- Page 1 ™ Carpetwin 16XP/20XP OPERATOR MANUAL Advance MODELS 56323776, 56323777 56323778, 56323779 11/97 revised 1/01 Form Number 56041387...
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Model Carpetwin 16XP Carpetwin 16XP Carpetwin 16XP Carpetwin 20XP Model Number 56323779 56323777 56323778 56323776 Voltage/frequency V/Hz 100 / 50/60 120 / 60 220-240 / 50/60 120 / 60 Rated Power 1,040 1,080 Protection Class (electrical) Protection grade (mec, moist, dust) IP 30 IP 30 IP 30... -
Page 3: Table Of Contents
TABLE OF CONTENTS ______________________________________________________________________________________________ page Introduction ............2 Parts and Service......... 2 Nameplate............ 2 Uncrating............2 Important Safetry Instructions......3 Importantes Mesures de Sécurité....... 4 Grounding Instructions ........5 Preparing the Machine for Use ......6 Installing the Filter Bag ........ 6 Know Your Machine ........... -
Page 4: Introduction
INTRODUCTION ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ This manual will help you get the most from your Advance Carpetwin. Read it thoroughly before operating the machine. Note: Bold numbers in parentheses indicate an item illustrated on page 7. This product is intended for commercial use only. ______________________________________________________________________________________________ PARTS AND SERVICE Repairs, when required, should be performed by your Authorized Advance Service Center, who employs factory trained... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using. This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. -
Page 6: Importantes Mesures De Sécurité
IMPORTANTES MESURES DE SÉCURITÉ ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Lors de l’utilisation d’un appareil électrique, suivez toujours les précautions d’usage, y compris celles qui suivent : Lisez toutes les instructions avant de faire fonctionner l’aspirateur. Cette machine ne convient qu´à un usage industriel, par exemple dans les hotels, les écoles, les hôpitaux, les usines, les boutiques et bureaux et tout ce qui n´est pas pour l´entretien domestique résidentiel normal. -
Page 7: Grounding Instructions
GROUNDING INSTRUCTIONS ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. -
Page 8: Preparing The Machine For Use
PREPARING THE MACHINE FOR USE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ INSTALLING A FILTER BAG Push in the Latch and remove the Bag Housing Cover. Install either a Cloth Filter Bag or a Paper Filter Bag. Push the Cloth Filter Bag’s rubber seal over the intake tube. Expand the Paper Filter Bag by pulling out the pleats. -
Page 9: Know Your Machine
KNOW YOUR MACHINE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Handle Vacuum Hose Power Cord Wand Transport Wheel Main Power Switch Pedal Brush Housing Upper Housing 10 Bag Housing Cover 11 “Bag Full” Indicator 12 Cord Hook 13 Brush Height Adjustment (refer to page 8) revised 1/00 FORM NO. -
Page 10: Operation
OPERATION ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Plug the Power Cord (3) into a properly grounded outlet. Step DOWN on the Pedal (7) and lower the Upper Housing (9) to a comfortable operating position. Turn the Main Power Switch (6) ON. Turn the Brush Height Adjustment Knob (13) one notch at a time to the point where the machine just starts to pull itself along. -
Page 11: After Use
AFTER USE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Unplug the Power Cord and wrap it around the Cord Hooks. Turn the Brush Height Adjustment Knob to the HIGH setting to raise the brush off the floor during storage. Check the Maintenance Schedule and perform any required maintenance before storage. Store the machine indoors in a clean, dry place. -
Page 12: Maintenance
MAINTENANCE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ CAUTION! Unplug the Power Cord before performing any machine maintenance. ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ CHANGING THE FILTER BAG Check the Filter Bag daily to see that it is installed correctly. Change the bag whenever the Bag Full Indicator shows RED or if the bag is damaged or full. To Change the Bag: Remove the Bag Housing Cover. -
Page 13: Cleaning The Exhaust Filter
MAINTENANCE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ CLEANING THE EXHAUST FILTER The exhaust filter cleans the air discharged from the vacuum motor. The filter is located just under the Upper Housing. The filter should be cleaned every third time that the bag is changed (more often in very dusty applications). To Clean the Exhaust Filter: Step DOWN on the Pedal and lower the handle. -
Page 14: Changing The Brush / Belt
MAINTENANCE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ CHANGING THE BRUSH / BELT By turning the Brush Height Adjustment Knob, you can compensate for some normal brush wear. Rotating the Bearing Blocks allows you even more compensation. Change the brush when the brush bristles are worn to 1/4 inch (6 mm). To Rotate the Bearing Blocks or Change the Brush: Remove the bottom cover from the brush housing. -
Page 15: Troubleshooting
TROUBLESHOOTING ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ VACUUM MOTOR TROUBLESHOOTING WARNING! Unplug the power cord before attempting any service to the machine. Poor Vacuum Pickup Possible Causes: • Full filter bag • Debris blockage in vac shoe opening and hoses • Clogged vac secondary filter and exhaust filter •... - Page 16 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©2000 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
