SERVICE MANUAL
SERVICE MANUAL
2 CHANNEL AMPLIFIER
MODEL
BMDD
BMMA
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
x
ao
u163
y
i
http://www.xiaoyu163.com
2 9
8
ADM-30.1 (B)
Black model
120V AC 60Hz
Q Q
220-240V AC 50/60Hz
3
6 7
1 3
1 5
ON THE
co
.
9 4
2 8
Ref. No. 4164
Sep, 2009
0 5
8
2 9
9 4
2 8
m
ADM-30.1
9 9
9 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADM-30.1 (B) and is the answer not in the manual?

Questions and answers

Related Manuals for Integra ADM-30.1 (B)

Summary of Contents for Integra ADM-30.1 (B)

  • Page 1 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 Ref. No. 4164 SERVICE MANUAL SERVICE MANUAL Sep, 2009 2 CHANNEL AMPLIFIER ADM-30.1 (B) MODEL Black model BMDD 120V AC 60Hz BMMA 220-240V AC 50/60Hz L 13942296513 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

  • Page 2: Service Procedure

    http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 SERVICE PROCEDURE 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse , For fuse rating, refer to the marking adjest to the symbol.
  • Page 3 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 ADJUSTMENT PROCESURE OUTPUT OFFSET VOLTAGE Conditions: Non load, no signal. 1. Set the voltage at L-ch speaker terminal to 0mV +/- 10mVDC by adjusting R513 of BAAF-0249. Same as R514 (R-ch). 2. After 2 minutes, set the voltage at speaker terminal to 0mV +/- 10mV again.

  • Page 4: Exploded View

    http://www.xiaoyu163.com ADM-30.1 3 7 6 3 1 5 1 5 0 EXPLODED VIEW A017 A106 x 4pcs. x 7 pcs. A301 A003 A012 x 2 pcs. A018 A011 4 pcs. A101 x 4 pcs. A102 A002 A042 x 17 pcs. A104 A043 x 2 pcs.
  • Page 5 http://www.xiaoyu163.com ADM-30.1 3 7 6 3 1 5 1 5 0 BLOCK DIAGRAM-1 R2S15215FP (PART-1) SP-A TONE Phono VL Digital SP-B TONE NJM4556 Head Phone 1 3 9 4 2 2 9 6 5 1 3 DAC/DIR DAC/DIR 5V/3.3V T951 NPT-1487 Vol_UP Power SW...
  • Page 6 http://www.xiaoyu163.com ADM30.1 3 7 6 3 1 5 1 5 0 BLOCK DIAGRAM-2 (PART-2) VL Digital Sensor IPM OFF IPM ON 12Vtrg OFF 12Vtrg ON +12Vsub 12Vtrg_OUT 1 3 9 4 2 2 9 6 5 1 3 12Vtrg_IN +12Vsub INPUT OPAMP APOWER Driver...
  • Page 7 http://www.xiaoyu163.com ADM-30.1 3 7 6 3 1 5 1 5 0 SCHEMATIC +17V DIAGRAM-1 U002 DIGITAL AMP. CIRCUIT PC BOARD U001 BAAF-0278 Q505A SPEAKER TERMINAL PC BOARD BAAF-0249 HN3A51F Q505B DIGITAL AMP. LN25XB60 +33V D901 SECTION +B_LCH Q507A Q507B R589 (PART-3) HN3A51F 33(1/4W)
  • Page 8 http://www.xiaoyu163.com ADM-30.1 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAM-2 U002 SPEAKER TERMINAL PC BOARD BAAF-0278 (PART-6) Q311 78M15 220(2W) R353 47/50 NE5532AP C303 47/50 R311 Q301A P304 C341 C307 Q312 TRM-423 NE5532AP 79M15 C305 R317 47/50 R301 Q301B R354...
  • Page 9 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 SCHEMATIC DIAGRAM-3 U0032 AC INLET TERMINAL U003 POWER SUPPLY PC BOARD PC BOARD C956 BAETC-0272 NPT-1586 BAPS-0270 DE1E3KX102ME4BA01 T901 F901 L952 L951 RL951 NCH-3646 NCH-3645 NRL-1P10A-DC12-140 T902 NPT-1586 D955 1SS352 C958 104J Q952 DTC123JKA NPS-111-L687P(TV-5) S951...
  • Page 10 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 PRINTED CIRCUIT BOARD VIEW-1 U001: DIGITAL INPUT CIRCUIT PC BOARD BAAF-0249 Q627 R661 R663 C648 Q516 R572 C631 Q621 C519 R677 R675 Q514 R640 D502 C530 R559 R561 C647 R571 R532 R575 R577 Q513 R589 R590...

