Media POD
Unit operates on +12 VDC. Inadequate power grounding can result in equipment damage or destruction and
could void warranty. Ensure you utilize provided power supply unit only. Use of improper power supply can
****************************
Lethal operating voltages present at system power supply unit—internal and external units. Completely
disconnect main power cord prior to opening cover or removing any panels. Appropriately trained and
authorized personnel only should attempt any internal modifications, repairs, or service.
CONNECTIONS
Media POD Mini-Chassis Rear Panel Overview
Keyboard & Mouse if Required
Power Supply
RGBHV (VGA, WXGA, etc.)
Keywest Technology
th
14563 W. 96 Terrace
Lenexa, Kansas 66215
800.331.2019
www.keywesttechnology.com
***CAUTION***
damage or destroy the unit and will void the warranty.
WARNING
Composite Video Output
KWT TM 2-1-MEDIAPOD
24 July 2006
Change 01
Keywest Technology Information Systems
*****************************
Y/C Video Output
Composite & Y/C Video Inputs
Network
USB & Firewire Ports
Stereo Audio Out
