1. 1. 1. 1. Un Un Unpacking Un packing packing packing
Thank you for choosing OCTOBEAM For your own safety, please read this manual
before installing the device. This manual covers the important information on installation and
applications. Please install and operate the fixture with following instructions. Meanwhile, please
keep this manual well for future needs.
OCTOBEAM is made of a new type of high temperature strength of engineering plastics
and cast aluminum casing with nice outlook. The fixture is designed and manufactured strictly
following CE standards, complying with international standard DMX512 protocol. It's available
independently controlled and linkable with each other for operation. And it is applicable for small to
medium live performances, theater, studio, nightclubs and discos.
OCTOBEAM adopts 8PCS high power 8W White LEDs which features high brightness
and stability. Please carefully unpack it when you receive the fixture and check whether it is
damaged during the transportation. And please check whether the following items are included
inside the box:
OCTOBEAM ---------One Signal Cable----One
Omega Clamp-------Two Power Cable----One
Safety Chain---------One User Manual----One
9. 9. 9. 9. Key Key Features Key Key Features Features Features
8PCS 8W high power WHITE LEDs
100,000 hours lifespan and low power consumption
8 pixels (each LED is a pixel), controllable individually
Outstanding white BEAM effect
Specific optic system
High light output with 4870LUX@7M for 8 BEAMs, 1770LUX@7M for 1 BEAM
High efficiency LED shutter
Strobe effect with 18 flashes per second and pulse effect
0-100% smooth NEO-HLP-80
Amazing streaming effect
8 built-in default programs for easy performance
12 default pixel macros effect
14/15 DMX channels
DMX512, master-slave and sound activated controllable or auto operation
LED display
Efficient Noise free aluminum cooling system
Powercon IN/OUT as default
3-pin XLR connectors
Two 1/4 turn fastening Omega Clamps
10. Technical 10. 10. 10.

Technical Specifications

Technical Technical Specifications Specifications Specifications
Input Voltage: AC90-260V 50/60Hz
LED Quantities: 8PCS 8W WHITE LEDs
Control Signal: DMX512, master-slave and sound activated or auto operation
Control Channel: 14/15 DMX Channels switchable
Power Consumption: 120W
Dimensions: 84(D)x1064(W)x180(H)mm
Packing Dimensions: 165(D)x1165(W)x220(H)mm
Net Weight: 7.5kg
Gross Weight: 10kg
