects a desired item. Menu On/Off You can On/Off camera’s OSD menu settings.
Page 93: Using Search Viewer
USING SEARCH VIEWER The Search Viewer screen consists of following : Up to 3 users can access simultaneously. Menu Functions Menu Selection Switches to the corresponding menu screen by clicking each menu. Address, Name, Time Displays the IP, model name, time, etc. of connected DVR. Split Mode Selection Selects the type of split screen and selects the channel displayed in Display Pane.
Page 94 web viewer Menu Functions Play Control Adjusts current video’s playback speed and played time position. Displays the corresponding color depending on recorded data type if you place your Recording Color mouse cursor on that area. Display Pane Plays corresponding data on the screen if you select a search result. User ID, Logout Displays the user's ID.
Page 95 Names and Functions of Play Buttons a Moves backward by 10 minutes from the current playing point. b Plays in reverse at doubled speed. The playback speed is doubled up to 64x speed. c Moves backward by 1 second from current playing point. d Moves forward by 1 second from current playing point.
Page 96: Viewer Setup
web viewer VIEWER SETUP You can configure the DVR settings remotely on the network. To configure the DVR settings, click <Setup>. System You can configure the various settings of the DVR system. Date/Time/Language For more information, refer to <Date/Time/Language> in the <System Setup> menu. (Page 33) 1.
Page 97 Holiday You can set specific dates to Holidays according to your preferences. For more information, refer to <Setting Holiday> in the <System Setup> menu. (Page 35) Permission Management For more information, refer to <Permission Management> in the <System Setup> menu. (Page 36) • Admin You can change the admin ID or the password.
Page 98 web viewer • User You can add, change or remove a user or users. • Setup You can set the user permission. System Management For more information, refer to <System Management> in the <System Setup> menu. (Page 41) • System Information You can see information of the current system.
Page 99 Device You can check a list of devices that are connected to the DVR and configure the necessary settings. Click <Device> in the menu screen. For more information, refer to “Setting the Device”. (Page 45) Camera • Camera You can configure the settings of the camera that is connected to the DVR.
Page 100: Remote Device
web viewer Storage Device You can check and change the settings of the storage device. • Device You will see a list of storage devices that are connected to the DVR. You can check the type, used/total, usage and status of the device. • HDD Alarm You can set the alarm output channel and the alarm duration for an error.
Page 101 Monitor • Monitor You can configure the monitoring screen settings and set the output system. SDR-B73300 does not support Multi CH SEQ Time. • Mode You can switch between live mode and play mode. English _101...
Page 102 web viewer Record For more information, refer to <Setting the Recording>. (Page 54) Recording Schedule If you set a recording schedule for a specific date and time, the recording will start at that specific time. - Apply to All CH : Click <Apply to All CH> to display the confirmation window.
Page 103 REC Quality & Resolution • Standard/Event You can set the resolution, frame rate and recording quality for each channel. Record Option You can set the Disk End Mode. Event For more information, refer to <Setting the Event>. (Page 57) Motion Detection You can set the motion detection mode and the sensitivity as well as the alarm output type and the duration.
Page 104 web viewer • Motion Region Set the target motion detection area. Video Loss Detection You can set the alarm output time if a video loss occurs. Tampering Detection You can set whether to generate alarm and its dwell time for video tampering events.
Page 105 Alarm Schedule You can schedule the alarm output according to the day of the week and the time. The default setting is Event Sync, which activates the alarm only if an event occurs. Network For more information, refer to <Network Configuration>. (Page 61) Connection Mode A remote user can access the DVR via the network to check the current mode and the IP address.
Page 106 web viewer DDNS You can check the DDNS settings. Live Transfer Sets the quality of the image that is transferred from the DVR to the network. • Live Transfer A remote user can set the image resolution of the transferred data. Mailing Service You can specify the SMTP server that sends a mail if an event occurs and set the recipient group and users.
Page 107: Information
• Group You can add a group to receive the mail if an event occurs and set the permission to receive the event mail for each group. • Recipient You can add a user or users who will receive the mail. INFORMATION Click <Information>.
