Nitecore TM 11 User Manual

Your Ideal Lighting Solution
Features
The world's smallest and lightest 2000 lumen flashlight
·
Utilizes three CREE XM-L LED
·
Thermal protection circuit prevents overheating
·
Compatible with both 18650 Li-ion and CR123 batteries
·
Exceptionally long runtimes using 4×18650 Li-ion or 8×CR123 batteries
·
Capable of using 1×18650 or 2×CR123 batteries in emergency situations
·
Innovative single button two-stage switch offers versatile functionality
·
(Patented)
Integrated power indicator light displays remaining battery power
·
(Patented)
Power indicator secondary function displays battery voltage (accurate to
·
0.1V)
Coated mineral glass resists scratches
·
Aluminum reflector ensures a smooth and powerful beam
·
Stainless steel retaining ring protects the core components from damage
·
Constructed from aircraft grade aluminum alloy
·
HA III Military grade hard anodized
·
IPX-8 standard waterproof (two meters)
·
Dimensions
Length: 135mm
Head diameter: 60 mm
Tube diameter: 50mm
Weight 336g (without battery)
Accessories
Quality holster, lanyard, spare O-ring
Output & Runtime
TURBO
2000 1100
LUMENS LUMENS
1 15
h min
283m
20000cd
1.5m
IPX-8, 2m
NOTICE
Stated data has been measured according to the international flashlight
testing standards ANSI/NEMA FL1 by using eight SYSMAX CR123 batteries
in the laboratory. The data may vary due to different battery usage and
environment conditions.
Operation instructions
Battery installation
Insert 4 × 18650 Li-ion or 8 × CR123 batteries with the positive (+) end
pointing toward the flashlight head. In special circumstances, such as an
emergency situations, one to three 18650 Li-ion or two to six (R) CR123
batteries may be used. After loading the batteries, the power indicator light
will flicker to show the battery voltage. Please refer to the "Power Tips"
section of this manual for details.
HIGH MID LOW
550 200
LUMENS LUMENS
3 7 30 18
h h min h
(Beam Distance)
(Peak Beam Intensity)
(Impact Resistant)
(Waterproof AND Submersible)
Thanks for purchasing NITECORE!
®
TM 11
Note: The potential risks of over-discharging batteries can include
leakage and explosion so caution must be exercised when
using less than 4 x 18650 or 8 x CR123. Ensure you know
your batteries' limits and use the TM11's emergency
functionality sparingly. Furthermore, maximum output may be
reduced when using less than the maximum amount of
batteries.
WARNING
1. Insert batteries with the positive (+) end pointing toward the
flashlight head.
2. Do not mix rechargeable and non-rechargeable batteries.
3. Do not mix batteries of different types/brands.
4. Do not mix batteries of different charge levels.
5. Do not use lithium batteries without a protected circuit board.
6. This product does not support 18650 rechargeable Li-ion
batteries without protection circuit board as the battery length will
be too short to be used.
General Operation
NB: The TM11 utilizes a 2-stage switch (similar to a camera shutter
button). The light's numerous functions are selected according
to the depth the switch is pressed.
The TM11 has two modes: Daily mode and Turbo mode.
With the light turned off:
Press the switch partway down and hold to enter Momentary Daily
·
mode. Release the switch to turn the light off again.
Press the switch all the way down and hold to enter into
·
Momentary Turbo mode. Release the switch to turn the light off
again.
Press the switch partway down and release within one second to
·
access Constant Output Daily mode. Press switch to turn light off
again.
Press the switch all the way down and release within one second
·
to access Constant Turbo mode. Press switch to turn light off
again.
