TECshow octobeam User Manual page 5

7. 7. 7. 7. Photometric Photometric Data
Photometric Data Photometric Data Data
from a ceiling, or set on a flat level surface (see illustra on below). Be sure this fixture is kept at least
0.5m (1.5 ) away from any flammable materials (decora on etc.).
Always use and install the supplied safety cable as a safety measure to prevent accidental damage and/or
injury in the event the clamp fails.
Moun ng points Moun ng Moun ng Moun ng points: : : : Overhead moun ng requires extensive experience, including amongst others points points
calcula ng working load limits, a fine knowledge of the installa on material being used, and periodic
safety inspec on of all installa on material and the fixture. If you lack these qualifica ons, do not a empt
the installa on yourself. Improper installa on can result in bodily injury.
Be sure to complete all rigging and installa on procedures before connec ng the main power cord to the
appropriate wall outlet.
Moun ng: : : : The OCTOBEAM provides two unique moun ng bracket assembly that
Clamp Moun ng Clamp Clamp Clamp Moun ng Moun ng
integrates the bo om of the base, the included "Omega Bracket," and the safety cable rigging point in one
unit (see the illustra on below). When moun ng this fixture to truss be sure to secure an appropriately
rated clamp to the included omega bracket using a M10 screw fi ed through the center hole of the
"omega bracket". As an added safety measure be sure to a ached at least one properly rated safety cable
to the fixture using on of the safety cable rigging point integrated in the base assembly
