Nitecore TM06S User Manual

The All-Round Flashlight Expert
Features
• Compact and lightweight 4000 Lumens flashlight
• Utilizes four CREE XM-L2 U3 LEDs
• Uses four 18650 batteries for maximum runtime up to 560 hours
• Features advanced temperature regulation (ATR) technology
• Innovative two-stage side switch accesses various modes and
functions (Chinese Patent: ZL201120062948.1)
• Integrated power indicator in side switch indicates remaining battery
power (Chinese Patent: ZL201220057767.4)
• Power indicator displays battery voltage accurate to 0.1V
• Intelligent memory function for brightness levels
• Direct access to ultralow and turbo outputs
• Toughened ultra-clear mineral glass with anti-reflective coating
• Integrated "Precision Digital Optics Technology" provides extreme
reflector performance
• Stainless steel bezel ring protects core components from damage
• Constructed from aerospace grade aluminum alloy
• HAIII military grade hard-anodized
• Waterproof in accordance with IPX-8 (submersible to 2 meters)
• Tail stand capability
Dimensions
Length: 4.74" (117mm)
Head diameter: 1.97" (50mm)
Tube diameter: 1.97" (50mm)
Weight: 9.39oz (266g) (without batteries)
Battery Options
TYPE
18650 Rechargeable Li-ion battery 18650
Primary Lithium battery CR123
Rechargeable Li-ion battery RCR123
*Warning: Do not use the TM06S with RCR123 or CR123 batteries.
Otherwise the flashlight may be damaged.
Output & Runtime
TURBO
HIGH
4000 1500
LUMENS LUMENS
1 4
h h
32,300cd
IPX-8, 2m
NOTICE:
The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1 using 4 x 3.7V 3400mAh
18650 batteries under laboratory conditions. The data may vary slightly
during real-world use due to battery type, individual usage habits and
environmental factors.
Accessories
Quality holster, lanyard,
spare O-ring
Nominal voltage Compatible
Yes
3.7V
(Recommended)
3V NO
3.7V NO
MID LOW LOWER
480 160
LUMENS LUMENS LUMENS
11 15 n 32h 560h
h mi
359m
(Beam Distance)
(Peak Beam Intensity)
1.5m
(Impact Resistant)
(Waterproof AND Submersible)
Thanks for purchasing NITECORE!
®
TM06S
Operating Instructions
Battery Installation
1. Insert batteries with the positive (+) and negative (-) ends
corresponding to the diagram on the inside of the battery compartment.
2. Tighten the tailcap by aligning the two metal pins on the tailcap with the
corresponding holes on the flashlight body, and rotate clockwise.
NOTE: After loading batteries, the power indicator light will blink to
indicate battery voltage. Please refer to "Power Tips" section of this
manual for details
WARNING:
1. Do not mix batteries of different types/brands.
2. When the TM06S is stored in a backpack or left unused for extended
periods, Nitecore recommends the tailcap is loosened to cut off the power
entirely, thus preventing accidental activation of the flashlight.
On/Off Operation
To turn on: press the side switch all the way down until a "click" is heard;
To turn off: press the side switch all the way down again until a "click" is
heard to turn the light off and enter standby mode.
Standby mode: In standby mode, press the side switch partway down to
activate the power indicator to flash once every three seconds, thus
helping users locate the flashlight in dark conditions. To turn off the power
indicator, press the side switch half way down again.
In standby mode, the TM06S operates for up to 40 days with the power
3
indicator on and up to 138 days with the power indicator off.
Brightness Levels
With the light turned on, press the side switch partway down repeatedly
to cycle through lower, low, medium, high and turbo brightness
levels.TM06S has memory effect for brightness levels. When the
flashlight is turned on, it will resume on the brightness level last used.
Direct Accesses to Lower/Turbo
In standby mode, press and hold side switch partway down to enter lower
mode (3 lumens).
In standby mode, press and hold the side switch all the way down to
enter turbo mode (4000 lumens)
Special Modes (Strobe/Location Beacon/SOS)
With the light turned on, press and hold the side switch all the way down
for more than one second to enter Strobe mode. To cycle through SOS,
