3 .
Connection overview, adapter leads and power cables
0
0
I t e m
Description
A
Adapter lead
A1
17-pin pin housing
A2
17-pin socket housing
A3
Cable shoe 6 mm
A4
25-pin socket housing
A5
Stranded wire
A6
Flat-pin terminal
B
Power cable
B1
Fuse holder with fuse (20 A)
B2
Cable shoe 6 mm
The X-designations marked with * apply to this overview only and do not refer to the general service documentation.
Retrofit/installation kit No.: 82 83 0 136 491
Installation instruction No.: 01 29 0 139 395
W i r e
c o l o u r /
Signal
cross
s e c t i o n
---
---
---
---
---
---
Ground
brown/
4 mm
2
---
---
red/4 mm
2
---
---
---
---
---
---
---
Terminal
red/4 mm
2
30
Status: 06.2001
Connection location in vehicle
---
17-pin radio plug connector X2519
on vehicle wiring harness
radio in instrument panel
ground terminal point, splashboard
in engine compartment
amplifier
cut to length, crimp on supplied flat-
pin terminal A6 and plug into fuse
holder B1
crimp on branch A5
---
secure in battery box
battery positive terminal
D e s i g n a t i o n /
p l u g - i n slo t
---
X2*
X2519
---
X1*
---
---
---
---
---
EN/6
