SERVICE SETTINGS

Service settings are password protected and normally
should be used by an authorized technician only.
The SERVICE SETTINGS parameters are spread over
multiple menu pages.
The default password for the service settings menu is
"1234", this may be modified within the SERVICE
SETTINGS menu. Please notice that the password
digits should NOT be entered using the numeric keys
on your remote control! Please use up and down keys
to change a digit followed by the OK key to confirm.
BOOT POWER OPTION
Determine the recovery power mode of the screen after a
power interruption, choose from Last, Standby, Power On or
Instant.
OSD ACCESS
(De)activate the ability to see the OSD menu once setup key
is used. NEVER set this parameter to OFF unless you are
provided with a special service password by ad notam
If the OSD menu is set to OFF (deactivated), users will not
be able to access the OSD menu anymore without a
special service password! This special service password
will be provided by ad notam to an authorized technician
only upon a written request.
START LOGO
(De)activate the "ad notam" start-up logo that shows on
booting.
IR ADDRESS CODE
In order to control a single screen in a multi-screen installation
both the screen and the IR REMOTE are needed to be set up for
a dedicated IR address, otherwise a single remote will affect all
screens. You can set a unique IR address code for the screen
according to your preferences, choose from value of "0" up to
"254". The default (master) IR address code is "0". To set an IR
address on a Waterproof IR Remote please press and hold both
learn and power keys simultaneously until the remote's LED
indicator lights constantly. While the LED
constantly press and release a sequence of 3 numeric keys
matching your new IR address (address codes "000" to "254" are
available).
INPUT SCAN
(De)activate the automatically scan of the input ports for a valid
video signal. Once there is no video signal at the currently
selected input port the screen will search for a video signal on
the other ports by the following sequence:
HDMI 1 > HDMI 2 > HDMI 3 > Component > HDMI 1... and so
on (See also SIGNAL LOSS TIMER).
SIGNAL LOSS TIMER
Set a time span for how long the input scan should be
performed once a video signal is not present on current selected
input port. Choose from 5s, 10s, 30s, 60s or120s. The screen will
switch to STANDBY mode if no video signal is present within the
chosen time. If signal loss timer is set OFF the search will
continue indefinitely or until a signal is present again.
VOLUME LIMIT Determine the maximum volume level value,
choose from value 0% (no sound) up to 100% (full volume level).
27
