Summary of Contents for TECshow Alfie
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. BEFORE YOU BEGIN......................3 WHAT IS INCLUDED............................3 UNPACKING INSTRUCTIONS ........................... 3 AC POWER ..............................3 SAFETY INSTRUCTIONS..........................4 2. INTRODUCTION ........................5 FEATURES............................... 5 DMX CHANNEL SUMMARY 12 CHANNEL MODE FOR WASH................5 DMX CHANNEL SUMMARY 4 CHANNEL MODE FOR WASH................. 6 PRODUCT OVERVIEW ............................. -
Page 3: Before You Begin
1. BEFORE YOU BEGIN What is included 1 x Mini wash User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully, it includes important information about the installation, usage and maintenance of this product. Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Always make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the decal or rear panel of the fixture. -
Page 5: Introduction
2. INTRODUCTION Features CONTROL FEATURES 4 or 12-channel DMX-512 LED moving yoke Pan: 540 / tilt: 180 Variable electronic strobe Variable electronic dimmer (0 100%) Vector speed channel for pan/tilt, RGBW color mixing and color macros Built-in movement macros via master/slave or DMX ADDITIONAL FEATURES User-selectable basic or advanced operating modes User-selectable pan/tilt ranges... -
Page 6: Dmx Channel Summary 4 Channel Mode For Wash
DMX Channel Summary - 4 Channel Mode for Wash CHANNEL FUNCTION Tilt Dimmer/Strobe Color Macros Product Overview LED lens Projector Head Control Panel LED Readout DMX Out DMX In IEC Power Connector with Fuse holder (Rear) -
Page 7: Setup
3. SETUP Disconnect the power cord before replacing a fuse and always replace with the same type fuse. Fuse Replacement With a flat head screwdriver wedge the fuse holder out of its housing. Remove the damaged The fuse is located fuse from its holder and replace with exact inside this same type fuse. -
Page 8: Cable Connectors
CAB LE C ONN ECTORS Cabling must have a male XLR connector on one end and a female XLR connector on the other end. DMX connector configuration Resistance 120 ohm 1/4w between pin 2 (DMX -) and COMMON pin 3 (DMX +) of the last fixture. -
Page 9: Master/Slave Fixture Linking
Master/Slave Fixture Linking 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. -
Page 10: Operating Instructions
4. OPERATING INSTRUCTIONS Navigating the Control Panel Access control panel functions using the four panel buttons located directly underneath the LCD Display. Button Function Used to access the menu or to return to a <MODE/ESC> previous menu option Scrolls through menu options in ascending <UP>... -
Page 11: Menu Map
Menu Map Use the <MODE/ESC> Use the <UP>,<DOWN>, button to scroll through and <ENTER> buttons to these menu items scroll through these menu items When navigating the menu: Use the “UP” button to move up. Use the “DOWN” button to move down. Use the “ENTER”... -
Page 12: User Configurations
User Configurations TO SET THE PAN TO INVERTING OR NON- INVERTING: 1) Press the Mode button until it shows 2) Use the Up/Down buttons to set to the desired inversion, press enter to confirm. TO SET THE TILT TO INVERTING OR NON- INVERTING: 1) Press the Mode button until it shows 2) Use the Up/Down buttons to set to the desired inversion, press enter to confirm. -
Page 13: Operation
Operation Stand-Alone Mode (Auto Mode): This mode allows a single unit to run to a factory installed program in one of two speeds. 1) To set the fixture in auto mode Fast, select . Once confirmed the display reads 2) To set the fixture in auto mode Slow, select Once confirmed the display reads Master/Slave Mode (Master Sound): This mode will allow you to link up to 32 units together without a controller. -
Page 14: Dmx Channel Values (12 Channel)
DMX Channel Values (12 Channel for Wash) CHANNEL VALUE FUNCTION Pan Fine Tilt Tilt Fine Vector Speed: (Normal Slow) Dimmer/Strobe Closed 100-0% Strobe (slow fast) Open 0-100% Green 0-100% Blue 0-100% White 0-100% Color Macros No Function Macro 1 Macro 2 Macro 3 Macro 4 Macro 5... -
Page 15: Dmx Channel Values (4 Channel )
DMX Channel Values (4 Channel for Wash) CHANNEL VALUE FUNCTION Tilt Dimmer/Strobe Closed 100-0% Strobe (slow fast) Open Color Macros No Function Macro 1 Macro 2 Macro 3 Macro 4 Macro 5 Macro 6 Macro 7 Macro 8 Macro 9 Macro 10 Macro 11 Macro 12... -
Page 16: Appendix
5. APPENDIX Technical Specifications WEIGHT & DIMENSIONS Length........................12in (300 mm) Width ........................9.5 in (240 mm) Height ........................9.5 in (240 mm) Weight ........................8.3 lbs (3.8 kg) POWER Switch-selectable power settings ............100-240V 50/60Hz Fuse..................... 3A 250V Power Consumption ................68.1W (0.30A) Max at 230V Inrush Power ..................