  • Page 11: Printed Circuit Board View

    http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 PRINTED CIRCUIT BOARD VIEW-2 U003 : POWER SUPPLY PC BOARD BAPS-0270 POFF APOWER RISK OF FIRE +12VS C962 -REPLACE FUSE AS MARKED. P956 C961 BCPS-0270 D954 P954A 25140270B Q951 J952 J951 C960 R956 J953 P953A P952A...
  • Page 12 http://www.xiaoyu163.com ADM-30.1 3 7 6 3 1 5 1 5 0 PRINTED CIRCUIT BOARD VIEW-3 BLACK BLACK U002 : SPEAKER TERMINAL PC BOARD J191 P902 P901 S301 BAAF-0278 S302 P301 P302 P304 P305 P303 -12V P902 P960 J378 P901 +12V APOWER J379 C930...
  • Page 13 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 PRINTED CIRCUIT BOARD VIEW-4 U0021 : POWER INDICATOR PC BOARD BAETC-0279 BCETC-0279 25140279 D411 J411 P606A Soldering side view from component side Q414 Q411 L 13942296513 Q421 Q412 Q413 Component side view from soldering side u163 http://www.xiaoyu163.com...
  • Page 14 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q601/Q602: IRS20954S DIGITAL AUDIO DRIVER-1 LEAD DEFINITIONS Pin # Symbol Description Floating input positive supply Shutdown timing capacitor, referenced to VSS PWM non-inverting input, in phase with HO Floating input supply return 5V reference output for setting OCSET VREF...
  • Page 15 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q601/Q602: IRS20954S DIGITAL AUDIO DRIVER-2 BLOCK DIAGRAM FLOATING INPUT DETECT DETECT HIGH SIDE INPUT LOGIC 10.4V LEVEL SHIFT FLOATING HIGH SIDE LEVEL LEVEL SHIFT SHIFT 5V REG DETECT CHARE/ DISCHARGE L 13942296513...
  • Page 16 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q631/ Q632: LM61CIZ (TEMPERATURE SENSOR) Connection Diagram SOT-23 TO-92 Top View L 13942296513 u163 http://www.xiaoyu163.com...
  • Page 17 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q303/ Q305 : NE5532APSR (OPE. AMP.) (TOP VIEW) 1OUT 2OUT 1IN− 2IN− 1IN+ 2IN+ CC− L 13942296513 u163 http://www.xiaoyu163.com...

  • Page 18: Pin Configuration

    http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q519/Q520/Q322 : NJM78L05UA (VOLTAGE REGULATOR) PIN CONFIGURATION PIN DESCRIPTION 1. OUTPUT 2. GND 3. INPUT L 13942296513 u163 http://www.xiaoyu163.com...
  • Page 19 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q310 : NJM78MxxFA 3-TERMINAL VOLTAGE REGULATOR PIN CONFIGURATION 1. Input 2. GND. 3. Output L 13942296513 u163 http://www.xiaoyu163.com...
  • Page 20 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q951: S-80127CNMC-JKM VOLTAGE DETECTOR (12.7V N-ch open drain, Active L: out) PIN CONFIGURATION PIN DESCRIPTION Symbol Description ON/OFF switch for delay time Top view Non-connection Voltage detection output pin Voltage input pin *1.
  • Page 21 http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q511/Q512: TC7W14FU SCHMITT INVERTER PIN ASSIGNMENT (TOP VIEW) 7W14 TRUTH TABLE L 13942296513 u163 http://www.xiaoyu163.com...

  • Page 22: Package Info

    http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION Q404/ Q405: TC74HC00AF (QUAD 2-INPUT NAND GATE) PACKAGE INFO. PIN DESCRIPTION L 13942296513 Top View TRUTH TABLE u163 http://www.xiaoyu163.com...

