- Page 1 Installation Guide...
- Page 2 Australian Registered Design No. 325331, 328015; U .S. Pat. Nos. D612476 and D614757; Malaysian Registered Design No. MY09-00255-0101, MY09-00973-0101; and Singapore Registered Design No. D2008/951/E and D2009/235/G. Haiku and the Haiku logo are trademarks of Delta T Corporation, registered in the United States and/ or other countries.
-
Page 3: Troubleshooting
Annual maintenance Installing the lower cover Installing rubber bumpers Attaching the mounting plate WARRANTY Securing the safety cable Warranty policy Wiring the fan Hanging the fan Securing the wiring cover Wire color chart Wiring diagram HAIKU by Big Ass Fans... -
Page 4: Important Safety Instructions
WARNING: Before installing or servicing the fan, ensure power is disconnected. CAUTION: Haiku (K3150-S1) is rated for use in damp environments and can be operated indoors or outdoors. Haiku Bamboo (S3150-S1) is not rated for damp environments and must be operated indoors only. -
Page 5: Technical Specifications
I NTR ODUCTION Thank you for your Haiku purchase and congratulations on your selection of an elegant, efficient, and cost-effective way to stay cool! We are proud to assure you that the fan you have chosen is backed by extensive research, thorough testing, and quality manufacturing. -
Page 6: Parts And Hardware
INTRODUCTION (CONT.) Parts and hardware If you are missing any parts or hardware required for the installation or operation of your Haiku, contact Haiku Technical Service. Note: Drawings below are not to scale. (2) Rubber Mounting plate (2) Mounting bracket... -
Page 7: Tools Needed
Determining fan location Consider the following guidelines as you decide where to install your Haiku: • Do not mount the fan in an environment that is excessively dusty, conductive, corrosive, or gas- filled, near strong chemicals or solvents, or where there is excessive heat, shock, or vibration. -
Page 8: Installation
Review the safety guidelines. If you are not completely comfortable or have questions about any aspect of the installation process, consult a structural engineer or electrical contractor or contact Haiku Technical Service for assistance. Step 1. Installing the airfoils Position the fan upside-down on the provided foam work aid located inside the packaging as shown on the right. -
Page 9: Step 2. Installing The Lower Cover
For Haiku Bamboo, simply snap the lower cover to the bottom of the fan hub. Lower Cover Haiku For Haiku, position the lower cover, and then place both hands flat on the cover and turn clockwise to lock the lower cover into place. Lower Cover Step 3. -
Page 10: Step 5. Securing The Mounting Plate
INSTALLATION (CONT.) Step 4. Installing anchor bolts Ensure wiring has been routed to the fan site. Drill four 8 mm holes. The hole depth should not exceed 40 mm. Drill one 14 mm hole (for safety anchor hook) in the pattern shown below. The hole depth should not exceed 50 mm. -
Page 11: Step 6. Wiring The Fan
Twist clockwise to snap the wiring cover trim into position as shown. If there is not enough clearance between the wiring cover and ceiling, the screw can be moved to the lower tip! hole on the extension tube. Wiring cover Wiring cover trim HAIKU by Big Ass Fans... -
Page 12: Wiring Diagram
INSTALLATION (CONT.) Wiring diagram Ensure power is disconnected before installing the fan! WARNING: Do not connect the fan to a damaged power source! Do not attempt to resolve electrical failures on your own. Consult a qualified electrician if uncertain of the electrical installation of this fan. Wire color chart 50/60 Hz Compatible Earth/PE... -
Page 13: Operation
Operation Before using the Haiku remote control, remove the plastic tab in the battery tray. The fan mode indicators are located on the bottom of the fan hub when viewed from the floor. Remote Front Powering the fan To turn the fan on or off, press the On/Off button on the fan remote. This button can also be used to reset the fan’s speed. - Page 14 OPERATION (CONT.) Fan mode indicators Each operating mode is indicated by a pattern on the fan mode indicator display, which is located on the bottom of the fan and is visible from the floor. The display includes an LED (light emitting diode) bar graph to indicate fan speed and Whoosh mode, and separate LEDs to indicate Timer mode and Sleep mode.
-
Page 15: General Troubleshooting
• Check all mounting and fan hardware. If loose, tighten. The fan is noisy during operation. • For Haiku Bamboo fans, remove the airfoil to ensure the colored sticker matches the sticker on the fan hub. For Haiku fans, remove the bottom cover and ensure the colored sticker on the bottom of the airfoil matches the sticker on the fan tab. -
Page 16: Annual Maintenance
Please take a few moments each year to perform the following preventative maintenance procedures on your fan to ensure its safe and efficient operation. If you have any questions, require assistance with your fan, or need replacement parts, contact Haiku Customer Service at www.haikufan.com/ service. -
Page 17: Limited Lifetime Warranty
Return Materials Authorization (RMA) number. You will be responsible for all shipping insurance, freight, or other transportation charges to our service center. Your Haiku fan should be properly packed to avoid damage in transit since we will not be responsible for such damage. - Page 18 LIMITED LIFETIME WARRANTY (CONT.) e) Any event beyond the control of Big Ass Fans and occurring after the Product is no longer in our control. Additionally, this warranty ceases to apply when: a) The original purchaser or user ceases to own the product; or b) The product is moved from its original point of installation.