Page 108: Connecting Web Viewer (Mac)
web viewer CONNECTING WEB VIEWER (Mac) Safari on MAC. If you want to use DVR Web Viewer with Safari Browser on a Mac, please refer to this user guide and install Multi Viewer with firmware upgrade if necessary. • Mac OS versions available : Mac OS X - 10.7/10.8/10.9 • Safari : v5.1, v6.1, v7.0 1.
Page 109 • If Microsoft Silverlight plug-in is already installed 1. Use a web browser to connect to the DVR. 2. If Silverlight plug-in is already installed, you will see the login screen as shown. 3. If the login screen does not appear, check if the DVR set is connected properly with a valid IP address.
Page 110: Using Live Viewer (Mac)
web viewer USING LIVE VIEWER (Mac) The Live Viewer screen consists of following : Menu Functions Name, Address Displays a connected DVR’s IP address and model name. Menu Selection Consists of < LIVE > ,< ABOUT > and < LOGOUT > menu. These buttons are used for the screen split and full screen mode.
Page 111: Mobile Viewer
MOBILE VIEWER What is Mobile Viewer? Mobile Viewer is management software that enables you to connect to DVR (Digital Video Recorder) remotely and control the video playback and PTZ operations (if configured) in real time. Key Features • Remote access via Smart phone • Voice Recognition • 1-split and 4-split modes supported in Live Viewer • Supports single channel search function...
Page 112: Backup Viewer
backup viewer backup viewer SEC BACKUP VIEWER You can play a file that is backed up in the format of SEC. Backup in SEC format produces backup data file, library file and self-executable viewer file. If you run the backup file viewer, the backup data file will be automatically played. d e f 2015-01-01 06:59:57 SDR-C75300_CAM 01...
Page 113 Part Names Functions Set the screen’s aspect ratio to be displayed. Split Screen The screen switches to the selected split screen mode. Saves the current video’s image as in an image file. Supports jpeg file format. Screen Printout Prints out the current screen. You should have installed the appropriate printer driver before you can print out the screen.
Page 114: Appendix
appendix appendix PRODUCT SPECIFICATION (CAMERA) SDC-9441BC Item Details Video Imaging Device 2M CMOS (1/2.9") Effective Pixels 1920(H) x 1080(V) Scanning System Progressive, 30fps(NTSC)/25fps(PAL) Synchronization Internal Horizontal Resolution Color : 900 TVL, B/W : 900 TVL Min. Illumination OLux (IR-LED ON) 1CH BNC Camera Output Maximum Transmission Length: Over 300m (75 3C2V)
Page 115: Product Specification
PRODUCT SPECIFICATION (SDR-C74300, SDR-C75300) Details Item SDR-C74300 SDR-C75300 Inputs 8CH BNC 16CH BNC Video Resolution 1920 x 1080 (Full HD) / 1280 x 720 ( HD) / 928x480 (wD1) 240fps@ 1920 x 1080 /240fps@1280 480fps@ 1920 x 1080 /480fps@1280 Frame rate x 720 / 240fps@928 x 480 x 720 / 480fps@928 x 480 Live...
Page 116 1 RJ45 10/100 Base-T Serial interface RS-485 USB 2.0, 2 ports (Front/Rear) Connections Application Supoort Mouse, remote controller,WiFi Protocol support Samsung-E/ Samsung-T/ Pelco-D/ Pelco-p/Panasonic/ Phillips/ AD/ VICON/GE Coax Protocol Pelco-C General Input Voltage /Current 12V DC Adaptor Electrical Power consumption Max. 23W...
Page 117 Details Item SDR-C74300 SDR-C75300 Dimension (W x H x D) W300 x H48 x D208.7 mm (11.81" x 1.89" x 8.22") Mechanical Weight 1.73 kg (3.81 lb) 1.8 kg (3.97 lb) (With hard disks) Korean, Japanese, Chinese (Simplified), English, French, German, Spanish, Italian, Russian, Polish, Czech, Turkish, Netherlands, Portuguese,Swedish, Danish, Lauguage Thailandais, Rumania, Serbia, Croatia, Hungary, Greek, Chinese (Traditional),...