  • Page 23: Packing Procedure

    http://www.xiaoyu163.com ADM-30.1 3 7 63 1515 0 PACKING PROCEDURE A204 A922 A203 A912 A902 A901 <MDC> <MMA> A923 P953 A924 <MMA> A206 Top side marking Back side marking A204 P952 L 13942296513 A201 Front side A202 A306 A303 Front side marking A201 Top side...
  • Page 24 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 PARTS LIST ADM-30.1 NOTE: MDD : North American model THE COMPONENTS IDENTIFIED BY MARK MMA : Australian model CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED. EXPLODED VIEW PARTS LIST REF.
  • Page 25 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 A018 TR ACCY AC316A 223033 A019 SHEET 29096096 A022 CLAMP HL-28-0 27301396 A031 F BRACKET 27111555A A032 BRACKET 27131066 A034 SCREW 3TTB+8B(3CM)SR 801637 A035 SCREW 3TTB+8B(3CM)SR 801637 A036 SCREW 3TTB+8B(3CM)SR 801637 A039 SCREW...
  • Page 26 29355769 L 1 3 9 4 2 2 9 6 5 1 3 A301 CARTON ADM-30.1(B) 29055021A A302A EAN LABEL ADM-30.1 (B)MMA { 1} 29390850 N B MMA A302A UPC LABEL ADM-30.1 (B)MDD { 1} 29390849A N B MDD A303...
  • Page 27 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Digital Amp. circuit PC board U001 BAAF-0249-1B * 1B237549-1B a'ssy CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [SEMI CONDUCTOR] D501 ZENER D UDZS5.6B 224550560R2 D502 ZENER D UDZS5.6B 224550560R2 D503...
  • Page 28 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Q504 2SC2712-GR 2213145R2 Q505 HN3A51F(TE85L_F) 2217190R2 Q506 HN3A51F(TE85L_F) 2217190R2 Q507 HN3A51F(TE85L_F) 2217190R2 Q508 HN3A51F(TE85L_F) 2217190R2 Q509 2SC2712-GR 2213145R2 Q510 2SC2712-GR 2213145R2 Q511 TC7W14FU(TE12L_F) 22241161R2 Q512 TC7W14FU(TE12L_F) 22241161R2 Q513 2SC2712-GR 2213145R2 Q514 2SC2712-GR 2213145R2...
  • Page 29 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Q617 2SA1162-GR 2214375R2 Q618 2SA1162-GR 2214375R2 Q621 2SA1162-GR 2214375R2 Q622 2SA1162-GR 2214375R2 Q627 2SA1162-GR 2214375R2 Q628 2SA1162-GR 2214375R2 Q629 HN1A01F-GR 2215915R2 Q630 HN1A01F-GR 2215915R2 Q631 LM61CIZ 22242212 Q632 LM61CIZ 22242212 [CAPACITOR] C501 C-FILM C...
  • Page 30 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 C527 C-CERA C CK725F1E-104Z1 332161040R1 C528 C-CERA C CK725F1E-104Z1 332161040R1 C529 C-CERA C CK725F1E-104Z1 332161040R1 C530 C-CERA C CK725F1E-104Z1 332161040R1 C531 UPZ C 2AUPZTF471JE 376334714T C532 UPZ C 2AUPZTF471JE 376334714T C533 UTSP C CE04W25V-220M(UTSP)
  • Page 31 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 C632 C-CERA C CK725F1E-104Z1 332161040R1 C643 C-CERA C CK725F1E-104Z1 332161040R1 C644 C-CERA C CK725F1E-104Z1 332161040R1 C645 C-CERA C CK725F1E-104Z1 332161040R1 C646 C-CERA C CK725F1E-104Z1 332161040R1 C647 C-CERA C CC725CH1H-102J1 342101024R1 C648 C-CERA C CC725CH1H-102J1...
  • Page 32 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R526 C-CARBON R RN72K1J-392JE 435033924R1 R527 C-CARBON R RN72K1J-392JE 435033924R1 R528 C-CARBON R RN72K1J-392JE 435033924R1 R529 C-CARBON R RN72K1J-332JE 435033324R1 R530 C-CARBON R RN72K1J-332JE 435033324R1 R531 C-CARBON R RN72K1J-104JE 435031044R1 R532 C-CARBON R RN72K1J-104JE...
