Ip Phone Provision - Planet Networking & Communication IPX-2100 User Manual

Pause Queue Member
Extension
Unpause Queue Member
Extension
Others

4.15 IP Phone Provision

When you need many IP Phones, please record the MAC, extension number, and user name
of each phone according to the format (please take reference of the auto provision script file
model for details). Then import the format file. Once the phone is connected to the local
network, it will get the extension number and password automatically.
There are two operation methods to fulfill this function. Please see details as shown below:
Enable DHCP service
Click【Network Settings】->【DHCP Server】, enable DHCP Server in the dialog as shown
below:
Then Click【Advanced】->【Phone Provisioning】->【New Phone】:
to invite the participant. When the call is connected, you can dial "*#"
to hang up and return the conference yourself.
Pause the agent, and the agent cannot receive the call.
Unpause the agent, and the agent can receive the call.
Function key for Intercom/ Paging/ Directory
75
Internet Telephony PBX System
IPX-2100
