3.3 Rack mounting the DX central and User units

Use the L-shaped brackets and screws provided to mount the DX units on a server
rack as illustrated below.
5
I
SE RVICE
0
1
P OWE R
100- 250 V AC 50 /6 0 Hz SE RIAL

3.4 Rack mounting the XRICCs

You can attach the XRICCs to a server rack or computer using the Velcro strips
provided. Or connect it using the bracket provided.
The figure below illustrates the bracket. Use the screws that came with rack to
connect the bracket to the rack. Once secured, clip the XRICC into the bracket.
6 7 8 17 18 19 20 21 22
2 3 4 1 2 3 4 5 6
USER
Figure 6 Connecting the L-shaped bracket
Figure 7 Rack mounting the XRICC
USER GUIDE
23 24 25 2 6 2 7 2 8 29 3 0 3 1
7 8 9 10 1 1 1 2 13 14 1 5
SERVER
Insert screws through
2 of the 3 holes in the
bracket and connect
to a rack
10
3 2
1 6
ETHERNE T
Insert screws to connect
to DX Central side panel
Insert
screws to
connect to
rack