  • Page 33 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R577 C-CARBON R RN72K1J-562JE 435035624R1 R578 C-CARBON R RN72K1J-562JE 435035624R1 R579 C-CARBON R RN72K2E-103JE 435221034R1 R580 C-CARBON R RN72K2E-103JE 435221034R1 R581 CARBON R R16J-6.8K 417346824T R582 CARBON R R16J-6.8K 417346824T R583 CARBON R R16J-39K...
  • Page 34 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R614 C-CARBON R RN72K1J-683JE 435036834R1 R615 C-CARBON R RN72K2E-068JE 435220684R1 R616 C-CARBON R RN72K2E-068JE 435220684R1 R617 C-CARBON R RN72K2E-068JE 435220684R1 R618 C-CARBON R RN72K2E-068JE 435220684R1 R619 C-CARBON R RN72K2E-068JE 435220684R1 R620 C-CARBON R RN72K2E-068JE...
  • Page 35 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R661 C-CARBON R RN72K1J-223JE 435032234R1 R662 C-CARBON R RN72K1J-223JE 435032234R1 R663 C-CARBON R RN72K1J-103JE 435031034R1 R664 C-CARBON R RN72K1J-103JE 435031034R1 R673 C-CARBON R RN72K1J-123JE 435031234R1 R674 C-CARBON R RN72K1J-123JE 435031234R1 R675 C-CARBON R RN72K1J-224JE...
  • Page 36 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 P603A SOCKET NSCT-9P2189 25052292 P605A SOCKET AS NSAS-14P1802 2009991165UL ADM-30.1 Speaker terminal PC board U002 BAAF-0278-1A * 1B237578-1A a'ssy Power indicator PC board U0021 BAAF-0279-1A 1B237579-1A a'ssy CIRCUIT. NO. PART NAME DESCRIPTION Q'TY PART NO.
  • Page 37 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 D412 C-DIODE 1SS352 223234R2 D413 C-DIODE 1SS352 223234R2 D414 C-DIODE 1SS352 223234R2 D415 C-DIODE 1SS352 223234R2 D416 C-DIODE 1SS352 223234R2 D417 C-DIODE 1SS352 223234R2 D418 ZENER D UDZS5.6B 224550560R2 D419 C-DIODE 1SS352 223234R2...
  • Page 38 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Q317 2SA1015-GR 2211455T Q318 2SC1815-GR 2211255T Q319 2SC1815-GR 2211255T Q320 2SA1015-GR 2211455T Q321 2SC1815-GR 2211255T Q322 78L05(NJM78L05UA) 222780053R2JR Q323 2SA1015-GR 2211455T Q324 RN1402 2214470R2 Q325 RN1402 2214470R2 Q328 2SC1815-GR 2211255T Q329 2SC1815-GR 2211255T...
  • Page 39 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Q424 2SC1815-GR 2211255T Q425 RN1402 2214470R2 Q426 RN1402 2214470R2 Q619 HN1C01F-GR(TE85L_F) 2215925R2 Q620 HN1C01F-GR(TE85L_F) 2215925R2 Q625 HN1C01F-GR(TE85L_F) 2215925R2 Q626 HN1C01F-GR(TE85L_F) 2215925R2 Q901 78M12HF(NJM78M12FA) 222780125JRC Q902 78M12HF(NJM78M12FA) 222780125JRC Q903 DTC123JKA 2216690R2 Q904 DTC123JKA 2216690R2...
  • Page 40 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 C324 UTSP C CE04W25V-220M(UTSP) 397552217T C325 UTSP C CE04W25V-220M(UTSP) 397552217T C326 TF C ECQ-V50V-104J 374721044T C327 TF C ECQ-V50V-104J 374721044T C330 UTSP C CE04W50V-22M(UTSP) 397582207T C331 UTSP C CE04W50V-10M(UTSP) 397581007T C332 UTSP C CE04W50V 47M(UTSP)
  • Page 41 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 C641 C-CERA C CK725F1E-104Z1 332161040R1 C642 C-CERA C CK725F1E-104Z1 332161040R1 C901 TF C ECQ-V50V-104J 374721044T C902 TF C ECQ-V50V-104J 374721044T C903 TF C ECQ-V50V-104J 374721044T C904 TF C ECQ-V50V-104J 374721044T C905 TF C ECQ-V50V-104J...
