Summary of Contents for World Dryer Q-Series VERDEdri
- Page 1 IFS Ltd t/a Intelligent Hand Dryers UK www.intelligenthanddryers.com 0114 286 6394...
- Page 2 VERDEdri Hi-Speed Surface-Mounted ADA Compliant Hand Dryer Secamanos compatible con ADA, de montaje en superficie, de alta velocidad Sèche-mains grande vitesse monté en surface conforme à l’ADA Oberflächenmontierter ADA-konformer Hochgeschwindigkeits-Händetrockner Asciugamani elettrico ad alta velocità e conforme ADA per montaggio su superficie All “Q”...
-
Page 3: Electrical Specifications
Description World warm air hand dryer is a surface-mounted ADA (American Disabilities Act) compliant dryer powered by a universal brushed motor, and delivers up to 950 watts of drying power. These models operate at all voltages 115 – 230VAC, incorporate an integrated heating element, blower speed control and infrared sensor for automatic activation. Your specific model may include a high efficiency particulate absorption (HEPA) filter to remove a minimum of 99.97% of contaminants at 0.3 microns in size or larger. -
Page 4: Installation
Unpacking 1. Remove all packing material. Recycling is recommended. 2. Carefully remove the hand dryer from the shipping carton, using care not to drop the appliance. 3. Inspect carefully for any damage that may have occurred during transit. Check for any loose, missing or damaged parts. -
Page 5: Adjusting Blower Speed
Adjusting Blower Speed These models include adjustable blower speed control for (2) levels of operation – Hi, and Low. The switch is located on the printed circuit board inside the dryer as shown in Fig. 1 below. Note: The factory setting for the blower speed control is “Hi”. To adjust blower speed: 1. -
Page 6: Parts List
Parts List Repair Parts List For VERDEdri Hand Dryer ™ All kits include fasteners needed for installation.Part Number for Cover Assy. (Reference Number 7) varies with model number for hand dryer. For Repair Parts, visit www.WorldDryer.com Please provide following information: Model number Serial number Part description and number shown in... -
Page 7: Maintenance And Cleaning Instructions
Maintenance and Cleaning Instructions IMPORTANT: The dryer may collect lint and debris that is naturally present in the air. Excessive build up of lint and debris can damage the motor and heating element. The dryer should be cleaned on a routine schedule to maintain the dryer in good operating condition With light to moderate wash room traffic, cleaning once a year is recommended. - Page 8 The printed circuit board includes a set of LED’s that indicate the operational status of the hand dryer. When contacting World Dryer Technical Service, be prepared to remove the dryer’s cover and provide the condition of the LED’s as they can be helpful in troubleshooting the dryer. See Figure 1 for location of diagnostic LED’s on the printed circuit board.
-
Page 9: Troubleshooting Chart
Limited Warranty World LIMITED FIVE – YEAR WARRANTY. World Warm Air Hand Dryer, Model covered in this manual, is warranted by World Dryer Corporation to the origi- nal user against defects in workmanship or materials under normal use for 5 years after date of purchase excluding normal wear and tear, or expendable parts such as HEPA filters, motor brushes, etc.
