Page 1: Wall Mounted
WALL MOUNTED MDV-D22G/N1-S, MDV-D28G/N1-S, MDV-D36G/N1-S, MDV-D45G/N1-S, MDV-D56G/N1-S. SERVICE MANUAL MAN-S-WMST-0715 intensity.mx... - Page 2 Wall Mounted Type...
- Page 3 1. Feature 1.1 New panels design, withLED display. 1.2 Convenient for installation 1.2.1 Multi-refrigerant outlet pipe method: left\right\rear, more flexible for installation. Left Rear Right 1.2.2 Longer the connection pipe, Gas pipe: 18-7/16in(468mm) /Liquid pipe: 21-21/32in(550mm), more flexible for the installation 1.2.3 Adopts new type fixing plate,easy for installation and stable.
- Page 4 1.5.1 Adoption of the Fujikoki brand mechanical expansion valve which has 2000 stages element positioning, ensure precise flow control, as well lower modulation noise when EXV operating. 1.5.2 Smoother airflow with less turbulence. Owing to the multiple-blade fan and the air guide design, the airflow is getting smoother and more comfortable 1.5.3 Louver’s air swing angle can be up to 90º...
- Page 5 Wall mounted Type Model MDV-D22G/N1-S MDV-D22G/DN1-S MDV-D28G/N1-S MDV-D28G/DN1-S Power supply V- Ph-Hz 220-240V~, 1Ph, 60Hz Capacity 7500 9600 Btu/h 7500 9600 Cooling Input Rated current 0.14 0.14 0.14 0.14 Capacity 8900 8900 10900 10900 Btu/h Heating Input Rated current 0.14 0.14...
- Page 6 Wall mounted Type MDV-D36G/N1-S MDV-D36G/DN1-S MDV-D45G/N1-S MDV-D45G/DN1-S Model Power supply V- Ph-Hz 220-240V~, 1Ph, 60Hz Capacity Btu/h 12300 12300 15400 15400 Cooling Input Rated current 0.14 0.14 Capacity Btu/h 13600 13600 17100 17100 Heating Input Rated current 0.14 0.14 Electrical heating capacity 0.75 Model YDK15-6B...
- Page 7 Wall mounted Type MDV-D56G/DN1-S Model MDV-D56G/N1-S Power supply V- Ph-Hz 220-240V~, 1Ph, 50Hz Capacity Btu/h 19100 19100 Cooling Input Rated current Capacity Btu/h 21500 21500 Heating Input Rated current Electrical heating capacity Model YDK18-4 YDK18-4 Type AC motor Indoor fan Brand Welling motor...
- Page 8 Wall mounted Type MDV-D22G/N1-S MDV-D28G/N1-S MDV-D36G/N1-S MDV-D22G/DN1-S MDV-D28G/DN1-S MDV-D36G/DN1-S Outer Length: 915mm), Height: 290mm), Depth: 230mm) 36-1/32in( 11-13/32in( 9-1/16in( Filter length: 26-3/32in(663mm) Gas tube: 1/2” ( 12.7mm), (length: Approx. 468mm,18-7/16in) Liquid tube: 1/4” ( 6.35mm) (length: Approx.550mm, 21-21/32in) Outer Length:...
- Page 9 Wall mounted Type MDV-D22G/N1-SMDV-D28G/N1-SMDV-D36G/N1-SMDV-D45G/N1-SMDV-D56G/N1-S MDV-D22G/DN1-SMDV-D28G/DN1-SMDV-D36G/DN1-SMDV-D45G/DN1-SMDV-D56G/DN1-S motor flare nut gas side heat exchanger flare nut liquid side...
- Page 10 Wall mounted Type MDV-D22G/N1-SMDV-D28G/N1-SMDV-D36G/N1-SMDV-D45G/N1-SMDV-D56G/N1-S MDV-D22G/DN1-SMDV-D28G/DN1-SMDV-D36G/DN1-SMDV-D45G/DN1-SMDV-D56G/DN1-S...
- Page 11 Wall mounted Type : total capacity : sensible capacity : wet-bulb temperature :dry-bulb temperature 53.6 57.2 60.8 64.4 69.8 73.4 80.6 84.2 87.8 91.4 98.6 102.2 107.6 111.2 114.8 53.6 57.2 60.8 64.4 69.8 73.4 80.6 84.2 87.8 91.4 98.6 102.2 107.6 111.2...
- Page 12 Wall mounted Type 53.6 57.2 60.8 64.4 69.8 73.4 80.6 84.2 87.8 91.4 98.6 102.2 107.6 111.2 114.8 53.6 57.2 60.8 64.4 69.8 73.4 80.6 84.2 87.8 91.4 98.6 102.2 107.6 111.2 114.8...
- Page 13 Wall mounted Type : total capacity : wet-bulb temperature : dry-bulb temperature -3.64 1.46 1.46 1.46 1.46 1.46 1.46 -1.84 -2.2 1.56 1.56 1.56 1.56 1.56 1.56 1.94 1.64 1.64 1.64 1.64 1.64 1.64 7.34 1.69 1.69 1.69 1.69 1.69 1.69 10.76 1.79...
- Page 14 Wall mounted Type 1.94 3.15 3.15 3.15 3.15 3.15 3.15 7.34 3.25 3.25 3.25 3.25 3.25 3.25 10.76 3.35 3.35 3.35 3.35 3.35 3.35 14.36 12.2 3.50 3.50 3.50 3.50 3.50 3.50 14.9 3.65 3.65 3.65 3.65 3.65 3.65 16.7 15.62 3.75 3.75...
- Page 15 Wall mounted Type Indoor Unit Power Supply Model Voltage Min. Max. MDV-D22G/N1-S 220-240V 0.013 0.225 MDV-D28G/N1-S 220-240V 0.013 0.225 MDV-D36G/N1-S 220-240V 0.013 0.225 MDV-D45G/N1-S 220-240V 0.028 0.24 MDV-D56G/N1-S 220-240V 0.028 0.24 MDV-D22G/DN1-S 220-240V 0.013 0.225 MDV-D28G/DN1-S 220-240V 0.013 0.225 MDV-D36G/DN1-S 220-240V 0.013...
- Page 16 Wall mounted Type 3.28ft MDV-D22G/(D)N1-S MDV-D28G/(D)N1-S MDV-D36G/(D)N1-S MDV-D45G/(D)N1-S MDV-D56G/(D)N1-S MDV-D22G/(D)N1-SMDV-D28G/(D)N1-SMDV-D36G/(D)N1-SMDV-D45G/(D)N1-SMDV-D56G/(D)N1-S Audibility limits of Audibility limits of continuous white continuous white sound sound Octave band center frequency Hz Octave band center frequency Hz...
- Page 17 Wall mounted Type Name Quantity Shape Usage Installation manual Pipe insulation material Heat insulation Remote controller 7# alkaline battery Holder for remote controller Hold the remote controller Remoter controller manual Mounting screw(ST2.9 10-C-H) Installation Holder for remote controller Controlling discreteness installation plot Installation spring Fix water outlet Water outlet joint...