  • Page 42 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 C930 MKT C B32529C0102J289 376491024T C931 TF C ECQ-V50V-104J 374721044T C932 TF C ECQ-V50V-104J 374721044T [RESISTOR] R301 CARBON R R16J-330 417343314T R302 CARBON R R16J-330 417343314T R303 CARBON R R16J-220K 417342244T R304 CARBON R...
  • Page 43 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R347 CARBON R R16J-120K 417341244T R348 CARBON R R16J-10K 417341034T R349 CARBON R R16J-100K 417341044T R350 CARBON R R16J-100K 417341044T R351 CARBON R R16J-100K 417341044T R352 CARBON R R16J-10K 417341034T R355 METAL O R RS1/2WBJ-22...
  • Page 44 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R385 CARBON R R16J-220K 417342244T R386 CARBON R R16J-220K 417342244T R388 CARBON R R16J-47K 417344734T R389 CARBON R R16J-10K 417341034T R390 CARBON R R16J-68K 417346834T R391 CARBON R R16J-68K 417346834T R392 CARBON R R16J-10K...
  • Page 45 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R425 CARBON R R16J-100K 417341044T R426 CARBON R R16J-5.6K 417345624T R427 CARBON R R16J-330K 417343344T R428 CARBON R R16J-680K 417346844T R429 CARBON R R16J-180K 417341844T R430 CARBON R R16J-2.2M 417342254T R431 CARBON R R16J-100K...
  • Page 46 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 R485 C-CARBON R RN72K1J-000JE 435030004R1 R641 C-CARBON R RN72K1J-273JE 435032734R1 R642 C-CARBON R RN72K1J-273JE 435032734R1 R643 C-CARBON R RN72K1J-223JE 435032234R1 R644 C-CARBON R RN72K1J-223JE 435032234R1 R645 C-CARBON R RN72K1J-392JE 435033924R1 R646 C-CARBON R RN72K1J-392JE...
  • Page 47 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 F401 RESISTOR nanoSMDC016F 4000239R2 P301 PIN JACK NPJ-2PDWR706 25045940A P301A SHLD PLT (PINJACK) 27150527 P302 PIN JACK NPJ-2PDWR706 25045940A P302A SHLD PLT (PINJACK) 27150527 P303 ST JACK HSJ1002-01-6020 25045647 P304 TRM-423(SCREW) NEJITANSI ST3 25060495...
  • Page 48 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 RL901 RELAY NRL-2P5A-DC12-192 25065702 RL902 RELAY NRL-2P5A-DC12-192 25065702 S301 SLIDE SW NSS-22203 25065581 S302 SLIDE SW NSS-22203 25065581 ADM-30.1 U003 Power supply PC board a'ssy BAPS-0270-1E * 1B237570-1E N B MDD U003 Power supply PC board a'ssy BAPS-0270-1F *...
  • Page 49 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 [CAPACITOR] C951 IS C DE1310E472M-KH 3300054 C953 IS C MKP R46 224M 3800040S C954 IS C MKP R46 224M 3800040S C955 IS C MKP R46 224M 3800040S C956 PLA C DE1E3KX102ME4BA01 3800043S C957...
  • Page 50 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 P957 PLUG NPLG-2P631 25055675 P958 PLUG NPLG-2P631 25055675 P959 TRM-423(SCREW) NEJITANSI ST3 25060495 P959B PLUG NPLG-5P133 25055149 RL951 RELAY NRL-1P10A-DC12-140 25065584 S951 P SW NPS-111-L687P(TV-5) 25035724 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 51 ADM-30.1 3 7 63 1515 0 L 13942296513 Integra Division of ONKYO CORPORATION Service Dept. Technical Support : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 http://www.onkyo.com/ Integra Division of ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
