TECshow octobeam User Manual page 4

3. 3. 3. 3. Operation Operation Operation Operation Ins truc tions Ins truc tions Ins truc tions Ins truc tions
-T he OCTOBEAM is for beam effect for on-s ite decoration purpos e.
-Don't turn on the fixture if it's been through s evere temperature difference like after
trans portation because it might damage the light due to the environment changes . S o make s ure
to operate the fixture until it is in normal temperature.
-T his light s hould be keep away from s trong s haking during any trans portation or movement.
-Don't pull up the light by only the head, or it might cause damages to the mechanical parts.
-Don't expose the fixture in overheat, mois ture or environment with too much dust when ins talling
it. And don't lay any power cables on the floor. Or it might cause electronic s hock to the people.
-Make s ure the ins tallation place is in good s afety condition before ins talling the fixture.
-Make s ure to put the s afety chain and check whether the sc rews are sc rewed properly when
ins talling the fixture.
-Make s ure the lens are in good condition. It's recommended to replace the units if there are any
damages or s evere sc ratch.
-Make s ure the fixture is operated by qualified pers onnel who knows the fixture before us ing.
-K eep the original packages if any s econd s hipment is nee ded.
-Don't try to change the fixtures without any ins truction by the manufacturer or the appointed
repairing agencies .
-It is not in warranty range if there are any malfunctions from not following the us er manual to
operate or any illegal operation, like s hock s hort circuit, electronic s hock, lamp broke, etc.
4. 4. 4. 4. Mounting Mounting Mounting Mounting and and and and Ins tallation Ins tallation Ins tallation Ins tallation
Cau ons: For added protec on mount the fixtures in areas outside walking paths, sea ng areas, or in Cau ons: Cau ons: Cau ons:
areas were the fixture might be reached by
unauthorized personnel.
Before moun ng the fixture to any surface, make sure that the installa on area can hold a minimum
point load of 10 mes the device's weight.
Fixture installa on must always be secured with a secondary safety a achment, such as an appropriate
safety cable.
Never stand directly below the device when moun ng, removing, or servicing the fixture.
8.DMX 8.DMX C hannels 8.DMX 8.DMX C hannels C hannels C hannels
Fu nc tion Fu nc tion Fu nc tion Fu nc tion Values Values Values Values Des c ription Des c ription Des c ription Des c ription
C hannel C hannel C hannel C hannel
MOD1 MOD 2
1 1 Dimmer 0-255 Dimmer 0%...100%
0-009 No Func on
2 2 Shu er 010-249 Strobe effect slow to fast
250-255 No Func on
3 3 TILT 0-255 TILT movement
4 TILT Fine 0-255 Fine control of Tilt movement
5 4 Speed 0-255 Max to min speed for TILT
0-019 No Func on
020-029 No Func on
030-039 No Func on
040-079 No Func on
080-099 Motor reset
100-119 Internal program 1
6 5 Special 120-139 Internal program 2
140-159 Internal program 3
160-179 Internal program 4
180-199 Internal program 5
200-219 Internal program 6
220-239 Internal program 7
240-255 Internal program 8
7 6 Pixel 1 0-255 Pixel 1 satura on control (0-100%)
8 7 Pixel 2 0-255 Pixel 1 satura on control (0-100%)
9 8 Pixel 3 0-255 Pixel 1 satura on control (0-100%)
10 9 Pixel 4 0-255 Pixel 1 satura on control (0-100%)
11 10 Pixel 5 0-255 Pixel 1 satura on control (0-100%)
12 11 Pixel 6 0-255 Pixel 1 satura on control (0-100%)
13 12 Pixel 7 0-255 Pixel 1 satura on control (0-100%)
