Summary of Contents for Ironton 46682
- Page 1 TOE-KICK SAW OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 46682...
-
Page 2: Intended Use
Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Important Safety Considerations
SAVE THESE INSTRUCTIONS IMPORTANT SAFETY CONSIDERATIONS WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your corded power tool. - Page 4 e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts.
- Page 5 Hold power tool by insulated gripping surfaces when performing an operation where the • cutting tool may contact hidden wiring or its own cord. Contact with a ″live″ wire will also make exposed metal parts of the power tool ″live″ and shock the operator. When ripping, always use a rip fence or straight edge guide.
- Page 6 Check guard for proper closing before each use. Do not operate the saw if guard does • not move freely and enclose the blade instantly. Never clamp or tie the guard with the blade exposed. If saw is accidentally dropped, guard may be bent. Check to make sure that guard moves freely and does not touch the blade or any other part, in all angles and depths of cut.
- Page 7 People with pacemakers should consult their physician(s) before use. Electromagnetic fields in • close proximity to heart pacemaker could cause pacemaker interference or pacemaker failure. In addition, people with pacemakers should avoid operating alone. Do not use with Trigger locked on. •...
- Page 8 Double Insulated Tools: Tools with Two Prong Plugs Tools marked “Double Insulated” do not require grounding. They have a special double insulation system which satisfies OSHA requirements and complies with the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code.
- Page 9 Symbology Page of 18...
- Page 10 ASSEMBLY TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Make sure that the Trigger is in the off position and unplug the tool from its electrical outlet before performing any procedure in this section. TO PREVENT SERIOUS INJURY FROM FLYING FRAGMENTS: Do not use blades made from high-speed steel, abrasive blades, or metal- or masonry-cutting blades.
- Page 11 4. Remove the Blade. 5. Install the new blade over the Arbor Adaptor Plate. Make sure the Arbor Adapter Plate is properly seated on the Shaft. Guide the Saw Blade onto the pins of the Arbor Adaptor Plate. The Saw Blade teeth at the bottom of the Saw Blade should be pointing toward the front of the Saw.
-
Page 12: Operation
3. Route the power cord along a safe route to reach the work area without creating a tripping hazard or exposing the power cord to possible damage. The power cord must reach the work area with enough extra length to allow free movement while working. 4. - Page 13 b. Remove the carbon brushes from the housing. Keep track of which orientation the old carbon brushes were in to prevent needless wear if they will be reinstalled. c. If either carbon brush is worn down by more than 1/2, replace them both. d.
- Page 14 Page of 18...
- Page 15 DIAGRAM AND PARTS LIST Page of 18...
- Page 16 Part Name Part Name Screw M8*16 Bearing Blade Rubber Pin Locating Plate Brake Spring Check Ring Stopping Plate Protecting plate Rotor Torsional Spring Bearing Screw M4*10 Screw ST4*14 Guard Handle Cap Pinion Spring Wind Baffle Steel Ball Screw ST4*60 Base of guard Stator Screw M4*8 Bearing Cover...
- Page 17 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
- Page 18 Page of 18...