Page 118: Product Specification(Sdr-B73300)
appendix PRODUCT SPECIFICATION (SDR-B73300) Details Item SDR-B73300 Inputs 4CH BNC Video Resolution 1920 x 1080 (Full HD) / 1280 x 720 ( HD) / 928x480 (wD1) Frame rate 120fps@ 1920 x 1080 / 120fps@1280 x 720 / 120fps@928 x 480 Live Resolution 1920 x 1080 (Full HD) / 1280 x 720 ( HD) / 928x480 (wD1)
Page 119 8KHz Alarm Remote notification Notification via e-mail Ethernet 1 RJ45 10/100 Base-T Serial interface RS-485 USB 2.0, 2 ports (Front/Rear) Connections Application Supoort Mouse, remote controller,WiFi Protocol support Samsung-E/ Samsung-T/ Pelco-D/ Pelco-p/Panasonic/ Phillips/ AD/ VICON/GE Coax Protocol Pelco-C English _119...
Page 120 appendix Details Item SDR-B73300 General Input Voltage /Current 12V DC Adaptor, 100~250V AC, 50/60Hz Electrical Power consumption 11 W Operating Environmental Temperature / +0°C to +40°C (+32°F to +104°F) / 20% to 85% RH Humidity Dimension (W x H x D) W300 x H48 x D208.7 mm (11.81" x 1.89" x 8.22") Mechanical Weight 1.45 kg (3.17 lb)
Page 121: Product Overview
PRODUCT OVERVIEW • SDR-C75300 unit : mm (inches) 300.0mm (11.81’’) English _121...
Page 122 appendix • SDR-C74300 unit : mm (inches) 300.0mm (11.81’’) 122_ appendix...
Page 123 • SDR-B73300 unit : mm (inches) 300.0mm (11.81’’) English _123...
Page 124: Default Setting
appendix DEFAULT SETTING This returns the factory default settings. The settings are made as follows; • Use System/Load Factory Default in MENU The default settings are based on SDR-C75300. The initial administrator ID is “admin” and the password should be set when logging in for the first time. Please change your password every three months to safely protect personal information and to prevent the damage of the information theft.
Page 125 Category Details Factory Default Baudrate 9600 Parity None Remote Device Data Stop bit Remote Control ON(0) Event Display Device Display Monitor Multi CH SEQ Time 5 sec Monitor VGA/HDMI 1920 x 1080 HDMI Resolution Auto Detection Live Screen Mode Play Screen Recording Schedule CH1~CH16 Both(Cont&Evnt)
Page 126 appendix Category Details Factory Default IP Type Static Transfer Bandwidth 2Mbps IP Address 192.168.1.200 Interface Gateway 192.168.1.1 Subnet Mask 255.255.255.0 Connection Mode 168.126.63.1 Protocol Type Device Port 4520~4524 Port HTTP Port Secure Video Transmission DDNS DDNS Site Network Resolution Live Transfer Quality Server Port...
Page 127: Troubleshooting
TROUBLESHOOTING Symptom Countermeasures The system does not turn on and the indicator on the y Check if the power supply system is properly connected. front panel does not work at all. y Check the system for the input voltage from the power source. y If the problem persists even after you have taken the above actions, check the power supplier and replace it with a new one if neccessary.
Page 128 appendix Symptom Countermeasures A message of “Need to reset date/time.” Is displayed y This message is displayed if there occurs a problem with the time on the screen. setting of the internal clock or an error in the clock itself. Contact the retailer or the service center for more information.
Page 129 Symptom Countermeasures The image quality of the recording data is not good. y Increase the resolution and quality level in Menu – Record – Quality / Resolution. 1) Resolution: Select a bigger size when specifying the recording size. (1080p>720p>WD1>4CIF>2CIF>CIF) The recording image in the CIF format shows a deteriorated quality as it is enlarged from a small-sized image.
Page 130: Gnu General Public License
The software included in this product contains copyrighted software that is licensed under the GPL/LGPL. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
Page 131 10. If you wish to incorporate parts of the Program into other free a) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed programs whose distribution conditions are different, write to the author only for noncommercial distribution and only if you received the to ask for permission.
