Chapter 2 Installation Procedure; Web Login - Planet Networking & Communication IPX-2100 User Manual

Chapter 2 Installation Procedure

2.1 Web Login

Step 1. Connect a computer to an ETH port on the IPX-2100. Your PC must set up to the
same domain of 192.168.0.X as that of the IPX-2100.
Step 2. Start a web browser. To use the user interface, you need a PC with Internet Explorer
(version 6 and higher), Firefox, or Safari (for Mac).
Step 3. Enter the default IP address of the IPX-2100: 192.168.0.1 in the URL address box.
Step 4. Enter the default user name
Login to enter Web-based user interface.
(Default IP)
Default ETH IP: 192.168.0.1
Default User Name: admin
Default Password: admin
For security reason, please change and memorize the new password after this first
setup.
admin and the default password admin, and then click
Figure 2-1. Login page of the IPX-2100
18
Internet Telephony PBX System
IPX-2100
