OPTIONAL CONTROL VALVES
2 port on/off valves or 4 port diverting valves are available as factory fitted options.
(4 port modulating valves are also available - contact TEV Technical Sales Department).
2 pipe cool only systems require one valve per fan coil.
2 pipe heat/cool systems (supplied from a reverse cycle chiller, or chiller + boiler) require one valve: if using an
auto changeover thermostat, they also need a means of signalling heating or cooling status of the flow eg a pipe
thermostat (kit shown on page 23).
4 pipe systems require two valves (but no pipe thermostat is needed).

VALVE POSITIONS

ELECTRICAL LOADS (A)
CWM (L)
55
75
105
OPTIONAL ELECTRIC HEATING (kW)
CWM (L)
55
75
105
AIRFLOWS (m³/s)
CWM (L) LOW SPEED
55
75
105
COIL WATER VOLUMES (Litres)
CWM (L) Chilled water coil
55
75
105
Fan motor
0.4
0.4
0.5
240V 50Hz
1.3
1.8
2.3
MEDIUM SPEED
0.17 0.19
0.24 0.31
0.25 0.34
1.6
2.0
2.5
Electric heater
5.2
7.2
9.2
230V 50Hz
1.2
1.7
2.1
HIGH SPEED
0.28
0.37
0.49
LPHW coil
0.18
0.24
0.30
-3-