Page 132: Terms And Conditions
GNU GENERAL PUBLIC LICENSE a computer network, with no transfer of a copy, is not conveying. An interactive user interface displays “Appropriate Legal Notices” to the Version 3, 29 June 2007 extent that it includes a convenient and prominently visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that Copyright ©...
Page 133 terms added in accord with section 7 apply to the code; keep intact all A separable portion of the object code, whose source code is excluded notices of the absence of any warranty; and give all recipients a copy of from the Corresponding Source as a System Library, need not be this License along with the Program.
Page 134 permits relicensing or conveying under this License, you may add to a In the following three paragraphs, a “patent license” is any express covered work material governed by the terms of that license document, agreement or commitment, however denominated, not to enforce a provided that the further restriction does not survive such relicensing or patent (such as an express permission to practice a patent or covenant conveying.
Page 135 15. Disclaimer of Warranty. free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT a patent holder. Therefore, we insist that any patent license obtained for PERMITTED BY APPLICABLE LAW.
Page 136 you may at your option offer warranty protection in exchange for a fee. lines or less in length), then the use of the object file is unrestricted, regardless of whether it is legally a derivative work. (Executables 2. You may modify your copy or copies of the Library or any portion of containing this object code plus portions of the Library will still fall under Section 6.) it, thus forming a work based on the Library, and copy and distribute...
Page 137: Openssl License
How to Apply These Terms to Your New Libraries copying, distributing or modifying the Library or works based on it. 10. Each time you redistribute the Library (or any work based on the If you develop a new library, and you want it to be of the greatest Library), the recipient automatically receives a license from the original possible use to the public, we recommend making it free software that licensor to copy, distribute, link with or modify the Library subject to...
Page 138 1.3. “Covered Software” means (a) the Original Software, or (b) documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft. Modifications, or (c) the combination of files containing Original Software com).
Page 139 a) under Patent Claims infringed by the making, using, or selling of version will be given a distinguishing version number. Except as Modifications made by that Contributor either alone and/or in provided in Section 4.3, no one other than the license steward has the combination with its Contributor Version (or portions of such right to modify this License.
Page 140 DAMAGES, SO THIS EXCLUSION AND LIMITATION MAY NOT APPLY • You may not pretend that you wrote this software. If you use it, or TO YOU. only parts of it, in a program, you must acknowledge somewhere in your documentation that you have used the FreeType code. (`credits’) 8.
Page 141 For more additional information, send email to help.cctv@samsung.com. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED...
Page 142 BSD 2.0 http://www.opensource.org/licenses/bsd-license.html 4. Neither the name of the University nor of the Department may be For more additional information, send email to help.cctv@samsung.com. used to endorse or promote products derived from this software Copyright (c) 1998-2000 University College London without specific prior written permission.
Page 143 Copyright © 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND Clara, California 95054, U.S.A. CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED All rights reserved. WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A Use is subject to license terms below.
Page 144 License URL miniupnpc 1.5 BSD 2.0 http://miniupnp.free.fr/ For more additional information, send email to help.cctv@samsung.com. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED Copyright (c) 2005-2009, Thomas BERNARD WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 145 Copyright (c) 1999 Tommi Komulainen. endorse or promote products derived from this software without prior written permission. All rights reserved. THE AUTHORS OF THIS SOFTWARE DISCLAIM ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED Redistribution and use in source and binary forms, with or without WARRANTIES OF MERCHANTABILITY AND FITNESS, IN NO EVENT modification, are permitted provided that the following conditions are SHALL THE AUTHORS BE LIABLE FOR ANY SPECIAL, INDIRECT OR...
Page 146 El símbolo Eco representa el compromiso de Samsung Techwin de fabricar productos que respeten el medio ambiente e indica a la vez que este equipo cumple con la Directiva de la Unión Europea EU RoHS.
Page 147 SALES NETWORK SAMSUNG TECHWIN CO., LTD. 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA Tel : +82-70-7147-8753, 8764 Fax : +82-31-8018-3740 www.samsungsecurity.com SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 2nd Floor, No.
