G E T T I NG STARTE D
This appliance is intended for household use only.
• Remove all packing material, any stickers, and the plastic band around the
power plug.
• Go to www.prodprotect.com/applica to register your product.
• Wash all removable parts as instructed in CARE AND CLEANING.
HOW TO D I SASSE MB L E
1.
To remove the pulp container, hold the finger grips
firmly and slide it out, bottom first. (A)
2.
To unlock the safety locking latches, pull outward
at the bottom of the latches on both sides to
disengage from the grooves on the clear cover (B).
3.
To remove the clear cover, take out the fruit and
vegetable pusher, grasp the food chute and pull
up the clear cover (C).
4.
To remove the pulp separator, grip the pulp
separator on both sides through the half-round cut
outs above the latches. With the cutter/strainer
in place, pull up on the pulp separator while
pushing downwards on the main body of the juice
extractor (D).
5.
To remove the cutter/strainer, hold the pulp
separator with one hand and grasp the cutter/
strainer rim with the other hand;
pull it out (E).
Caution: The cutter/strainer teeth are very sharp.
Handle carefully.
5
A
B
C
D
E
