Ad Notam REFLEXION Owner's Manual page 26

ON SCREEN DISPLAY (OSD MENU)
SCREEN AUDIO SETTINGS
SOUND MODE
Define the sound mode according to your preferences,
choose from standard, music, movie, sports or user.
In user mode the settings for bass and treble may be
adjusted manually.
BALANCE
Adjust the balance between the left and the right speaker,
choose from -50 (totally left) to +50 (totally right).
BOOT VOLUME
Define a volume range at startup when your screen is
switched ON, choose from last or user. In user mode the
startup volume level can be manually defined between 0%
(no sound) up to 100% (full volume level).
SPEAKER PROTECTION
(De)activate the speaker protection that limits a quick
increase in volume to be passed on to the speaker output
port in order to prevent damages to the speakers.
SCREEN OSD SETTINGS
OSD LANGUAGE
Define the OSD menu language; choose from English,
Español, Français, Deutsch, Português, Italiano.
OSD TRANPARENCY
Set the transparency of the OSD menu; choose from 0%, 25%,
50% or 75%.
OSD TIME OUT
Determine a time span after that the OSD menu fades out
automatically; choose from 15s, 30s, 60s or 180s.
SCREEN SETUP SETTINGS
SAVE CURRENT SETTINGS TO USB
Transfer your individual device settings to a USB stick.
Connect a USB stick to the corresponding input of the
LOAD SETTINGS FROM USB
Load previously saved device settings from a USB stick.
Connect a USB stick to the corresponding input of the
Screen.
your current settings.
SOFTWARE UPDATE
Use this feature in order to update the screen's software
(firmware) version via a connected
Please make sure that the software file on the USB flash
drive is the correct version for your screen. Please
notice that every screen size has dedicated software file.
Once there is no USB flash drive connected, an error
message will appear: Can´t detect USB.
In order to have access to the USB port after
installation it is highly recommended to install
a USB EXTENSION CABLE
26
This will overrule
USB flash drive.
