Surface-Mounted ADA Compliant Hand Dryer
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or service
the product described. Protect yourself and others by observing all safety information. Failure to comply with
instructions could result in personal injury and/or property damage. Retain instructions for future reference.
SLIMdri
All "L48-" Series
1
™
World Dryer Corporation
5700 McDermott Drive
Berkeley, IL 60163 U.S.A.
800-323-0701
www.worlddryer.com
Advertisement
Related Manuals for World Dryer SLIMdri L48 Series
Summary of Contents for World Dryer SLIMdri L48 Series
- Page 1 Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage. Retain instructions for future reference. World Dryer Corporation 5700 McDermott Drive Berkeley, IL 60163 U.S.A.
-
Page 2: Specifications
Description World warm air hand dryer is a surface-mounted ADA (American Disabilities Act) compliant dryer powered by a universal brush motor, and delivers up to 950 watts of drying power. The dryer incorporates an integrated heating element with options for operation with, or without, heated air. An infrared sensor is used to automatically activate the dryer. These models are intended for use in commercial, industrial, office and public facility environments. -
Page 3: Parts List
Parts List Repair Parts List For SLIMdri™ Hand Dryer Description Part Number Kit, Dryer Controls 16-10130K Kit, Motor 32-230(A)K All kits include fasteners needed for Kit, Motor Clamps 33-10082K installation.Part Number for Cover Assy. (Reference Number 5) varies with model Kit, Heating Element 21-10144K number for hand dryer. -
Page 4: Installation
Installation 1. Disconnect the power source. 2. Using Table 2 to determine the recommended mounting height, select a mounting location for the hand dryer where no reflective surfaces or objects (such as a hand basin) are directly under the infra-red sensor eye. The infra-red sensor eye is visible from the bottom of the dryer. -
Page 5: Maintenance And Cleaning Instructions
The heating element control is located on the printed circuit board inside the dryer. To adjust heating element controls: 1. Disconnect the power source. 2. Use the security hex key supplied to turn the cover mounting screws clockwise to remove the cover from the dryer. 3. -
Page 6: Limited Warranty
Limited Warranty World LIMITED TEN – YEAR WARRANTY. World Warm Air Hand Dryer, Model covered in this manual, is warranted by World Dryer Corporation to the original user against defects in workmanship or materials under normal use for 10 years after date of purchase for all components except motor brushes (3 years), motor (5 years) and sensor (5 years).
