LED definitions
Front Panel LED
Steady Green
PWR
Off
Blinking Green
SYS
Off
Blinking Green
ETH
Off
Steady Red
FXO
Flashing
Off
Steady Green
FXS
Flashing
Off
Void
USB
1 12V DC
2 Reset
3 ETH
4
FXO Port
5
FXS Port
Button Action
Press less than 6 secs
Reset
Press over 6 secs
Please be reminded to reset to factory default. Uploaded music setting (on hold
music) and backup file will not be removed.
State
PBX Power ON
PBX Power OFF
System is working
System is off
PBX network connection established
Waiting for network connection
Ready / Standby
Ringing
Module not available
Ready / Standby
Ringing
Module not available
Future Feature
12V DC Power input outlet
The reset button, when pressed, resets the IP PBX without the
need to unplug the power cord.
The ETH port supports auto negotiating Fast Ethernet 10/100
Base-TX networks. This port allows your IP PBX to be connected to
an Internet Access device, e.g., router, cable modem and ADSL
modem through a CAT.5 twisted pair Ethernet cable.
Connect to PSTN or PBX SLT line with RJ-11(Write) analog line.
Connect to PBX CO or single line telephone with RJ-11(Write)
analog line.
Description
System reboot.
Reset to Factory Default
15
Internet Telephony PBX System
Description
IPX-2100
